Woodward 5466-409 High Performance Electronic Control Module

Description

Woodward 5466-409 is a high-performance electronic control module designed to be the core of engine management systems.

5466-409

It is connected to multiple sensors to monitor key parameters of the engine, such as engine speed, torque, fuel pressure, and exhaust emissions. By continuously analyzing the real-time data transmitted by these sensors, the module is able to make precise adjustments to the engine’s fuel injection, ignition timing, and other key functions. This helps optimize engine performance, improve fuel efficiency, and reduce emissions. In industrial automation systems, Woodward 5466-409 can seamlessly integrate with other components such as engine control units, power management systems, and monitoring platforms. It supports industry standard communication protocols such as CAN and Modbus, enabling seamless data exchange and collaborative operation with other devices in the system. This module also has built-in diagnostic functions, allowing engineers to quickly identify and troubleshoot faults, thereby reducing downtime and improving the overall reliability of the system.

5466-409

Technical specifications:
Model 5466-409
Brand Woodward
Type Electronic Control Module
Input voltage 12-24 VDC
Working temperature range -40 ° C to+85 ° C
Installation method: DIN rail installation
Dimensions 120mm x 80mm x 40mm
Weight 0.8 kg
Interface/Bus CAN, RS-485
Certification CE, RoHS
Supports protocols J1939 and Modbus RTU
Typical power consumption 6 W

contact us
Phone:+86 16626708626
WhatsApp/WeChat:+86 16626708626
Email: 3772179818@qq.com

5466-409

Main features and advantages:
This module has been carefully designed to be durable and reliable, capable of withstanding harsh conditions in industrial environments and ensuring long-term stable operation. Its advanced control algorithm can achieve precise fuel metering, significantly saving fuel consumption over time and reducing overall operating costs. By keeping the engine in optimal operating condition, it extends the service life of engine components, reduces the frequency of maintenance and replacement, and thus lowers maintenance costs. The rapid response of this module to changes in load demand ensures stable power output, which is crucial for maintaining the integrity of industrial processes and preventing interruptions. In addition, its user-friendly software based configuration system reduces engineering costs, allowing engineers to easily customize module settings to adapt to different engine types and operating scenarios without the need for complex hardware modifications.

5466-409

Application areas:
In the power generation industry, it is used in diesel and gas generators to optimize power output and fuel efficiency, ensuring stable and reliable power supply for both grid connected and off grid applications. In the field of ships, it plays a crucial role in controlling ship engines, enabling smooth navigation and efficient operation even in turbulent seas and unpredictable weather conditions.
It is also widely used in the oil and gas industry to help manage the engines of pumps, compressors, and other critical equipment, ensuring continuous safe operation in harsh remote locations with extreme temperatures, high pressures, and corrosive environments.

Related products:
Woodward 5466-410: Faster processing speed, increased input/output channels, suitable for more complex control requirements.
Woodward 5466-408: equipped with a basic feature set, suitable for engine control tasks with lower requirements.
Woodward 5466-409H: Designed specifically for hazardous environments, with higher safety levels and explosion-proof structures.
Woodward 5466-409- Lite: an affordable model that retains core control functions, making it ideal for entry-level engine control applications.
Woodward 5466-409- Pro: Provides advanced predictive diagnostic capabilities for proactive maintenance and more comprehensive system monitoring.

Installation and maintenance:
Before installing Woodward 5466-409, it is essential to verify the compatibility of its input voltage with the existing power system, ensuring that the voltage remains within the range of 12-24 VDC. Check the communication bus compatibility with other devices in the system, including sensors, actuators, and control units, to ensure seamless data transmission. In addition, ensure that the software used for configuration and monitoring is the latest version and properly authorized.
For daily maintenance, the status indicator lights of the module should be checked regularly to quickly detect any abnormal situations. Regularly check the connection of the module to ensure that it is secure and free from corrosion or damage. Conducting routine performance testing, such as simulating sudden load changes and evaluating module response, helps ensure that it continues to operate at optimal efficiency and reliability.
