WOODWARD 9907-1183 High-Voltage Communication Interface Module
The WOODWARD 9907-1183 functions as a specialized interface bridge, connecting low-voltage control networks (such as PLCs, SCADA systems, or DCS platforms) with high-voltage equipment like circuit breakers, transformers, and switchgear. Positioned at the boundary between control and power systems, it converts communication protocols—translating signals from standard industrial buses (like Modbus TCP/IP or IEC 61850) into formats compatible with high-voltage devices, and vice versa.
Model Number 9907-1183
Brand Woodward
Type High-Voltage Communication Interface Module
Input Voltage 24 V DC ± 15% (control side); 220 V AC/DC (auxiliary power)
Operating Temp Range -40°C to +70°C
Mounting Style Panel mount with DIN rail adapter option
Dimensions 180 mm x 120 mm x 80 mm
Weight 850 g
Interface/Bus Modbus TCP/IP, IEC 61850, Profibus DP
Compliance IEC 61010 (safety), IEC 61850-3 (power system communication), CE, UL 508
Isolation Rating 5 kV RMS (galvanic isolation between low and high voltage sides)
Data Transfer Rate Up to 100 Mbps (full-duplex)
Redundancy Dual communication ports with automatic failover
Typical Power Draw 8 W (control side); 12 W (auxiliary power)
Operating Humidity 5% to 95% (non-condensing)
The WOODWARD 9907-1183 functions as a specialized interface bridge, connecting low-voltage control networks (such as PLCs, SCADA systems, or DCS platforms) with high-voltage equipment like circuit breakers, transformers, and switchgear. Positioned at the boundary between control and power systems, it converts communication protocols—translating signals from standard industrial buses (like Modbus TCP/IP or IEC 61850) into formats compatible with high-voltage devices, and vice versa.
9907-1183
What sets the WOODWARD 9907-1183 apart is its advanced isolation technology, which provides galvanic separation between low-voltage and high-voltage sides, preventing voltage transients from damaging sensitive control electronics. This module supports dual redundant communication paths, ensuring uninterrupted data flow even if one channel fails—a critical feature for maintaining critical system uptime. Unlike generic interface modules, the WOODWARD 9907-1183 is optimized for high-voltage environments, with enhanced noise filtering to maintain signal integrity in the presence of electromagnetic interference common in power distribution facilities.
9907-1183
Technical specifications:
Model Number 9907-1183
Brand Woodward
Type High-Voltage Communication Interface Module
Input Voltage 24 V DC ± 15% (control side); 220 V AC/DC (auxiliary power)
Operating Temp Range -40°C to +70°C
Mounting Style Panel mount with DIN rail adapter option
Dimensions 180 mm x 120 mm x 80 mm
Weight 850 g
Interface/Bus Modbus TCP/IP, IEC 61850, Profibus DP
Compliance IEC 61010 (safety), IEC 61850-3 (power system communication), CE, UL 508
Isolation Rating 5 kV RMS (galvanic isolation between low and high voltage sides)
Data Transfer Rate Up to 100 Mbps (full-duplex)
Redundancy Dual communication ports with automatic failover
Typical Power Draw 8 W (control side); 12 W (auxiliary power)
Operating Humidity 5% to 95% (non-condensing)
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
9907-1183
Main features and advantages:
Choosing the WOODWARD 9907-1183 delivers tangible operational benefits that extend beyond basic communication. Its robust isolation ensures that voltage spikes or surges in high-voltage systems—common during switching operations—do not propagate to control networks, reducing the risk of damage to PLCs or SCADA components. This protection translates to lower maintenance costs and fewer unplanned shutdowns, as critical control equipment remains shielded from electrical disturbances.
The module’s support for IEC 61850, the global standard for power system communication, eliminates protocol compatibility issues, reducing engineering overhead during system integration. Engineers no longer need to develop custom translation software, as the WOODWARD 9907-1183 natively handles the data formats required by both control systems and high-voltage devices. Additionally, its dual redundant ports ensure that communication remains uninterrupted even if a network cable fails or a port malfunctions—a key advantage in applications like renewable energy plants, where downtime can result in significant revenue loss. The module’s wide operating temperature range further ensures reliable performance in harsh environments, from unheated outdoor switchyards to temperature-fluctuating industrial facilities.
9907-1183
Application areas:
The WOODWARD9907-1183 is deployed in a range of critical applications where high-voltage communication is paramount. In renewable energy plants—such as solar farms or wind parks—it connects the central control system to high-voltage inverters and grid-tie transformers, enabling real-time monitoring of power output and grid synchronization. Its robust isolation is particularly valuable here, as inverters often generate electromagnetic noise that can disrupt standard communication links.
In power distribution networks, the WOODWARD 9907-1183 facilitates communication between SCADA systems and high-voltage switchgear, allowing operators to remotely monitor breaker status, trip signals, and load currents. This remote visibility reduces the need for on-site inspections, enhancing safety by minimizing exposure to high-voltage equipment.
In large manufacturing facilities with on-site power generation, the module connects the plant’s DCS to high-voltage generators and transformers, ensuring seamless coordination between production processes and power supply. Its ability to operate in extreme temperatures makes it suitable for steel mills, chemical plants, or refineries, where ambient conditions are often harsh.
9907-1183
Related products:
9907-838 – Multi-axis motion control module, ideal for integrating with 9907-1183 in facilities requiring both motion control and high-voltage communication.
9907-167 – Steam turbine governor, compatible with 9907-1183 for communication between turbine controls and high-voltage auxiliary systems.
9907-028/029 – Engine control modules, which can interface with 9907-1183 in hybrid power plants using both engines and high-voltage equipment.
9907-156 – Redundant control module, pairs with 9907-1183 to enhance system reliability in mission-critical communication paths.
8200-1310 (505 XT) – Steam turbine control upgrade, works with 9907-1183 for modernizing communication in legacy power systems.
9907-042 – Ethernet/IP adapter, extends 9907-1183’s connectivity options for facilities using Ethernet-based control networks.
9907-1201 – High-speed data logger, integrates with 9907-1183 to capture and analyze communication traffic between control and high-voltage systems.
Installation and maintenance:
Before installing the WOODWARD 9907-1183, verify that the control side power supply delivers a stable 24 V DC within the ±15% tolerance; voltage fluctuations can cause communication errors. Ensure the mounting location provides adequate airflow, as the module dissipates heat during operation—prolonged exposure to ambient temperatures above 65°C may reduce lifespan. Check that the high-voltage side wiring is properly insulated and rated for the system’s voltage (up to 36 kV), and confirm that communication cables are shielded and grounded to minimize noise pickup. It’s critical to validate protocol compatibility with both the control system and high-voltage equipment; Woodward provides a protocol compatibility matrix to streamline this process. Finally, ensure firmware on connected devices is up-to-date to support seamless integration with the9907-1183.
For ongoing maintenance, perform monthly checks of the module’s status LEDs: a steady green light indicates normal operation, while flashing amber signals a communication warning, and red denotes a critical fault requiring immediate attention via Woodward’s diagnostic software. Every six months, inspect electrical connections for corrosion or looseness, focusing on terminal blocks in humid or dusty environments. Test the redundant communication paths quarterly by temporarily disconnecting one port to confirm automatic failover—this ensures redundancy works when needed. Calibration of isolation barriers is recommended every two years, using Woodward’s specialized test equipment to verify continued compliance with safety standards. Finally, update the module’s firmware annually to access the latest security patches and protocol enhancements.
