WOODWARD 8200-1302 Electronic governor control module

Description

Woodward 8200-1302 is a cutting-edge electronic speed control module.

8200-1302

As a central control hub, it is connected to a wide network of sensors that monitor key parameters of the engine, including speed, torque, fuel flow, and exhaust temperature. By continuously analyzing the real-time data provided by these sensors, the module is able to immediately and accurately adjust the engine’s fuel injection system and throttle mechanism. This precise control not only stabilizes the engine speed, but also optimizes the load distribution among multiple engines in the system, ensuring harmonious and efficient operation. In the industrial automation ecosystem, the Woodward 8200-1302 is easily integrated with other key components such as engine control units, power management systems, and monitoring platforms. It supports industry standard communication protocols such as CAN and Modbus, enabling seamless data exchange and collaborative operation with the entire system. In addition, the module has advanced diagnostic capabilities that enable engineers to quickly identify and resolve any potential issues, minimizing downtime and improving the overall reliability and availability of power generation and engine drive systems.

8200-1302

Technical specifications:
Model 8200-1302
Brand Woodward
Type: Electronic Governor Control Module
Input voltage 18-36 VDC
Working temperature range -40 ° C to+85 ° C
Installation method: DIN rail installation
Dimensions 135mm x 95mm x 55mm
Weight 1.2 kg
Interface/Bus CAN, RS-485
Certification CE, RoHS
Supports protocols J1939 and Modbus RTU
Typical power consumption 8 W

Contact Us
Phone:+86 16626708626
WhatsApp/WeChat:+86 16626708626
Email: 3772179818@qq.com

8200-1302

Main features and advantages:
Directly translated into improved operational efficiency and cost savings. This module has been carefully designed to withstand the harshest industrial environments and ensure long-term stable performance. Its precise control over engine speed and load distribution can bring significant fuel savings over time, significantly reducing operating costs related to power generation and engine operation. By keeping the engine in optimal operating condition, it extends the service life of engine components, reduces the frequency of maintenance and replacement, and further lowers maintenance costs. The fast and accurate response of this module to changes in load demand ensures stable and consistent power output, which is crucial for maintaining the integrity of industrial processes and preventing costly interruptions. In addition, its intuitive software based configuration system simplifies the engineering process, allowing engineers to easily customize module settings to adapt to different engine types and operating scenarios without the need for complex and time-consuming hardware modifications.

8200-1302

Application areas:
In the power generation industry, it is used in diesel and gas generators to optimize power output and ensure reliable power supply, whether in grid connected power plants or off grid backup systems. In remote rural areas where generators are the primary power source, Woodward 8200-1302 ensures stable operation even in the event of sudden surges in demand.
In the shipbuilding industry, it plays a crucial role in controlling ship engines, enabling ships to navigate smoothly and operate efficiently in various sea conditions, from calm waters to rough seas. It helps maintain the engine speed and power, ensuring safe and timely navigation of the vessel. In the oil and gas industry, it is used to manage the engines of pumps, compressors, and other critical equipment, ensuring continuous safe operation in harsh remote locations with extreme temperatures, high pressures, and corrosive atmospheres.

8200-1302

Related products:
Woodward 8200-1303: Equipped with enhanced processing capabilities and additional input/output channels, suitable for more complex and demanding control applications.
Woodward 8200-1301: Equipped with a more basic feature set, suitable for less complex engine control tasks.
Woodward 8200-1302H: Designed specifically for use in hazardous environments, with higher safety levels and explosion-proof structures.
Woodward 8200-1302 Lite: Retains core control functions, making it ideal for entry-level engine control requirements in budget limited applications.
Woodward 8200-1302 Pro: Provides advanced predictive diagnostic capabilities and enhanced monitoring capabilities for proactive maintenance and more comprehensive system supervision.

8200-1302

Installation and maintenance:
Before installing Woodward 8200-1302, it is necessary to thoroughly check the compatibility of its input voltage with the existing power system to ensure that the voltage remains within the specified range of 18-36 VDC. Verify communication bus compatibility with other devices in the system, including sensors, actuators, and control units, to ensure seamless and reliable data transmission. In addition, ensure that the software used for configuration and monitoring is the latest version and properly authorized.

For daily maintenance, the status indicator lights of the module should be checked regularly to detect any abnormal situations in a timely manner. Regularly check the connection status of the module to ensure that the connection is firm, corrosion-resistant, and in good working condition. Conducting routine performance testing, such as simulating sudden load changes and evaluating module response time and accuracy, helps ensure that it continues to operate at optimal efficiency and reliability in the long term.
