XO08R2 1SBP260109R1001 Digital Output Module

Description

XO08R2 1SBP260109R1001

The XO08R2 1SBP260109R1001 functions as a dedicated digital output module within industrial control systems, serving as the critical interface between programmable logic controllers (PLCs) and field-level actuators. Positioned between the controller’s processing unit and the physical devices it controls, this module converts low-power control signals from the PLC into robust output signals capable of driving industrial equipment.

XO08R2 1SBP260109R1001

This module integrates seamlessly with ABB’s AC 500 PLC system and other compatible control platforms, providing 8 individually configurable digital output channels for versatile control of diverse devices. The XO08R2 1SBP260109R1001 features built-in protection mechanisms, including short-circuit protection and overload detection, which safeguard both the module and connected equipment from electrical faults. It communicates with the host controller through a backplane bus, ensuring fast and reliable data exchange with minimal latency. The module’s design includes status indicators for each output channel, providing immediate visual feedback on operational status and simplifying troubleshooting. This combination of features ensures the XO08R2 1SBP260109R1001 delivers consistent, protected output control in a compact form factor.

XO08R2 1SBP260109R1001

Main features and advantages:

Selecting the XO08R2 1SBP260109R1001 delivers significant operational advantages that enhance control system reliability and performance. Its robust output protection features prevent damage to both the module and connected equipment in the event of electrical faults, reducing repair costs and minimizing downtime. The module’s high current capacity per channel (up to 2 A) provides flexibility to control a wide range of devices, from small solenoids to larger motors, eliminating the need for additional interface relays in many applications.

Engineered for industrial durability, the XO08R2 1SBP260109R1001 maintains consistent performance in harsh environments with temperature extremes, electrical noise, and vibration—common conditions in manufacturing and process facilities. This reliability ensures consistent operation even in challenging conditions, reducing the risk of unplanned production interruptions. The module’s integration with ABB’s AC 500 system simplifies system design and configuration, reducing engineering time during setup and modifications. Its compact form factor allows for high-density installation, optimizing control cabinet space utilization in applications where space is limited.

XO08R2 1SBP260109R1001

Application areas:

The XO08R2 1SBP260109R1001 excels in diverse industrial applications where reliable digital output control is essential. In packaging machinery, it controls critical actuators such as grippers, conveyor motors, and sealing mechanisms, ensuring precise timing and coordination of packaging processes. Its robust protection features prevent downtime caused by accidental short circuits, which are common in the fast-moving components of packaging lines.

In material handling systems, the module controls conveyor drives, sorting mechanisms, and stop gates, providing reliable actuation that ensures smooth product flow through distribution centers and manufacturing facilities. Its ability to handle up to 2 A per channel makes it suitable for direct control of small to medium-sized motors without additional relays. Additionally, in food and beverage processing, the XO08R2 1SBP260109R1001 controls valves, pumps, and mixing devices, supporting hygienic production processes with reliable performance in washdown environments. Its durability and protection features make it ideal for these applications where equipment reliability directly impacts production efficiency and product quality.

XO08R2 1SBP260109R1001

Related products:

XO16R2 1SBP260110R1001 – Higher channel count version with 16 digital outputs for larger systems.

XO08R1 1SBP260108R1001 – Lower current variant (1A per channel) for control of smaller devices.

XI08D2 1SBP260105R1001 – Complementary digital input module for monitoring sensors and switches.

XA04A2 1SBP260115R1001 – Analog output module for variable control of proportional devices.

XO08R2F 1SBP260109R2001 – Failsafe version compliant with SIL 2 requirements for safety-critical applications.

XC08L1 1SBP260120R1001 – Compact PLC bundle including XO08R2 outputs for small automation systems.

RE08R2 1SBP260130R1001 – Relay output module for applications requiring galvanic isolation.

Installation and maintenance:

Before installing the XO08R2 1SBP260109R1001, verify compatibility with the host PLC system, ensuring firmware versions support the module. Check that the backplane bus is properly powered and configured to supply the required 24V DC to the module. Confirm that the total current draw of all connected devices does not exceed the module’s maximum total current rating of 8 A to prevent overheating and performance issues.

For ongoing maintenance, perform monthly visual inspections of the module’s status LEDs—steady green indicators confirm normal operation, while red or flashing LEDs signal potential faults requiring attention. Every six months, inspect wiring connections for tightness and signs of corrosion, particularly in humid environments, as loose connections can cause intermittent operation or increased resistance. When replacing or reconfiguring connected devices, verify that their current requirements match the module’s capabilities. Before performing system updates, back up the PLC configuration to ensure the XO08R2 1SBP260109R1001 retains proper configuration settings after firmware upgrades.
