WOODWARD 8440-1849 D Advanced control module

Description

WOODWARD 8440-1849 D is an advanced control module that plays a crucial role as a core hub in coordinating and optimizing industrial processes. It can establish stable connections with a wide variety of on-site devices, sensors, and actuators, collect real-time data with extraordinary accuracy, and output extremely precise control signals. From a design perspective, this module fully considers seamless integration with existing control platforms and backplane systems, making it easy to embed. It supports a range of widely used industry standard communication protocols, such as Modbus, Profibus, and EtherNet/IP, effectively ensuring smooth and efficient data transmission between system components. With advanced self diagnostic capabilities, engineers can quickly locate and solve potential problems, greatly reducing the high losses caused by system downtime. In addition, its redundant function options further enhance the system’s fault resistance, ensuring continuous and stable operation even in the event of individual component failures.

8440-1849 D

Technical specifications:
Model 8440-1849 D
Brand WOODWARD
Advanced Control Module Type
The input voltage is 24 VDC (± 10%), which can adapt to a certain range of voltage fluctuations
Working temperature range -40 ° C to 85 ° C, with excellent environmental adaptability, capable of stable operation in harsh industrial environments
The installation method adopts DIN rail installation, which is convenient and fast, and conforms to standardized installation specifications
The dimensions are 215mm in length, 150mm in width, and 95mm in height, with a compact design that saves space
Weight 1.4kg, easy to install and transport
The interface/bus is equipped with Ethernet interface for high-speed data transmission, and RS-485 interface for reliable serial communication
Certified by CE and RoHS, strictly following international safety and environmental standards
Supports Modbus TCP/RTU protocol, suitable for diverse industrial network communication; Profibus DP， Ensure efficient data exchange in distributed systems; EtherNet/IP， Realize seamless integration in industrial Ethernet environment
Typical power consumption of 14W, maintaining a reasonable level of energy consumption while ensuring high performance

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

8440-1849 D

Main features and advantages:

Choosing WOODWARD 8440-1849 D can bring numerous significant advantages to practical industrial applications. Its core design combines excellent durability and high performance, allowing for long-term stable operation in extremely harsh industrial environments, reducing equipment replacement and maintenance frequency. The high-speed data processing capability enables real-time monitoring and precise control of industrial processes. Faced with complex and changing working conditions, it can quickly make adjustments and optimize system operating efficiency. The intuitive and easy to understand diagnostic features greatly shorten the troubleshooting time and effectively reduce engineering maintenance costs. Thanks to its flexible integration design, this module can easily adapt to both newly built systems and existing complex systems, perfectly meeting the ever-changing operational needs of modern industry. The ultimate goal is to achieve a significant increase in productivity, a significant reduction in energy consumption, and a qualitative leap in overall system stability.

8440-1849 D

Application areas:

WOODWARD 8440-1849 D has extensive and in-depth applications in many industries. In the field of energy, whether it is thermal power generation, hydropower generation or wind power generation, it can accurately adjust the speed, voltage and power output of the generator, ensure the stability of the power generation process, and ensure reliable connection with the power grid. During peak electricity consumption periods or sudden load changes, 8440-1849 Dcan quickly respond, accurately adjust generator parameters, and maintain stable operation of the power grid. In the chemical industry, this module can be used to manage complex chemical reaction processes, accurately control key parameters such as raw material flow rate, reaction temperature, and pressure, thereby ensuring product quality consistency and production process safety. In the automotive manufacturing industry, WOODWARD 8440-1849 D is responsible for monitoring highly automated assembly lines,

8440-1849 D

Related products:

WOODWARD 8440-1851 D: An advanced version with superior performance, further enhancing data processing capabilities and expanding memory capacity, suitable for large-scale, highly complex automation projects, and able to easily meet the needs of high data transmission and processing. ​
WOODWARD 8340-1600 D: This model features a unique input/output configuration, specifically designed for systems with specific requirements for device connectivity and functionality, providing a more targeted solution. ​
WOODWARD 8440-1849 DA: This variant integrates advanced network security features, providing an additional layer of security protection for industrial network environments, effectively resisting potential network threats, and ensuring system data security. ​
WOODWARD 8440-1849 DR: Emphasis has been placed on strengthening the redundancy design of power and communication channels, specifically designed for critical task application scenarios that do not allow system failures to occur, ensuring that the system can continue to operate stably in any situation. ​
WOODWARD 8440-1849 DE: As an extension module, it can be added to existing system architectures, significantly increasing the available I/O points and greatly enhancing the scalability and flexibility of the system, meeting the needs of future business expansion and system upgrades for enterprises. ​
WOODWARD 8440-1849 DH: Specially designed for high-temperature industrial environments, it has stronger high-temperature resistance and can work stably in high-temperature environments such as industrial furnaces and power plants in desert areas. ​
WOODWARD 8440-1849 DL: A low-power model developed to meet energy-saving needs, especially suitable for off grid power generation systems or remote areas with limited power resources that are sensitive to energy consumption.

8440-1849 D

Installation and maintenance:

Before installing WOODWARD 8440-1849 D, it is essential to carefully verify its compatibility with the existing control system. Thoroughly inspect whether the communication protocol matches, whether the power supply requirements can be met, and whether the physical dimensions are appropriate to ensure a smooth installation process. At the same time, it is necessary to confirm that the firmware of both the module and the host system is the latest version to avoid compatibility issues caused by outdated firmware.

In the subsequent maintenance work, it is necessary to closely monitor the status indicator lights of the module on a regular basis in order to detect potential fault signs in a timely manner. Regularly inspect connectors and cables to ensure the stability of signal transmission, and pay attention to any signs of wear, corrosion, or damage. By regularly conducting calibration and performance testing, the high precision and optimal operating state of the module are maintained, providing a solid guarantee for the continuous and reliable operation of industrial automation or power control systems.
