The Woodward 8440-1706 B is a digital synchronizer and governor control module designed for precise generator set control, load sharing, and power factor management. It is widely utilized in power generation, industrial plants, and large commercial facilities where controlling multiple standby or parallel generators with high reliability and accuracy is critical. The 8440-1706 B addresses common challenges such as synchronizing circuit breakers, regulating power factors, performing load sharing, and providing comprehensive generator protection, making it highly applicable in advanced control systems requiring robust parallel generation control.
- 8440-1706 B.
The 8440-1706 B combines synchronizing functionality for one circuit breaker with load and power factor control or isochronous load sharing, supporting seamless operation between multiple gensets or paralleling with the mains. It offers configurable start/stop sequencing, slip frequency and phase matching synchronization for breaker control, and precise real power and reactive power regulation. This controller supports asynchronous (induction) generator operation and offers flexible load dependent start/stop logic to optimize fuel efficiency and system stability. The device is designed to interface with engine control units (ECUs) and auxiliary equipment to provide full system coordination.
Technically, the Woodward 8440-1706 B module measures roughly 144 x 72 x 122 mm and weighs about 800 grams. It includes a two-line LCD display for diagnostics and alarm management, offering users clear system status and fault indications. Operating temperature ranges from -40°C to +70°C allow use in harsh industrial environments. It supports configurable isolated digital inputs and outputs and incorporates programmable protection functions and control logics for versatile installation. Power consumption is optimized for typical 12/24 V DC power systems. Communication options cater to integration within larger control architectures needing responsive and reliable generator synchronization and load sharing.
| Parameter | Value |
|---|---|
| Model | 8440-1706 B |
| Brand | Woodward |
| Product Type | Synchronizer and Governor Control Module |
| Dimensions (HxWxD) | 144 x 72 x 122 mm |
| Weight | Approx. 800 g (1.76 lbs) |
| Operating Temperature | -40°C to +70°C |
| Power Supply | 12/24 V DC |
| Display | Two-line LCD |
| Synchronization Features | Slip frequency phase matching, breaker control |
| Load Sharing | Isochronous and droop load sharing |
| Protection Functions | Generator and load protection |
| Application | Generator paralleling, power factor/load control |
| Mounting | Control panel or rack mount compatible |
Related Woodward products include the 8440-1705 (similar controller with extended I/O configurations), 8440-1707 (advanced load and power regulation), and other members of the SPM-D11 series such as the 8440-1706 LSXR variant designed for specific measurement and load sharing enhancements. These modules allow modular expansions and tailored control schemes for complex power generation and distribution systems.
Installation requires compatibility with Woodward panel or rack systems, precise wiring of inputs/outputs, and adherence to grounding and shielding best practices to ensure reliable synchronization and signal integrity. The compact design facilitates integration into existing control architectures while the front display aids local user interaction.
Maintenance involves regular status checks via the display, verification of alarms and diagnostics, and firmware updates when available. Keeping connection terminals secure and clean ensures signal quality and system safety. Woodward’s technical support and documentation provide valuable resources for troubleshooting and optimizing performance.
