WOODWARD 8440-1713 synchronizer

Description

Woodward 8440-1713/D is an advanced microprocessor based synchronizer designed specifically for single-phase or three-phase AC generators. Its core function is like an alert guardian, continuously monitoring and adjusting key electrical parameters to ensure that the generator can safely and efficiently synchronize with the grid or other power sources.

8440-1713

By automatically matching the frequency, phase, and voltage of the generator output with the target power system, it can achieve a smooth and seamless connection, minimizing the risk of electrical transients and equipment stress. This not only improves the overall reliability of power supply, but also helps optimize the performance of generators, thereby improving fuel efficiency and reducing wear and tear.

8440-1713

Main features and advantages:
It can easily integrate with other key elements such as generator control units, power management systems, and monitoring platforms. The synchronizer is equipped with industry standard communication interfaces, which can exchange real-time data with various devices, enabling collaborative operation and centralized control. Its user-friendly software interface simplifies the configuration and setup process, allowing engineers to customize synchronizer settings according to the specific requirements of different applications. In addition, the module is designed to be highly reliable and capable of withstanding the harsh conditions commonly found in industrial environments, including electrical noise, temperature changes, and mechanical vibrations.

Directly translated into improved operational efficiency and cost savings. Its high-precision synchronization capability ensures that the generator operates at its optimal level, reducing fuel consumption and maintenance requirements over time. By reducing the risk of electrical interference during the synchronization process, it helps to extend the lifespan of expensive generator equipment and further reduce replacement and maintenance costs. The seamless integration of this module with existing systems simplifies the implementation process, reduces engineering costs, and shortens deployment time. In addition, its reliable performance in harsh industrial environments is reassuring, ensuring stable power synchronization even under challenging conditions.

8440-1713

Technical specifications:
Model 8440-1713/D
Brand Woodward
Type: Synchronizer based on microprocessor
Input voltage 100-240 VAC, 50/60 Hz
Working temperature range -25 ° C to+70 ° C
Installation method: DIN rail installation or panel installation
Dimensions 125mm x 90mm x 45mm
Weight 0.7 kg
Communication interface RS-485, Ethernet (Modbus RTU/TCP)
Synchronization accuracy frequency: ± 0.01 Hz, phase: ± 1 °, voltage: ± 1%
Certified CE, UL, RoHS
Power consumption 10 W (typical value)

Contact Us
Phone:+86 16626708626
WhatsApp/WeChat:+86 16626708626
Email: 3772179818@qq.com

8440-1713

Application areas:
In the field of power generation, it is the mainstream equipment of traditional power plants, which can achieve efficient parallel operation of multiple generators; In distributed energy resources such as solar power plants and wind power plants, it ensures that the generated electricity can be smoothly integrated into the grid.
In manufacturing plants, it plays a crucial role in maintaining stable power supply for sensitive production equipment, preventing production interruptions caused by power fluctuations. In the shipbuilding industry, it is used to synchronize the generators on board, providing reliable power for onboard operations from propulsion systems to communication equipment.

Related products:
Woodward 8440-1714: With stronger processing capabilities and additional synchronization algorithms, it is suitable for more complex power systems with higher speed generators or greater load changes.
Woodward 8440-1712: The feature set is relatively basic and may be suitable for applications with relatively simple synchronization requirements and low demand.
Woodward 8440-1713/D-HAZ: Designed for use in hazardous environments, this variant has a higher safety rating and explosion-proof structure, ensuring reliable operation in potentially explosive environments such as oil and gas refineries.
Woodward 8440-1713/D-Lite: Retains core synchronization functionality, making it an attractive choice for budget limited projects or applications that do not require all the features of the standard model.
Woodward 8440-1713/D – Pro: This version provides advanced diagnostic and monitoring capabilities for proactive maintenance and real-time system health assessment. It can provide detailed insights into the synchronization process, enabling operators to identify and resolve potential issues before they escalate.

Installation and maintenance:
Before installing Woodward 8440-1713/D it is necessary to carefully review and verify its input voltage compatibility with the existing power supply infrastructure. Ensure that the voltage is within the specified range of 100-240 VAC and the frequency is 50 or 60 Hz. Check the compatibility of the communication interface with other devices in the system, such as sensors, actuators, and control units, to ensure seamless data transmission. In addition, confirm that the software used for configuration and monitoring is the latest version and has been properly authorized.

For daily maintenance, the status indicator lights of the module should be checked regularly to quickly detect any abnormal situations. Regularly check the connection to ensure it is secure and free from corrosion or damage. Conduct routine performance testing, such as simulating different synchronization scenarios and evaluating module response time and accuracy, to ensure that it continues to operate at optimal efficiency and reliability.
