WOODWARD 8440-2052 H Hydrogen Fuel Control Module

The WOODWARD 8440-2052 H operates as a specialized hydrogen fuel management center, integrating with hydrogen storage systems, pressure regulators, and engine control units. It continuously monitors hydrogen pressure, flow rates, and engine operating conditions to adjust fuel delivery with microsecond precision, ensuring optimal combustion efficiency while maintaining safe operating parameters. The module connects to central control systems via high-speed Ethernet/IP and RS-485 interfaces, enabling real-time data transmission and remote monitoring. What distinguishes the WOODWARD 8440-2052 H  is its advanced safety algorithm, which includes multiple layers of protection—such as rapid shutoff capabilities in case of pressure spikes or flameout detection—critical for handling hydrogen’s unique properties. It also features dual-redundant processing units to ensure uninterrupted operation, a key requirement for systems where downtime could have serious safety implications. By acting as the intelligent link between hydrogen supply and engine systems, the WOODWARD 8440-2052 H  simplifies the integration of hydrogen into industrial processes.

Model Number 8440-2052 H
Brand Woodward
Type Hydrogen Fuel Control Module
Input Voltage 24V DC ±15%
Operating Temp Range -40°C to +80°C
Mounting Style DIN Rail / Panel Mount with Isolation
Dimensions 170mm x 115mm x 90mm
Weight 1.3kg
Interface/Bus RS-485, Ethernet/IP, Modbus TCP
Compliance CE, RoHS, IECEx, ATEX, UL 60950
Supported Protocols Modbus RTU/TCP, PROFINET, OPC UA
Typical Power Draw 9W



Get a Quote
Categories: , , , , , Brand:

Description

The WOODWARD 8440-2052 H operates as a specialized hydrogen fuel management center, integrating with hydrogen storage systems, pressure regulators, and engine control units. It continuously monitors hydrogen pressure, flow rates, and engine operating conditions to adjust fuel delivery with microsecond precision, ensuring optimal combustion efficiency while maintaining safe operating parameters. The module connects to central control systems via high-speed Ethernet/IP and RS-485 interfaces, enabling real-time data transmission and remote monitoring. What distinguishes the WOODWARD 8440-2052 H  is its advanced safety algorithm, which includes multiple layers of protection—such as rapid shutoff capabilities in case of pressure spikes or flameout detection—critical for handling hydrogen’s unique properties. It also features dual-redundant processing units to ensure uninterrupted operation, a key requirement for systems where downtime could have serious safety implications. By acting as the intelligent link between hydrogen supply and engine systems, the WOODWARD 8440-2052 H  simplifies the integration of hydrogen into industrial processes.

8440-2052 H

8440-2052 H

Technical specifications:
Model Number 8440-2052 H
Brand Woodward
Type Hydrogen Fuel Control Module
Input Voltage 24V DC ±15%
Operating Temp Range -40°C to +80°C
Mounting Style DIN Rail / Panel Mount with Isolation
Dimensions 170mm x 115mm x 90mm
Weight 1.3kg
Interface/Bus RS-485, Ethernet/IP, Modbus TCP
Compliance CE, RoHS, IECEx, ATEX, UL 60950
Supported Protocols Modbus RTU/TCP, PROFINET, OPC UA
Typical Power Draw 9W





Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

8440-2052 H

8440-2052 H

Main features and advantages:

Engineered for the unique demands of hydrogen fuel systems, the WOODWARD8440-2052 H offers significant real-world advantages. Its precise fuel metering capabilities reduce hydrogen waste by up to 15% compared to generic fuel control systems, as it optimizes delivery to match engine load exactly—lowering operational costs and maximizing the efficiency of this valuable fuel source. The module’s built-in safety features, including redundant shutoff valves and continuous leak monitoring, minimize the risk of accidents, reducing liability and ensuring compliance with strict hydrogen safety standards.​
Maintenance teams benefit from the module’s comprehensive diagnostic suite, which provides real-time alerts for potential issues such as pressure regulator drift or sensor calibration errors. This proactive monitoring reduces unplanned downtime by allowing technicians to address problems before they escalate. Additionally, the WOODWARD 8440-2052 H’s design simplifies retrofitting into existing systems, enabling facilities to transition to hydrogen fuel without extensive overhauls of their control infrastructure, saving both time and capital investment.
8440-2052 H

8440-2052 H

Application areas:

The WOODWARD8440-2052 H is essential in industries pioneering hydrogen as a clean energy source. In power generation, it’s widely used in gas turbines and reciprocating engines that run on hydrogen or hydrogen-natural gas blends, ensuring stable operation and efficient power output. Its ATEX and IECEx certifications make it ideal for chemical processing plants, where hydrogen is used as a feedstock and fuel, requiring precise control to handle the gas’s high flammability.​
In industrial heating applications, such as metal processing furnaces, the WOODWARD8440-2052 H regulates hydrogen fuel delivery to maintain precise temperature control, critical for product quality. In each scenario, the module’s ability to handle hydrogen’s unique properties—including its wide flammability range and low ignition energy—ensures safe, reliable operation, making it a cornerstone of hydrogen-based industrial systems.
8440-2052 H

8440-2052 H

Related products:

WOODWARD 8440-2052 G – Dual-fuel module for hydrogen and natural gas blends​
WOODWARD 8440-2053 H – High-flow version for larger hydrogen engines and turbines​
WOODWARD 8440-2051 H – Basic hydrogen control module for less demanding applications​
WOODWARD 9907-422 – Hydrogen pressure sensor module that integrates with 8440-2052 H​
WOODWARD 505H – Speed control module optimized for use with 8440-2052 H in hydrogen engines​
WOODWARD 8272-3500 – Safety shutdown module compatible with 8440-2052 H for enhanced protection​
WOODWARD 8440-2054 H – Compact variant for space-constrained hydrogen systems
8440-2052 H

8440-2052 H

Installation and maintenance:

Before installing the WOODWARD 8440-2052 H, verify that the hydrogen supply system’s pressure rating matches the module’s 0-10 bar input range—exceeding this can damage internal components. Ensure the mounting surface is properly grounded to prevent static buildup, a critical safety measure with hydrogen systems. Check that the control system’s firmware supports OPC UA or PROFINET for seamless communication; older systems may require a protocol converter.​
For ongoing maintenance, conduct monthly inspections of all electrical connections to ensure they remain tight, as loose connections can generate sparks—a serious hazard with hydrogen. The module’s status LEDs should be checked weekly: a steady green light indicates normal operation, while a flashing red light signals a safety interlock activation requiring immediate attention. Calibrate the flow sensors annually using Woodward’s hydrogen-specific calibration tool, and update the module’s firmware during scheduled shutdowns to access the latest safety algorithms. In outdoor installations, inspect the module’s enclosure quarterly for signs of corrosion, which can compromise its integrity.
