The YOKOGAWA ADV569-P00 serves as the critical link between safety controllers and field actuators in a ProSafe-RS system. Each module provides 8 channels of 4-20mA analog output with HART communication capability, allowing both basic control signal transmission and advanced device diagnostics. The module integrates with Yokogawa’s safety controllers via a proprietary safety network, using certified protocols that maintain the system’s safety integrity level. Its dual-processor architecture performs continuous self-checks and signal validation, while the hot-swappable design enables maintenance without system shutdown.
ADV569-P00
The module supports flexible configurations including current sinking or sourcing outputs, with individual channel isolation to prevent cross-talk between critical control loops.
ADV569-P00
Technical specifications:
Model Number ADV569-P00
Brand Yokogawa
Type Safety Analog Output Module
Output Type 4-20mA with HART (8 channels)
Resolution 16-bit
Accuracy ±0.1% of span
Safety Certification SIL3 (IEC 61508)
Response Time < 100 ms per channel
Operating Temp Range -20°C to +60°C
Mounting ProSafe-RS I/O Unit
Diagnostics Open wire, short circuit, HART device status
Power Consumption 3.2 W (typical)
Compliance CE, ATEX, IECEx
contact us:
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
ADV569-P00
Main features and advantages:
The YOKOGAWA ADV569-P00 delivers operational confidence through its combination of precision, safety, and diagnostic capabilities. Control engineers benefit from its ±0.1% accuracy when managing sensitive processes like reactor temperature control or flow regulation. The SIL3 certification ensures compliance with the most stringent safety requirements, while the integrated HART communication enables predictive maintenance by monitoring valve positioner health and other field device parameters. Maintenance teams appreciate the module’s comprehensive diagnostics that quickly identify whether issues originate in the module, wiring, or field devices. The hot-swappable design significantly reduces downtime during maintenance operations, as modules can be replaced without taking the entire safety system offline.
ADV569-P00
Application areas:
In LNG plants, the ADV569-P00 precisely controls emergency shutdown valves where response time and signal accuracy are critical for safety. Petrochemical facilities use it to manage reactor feed control valves in batch processes where consistent output ensures product quality. Power generation applications leverage its HART capability to monitor and control turbine inlet valves while gathering diagnostic data. The module excels in these scenarios due to its combination of safety certification, signal precision, and ability to operate reliably in harsh industrial environments with electrical noise and vibration.
ADV569-P00
Related products:
ADV569-T00 – Triple modular redundant version for maximum availability systems
ADV559-P00 – Non-HART version for basic analog output requirements
ADV579-P00 – High-density 16-channel version
ADV551-P50 – Digital input counterpart for safety systems
AAV551-P50 – Analog input module for safety-related monitoring
ADV569-P00
Installation and maintenance:
When installing the ADV569-P00, first verify compatibility with your ProSafe-RS controller version (R4.03 or later recommended). Use shielded, twisted-pair cables for all analog outputs and maintain proper separation from power cables. During commissioning, configure the appropriate fail-safe state for each channel (hold last value or predefined safe state). Regular maintenance should include annual verification of output accuracy and inspection of terminal connections.
For HART-enabled loops, utilize Yokogawa’s PRM software to monitor device health trends and configure alerts for abnormal conditions. Always follow safety procedures when performing maintenance on live systems.
