Woodward 8200-226 High Performance Electronic Governor Control Module

Description

Woodward 8200-226 is a high-performance electronic governor control module.

8200-226

It serves as the nerve center for engine speed and load control, connected to various sensors for monitoring key parameters of the engine, such as speed, throttle position, and fuel flow. By continuously analyzing the real-time data transmitted by these sensors, the module is able to accurately adjust the engine’s fuel injection system and throttle settings to maintain stable RPM and optimal load distribution. In industrial automation systems, it seamlessly integrates with engine control units, power management systems, and other critical components. Woodward8200-226 supports industry standard communication protocols such as CAN and Modbus, enabling smooth data exchange and collaborative operation with other devices in the system. It is also equipped with built-in diagnostic functions, allowing engineers to quickly identify and troubleshoot faults, thereby reducing downtime and improving the overall reliability of the engine and power generation system.

8200-226

Technical specifications:
Model 8200-226
Brand Woodward
Type: Electronic Governor Control Module
Input voltage 18-36 VDC
Working temperature range -40 ° C to+85 ° C
Installation method: DIN rail installation
Size 130mm x 90mm x 50mm
Weight 1.0 kg
Interface/Bus CAN, RS-485
Certification CE, RoHS
Supports protocols J1939 and Modbus RTU
Typical power consumption 7 W

Contact Us
Phone:+86 16626708626
WhatsApp/WeChat:+86 16626708626
Email: 3772179818@qq.com

8200-226

Main features and advantages:
This module has been carefully designed to be durable and reliable, capable of withstanding harsh conditions in industrial environments and ensuring long-term stable operation. Its precise control over engine speed and load distribution helps to significantly save fuel consumption over time, directly reducing operating costs. By keeping the engine in optimal operating condition, it extends the service life of engine components, reduces the frequency of maintenance and replacement, and thus lowers maintenance costs. The rapid response of this module to changes in load demand ensures stable power output, which is crucial for maintaining the integrity of industrial processes and preventing interruptions. In addition, its user-friendly software based configuration system reduces engineering costs, allowing engineers to easily customize module settings to adapt to different engine types and operating scenarios without the need for complex hardware modifications.

Application areas:
In the power generation industry, it is deployed in diesel and gas generators to optimize power output and ensure stable power supply for both grid connected and off grid applications. For example, in remote areas that rely on backup generators for power supply, Woodward 8200-226 can ensure stable operation even in the event of sudden load changes.
In the shipbuilding industry, it plays a crucial role in controlling ship engines, enabling smooth navigation and efficient operation even in rough seas and harsh weather conditions. It helps maintain the engine speed and power, ensuring safe and reliable navigation of the ship.
In the oil and gas industry, it is used to manage the engines of pumps, compressors, and other critical equipment, ensuring continuous safe operation in harsh remote locations with extreme temperatures, high pressures, and corrosive environments.

Installation and maintenance:
Woodward 8200-227: Faster processing speed, increased input/output channels, suitable for more complex control requirements.
Woodward 8200-225: Equipped with a basic feature set, suitable for engine control tasks with lower requirements.
Woodward 8200-226H: Designed specifically for hazardous environments, with higher safety levels and explosion-proof structures.
Woodward 8200-226 Lite: retains core control functions, making it ideal for entry-level engine control applications.
Woodward 8200-226 Pro: Provides advanced predictive diagnostic capabilities for proactive maintenance and more comprehensive system monitoring.

Installation and maintenance:
Before installing Woodward 8200-226, it is essential to verify the compatibility of its input voltage with the existing power system, ensuring that the voltage remains within the range of 18-36 VDC. Check the communication bus compatibility with other devices in the system, including sensors, actuators, and control units, to ensure seamless data transmission. In addition, ensure that the software used for configuration and monitoring is the latest version and properly authorized.

For daily maintenance, the status indicator lights of the module should be checked regularly to quickly detect any abnormal situations. Regularly check the connection of the module to ensure that it is secure and free from corrosion or damage. Conducting routine performance testing, such as simulating sudden load changes and evaluating module response, helps ensure that it continues to operate at optimal efficiency and reliability.
