WOODWARD 9907-1200 Pressure converter

Description

Woodward 9907-1200 is a high-precision electric pneumatic current pressure converter. Its core function is to convert 4-20mA DC input signals into proportional 3-15psi pneumatic output signals, serving as a reliable bridge between electrical control systems and pneumatic operating equipment.

9907-1200

This conversion process has high accuracy, minimal hysteresis, and excellent repeatability, ensuring that the output pressure accurately reflects the input electrical signal. In industrial automation systems, it can seamlessly integrate with programmable logic controllers (PLCs), distributed control systems (DCS), and various sensors and actuators. The two-wire design of this converter simplifies the installation process as it only requires two wires to achieve power supply and signal transmission simultaneously. In addition, it adopts a universal installation design that can be flexibly installed in any direction without affecting its performance. The Woodward 9907-1200 also has built-in diagnostic capabilities that can quickly identify potential issues such as signal loss or pressure abnormalities, which helps reduce downtime and improve the reliability of the entire system.

9907-1200

Technical specifications:
Model 9907-1200
Brand Woodward
Type: Electric Pneumatic Current Pressure Converter
Input signal 4-20mA DC
Output signal 3-15psi
Input voltage 18-30 VDC
Working temperature range -40 ° C to+85 ° C
Universal installation method (in any direction)
Size 100mm x 80mm x 60mm
Weight 0.6 kg
Hysteresis ≤ 0.5% of the range
Repeatability ± 0.25% of the range
Certification CE, RoHS

Contact Us
Phone:+86 16626708626
WhatsApp/WeChat:+86 16626708626
Email: 3772179818@qq.com

9907-1200

Main features and advantages:
Significantly improve industrial operational efficiency. This product has been carefully designed to be sturdy and durable, capable of withstanding harsh industrial environments and ensuring long-term stable performance. Its high-precision conversion capability eliminates uncertainty in pressure control, thereby optimizing process operations. For example, in chemical plants, precise pressure regulation achieved through this converter can improve reaction yield, reduce waste, and enhance product quality, ultimately reducing production costs. The two-wire system and universal installation design not only simplify the installation process, but also reduce engineering costs, enabling faster deployment and easier integration into existing systems. The built-in diagnostic function supports proactive maintenance, as engineers can detect and resolve issues before they escalate, thereby reducing unplanned downtime and related losses.

9907-1200

Application areas:
In the chemical industry, it is used to control the pressure of reactors, valves, and other process equipment to ensure the safe and efficient conduct of chemical reactions. exist
In power plants, it plays a crucial role in regulating the pressure of turbines and other pneumatic drive components, helping to stabilize electricity production.
The oil and gas industry also relies on this converter for precise pressure control of pipelines, pumps, and compressors to maintain the integrity of extraction and transportation processes. In addition, it is also used in manufacturing factories to control pneumatic actuators in automated production lines, achieving accurate and consistent movement of machines.

9907-1200

Related products:
Woodward 9907-1201: With higher accuracy (0.15% repeatability of ± range) and enhanced diagnostic capabilities, it is suitable for applications that require ultra precise pressure control.
Woodward 9907-1199: Slightly lower accuracy, suitable for applications that prioritize cost-effectiveness and do not require high precision.
Woodward 9907-1200H: Designed specifically for hazardous environments, with higher safety levels and explosion-proof structures.
Woodward 9907-1200 Lite: Retains core conversion functionality, suitable for basic industrial applications with limited budgets.
Woodward 9907-1200 Pro: Provides advanced communication interfaces (such as support for HART protocol), seamlessly integrates with modern intelligent industrial systems, and has more comprehensive remote monitoring capabilities.

Installation and maintenance:
Before installing Woodward 9907-1200, it is necessary to verify the compatibility of its input voltage with the existing power system, ensuring that the voltage is within the range of 18-30 VDC.
Check the electrical connections to ensure correct polarity and secure wiring to prevent signal interference. For pneumatic connections, ensure that the pipe is compatible with the output pressure range and properly sealed to avoid air leakage. In addition, confirm that the input electrical signal source (such as PLC output module) is configured correctly and can provide a signal of 4-20mA

For daily maintenance, the status indicator lights of the converter should be checked regularly (if any) to see if there are any abnormal conditions. Regularly clean the pneumatic port to prevent dust and debris from affecting performance. Perform regular calibration checks to ensure the accuracy of the conversion process, especially in applications that require high precision pressure control.
