Woodward 2301E 8273-1011 is a microprocessor based digital control module that can interface with diesel or gas engines that drive generators.
2301E 8273-1011
In industrial automation systems, it is at a critical node position, responsible for collecting data from various sensors related to engine speed, load, and other parameters. For example, it can receive input from a speed sensor to monitor the engine’s rotational speed and adjust fuel supply or throttle settings accordingly to maintain a stable speed. At the same time, it will also interact with load sensors to manage the power load distribution among multiple generators. This module supports multiple control modes, including isochronous mode, droop mode, and base load mode, which allows it to adapt to different operational requirements. In addition, it also has two serial ports (RS-232 and RS-422) that enable communication with other devices in the system, such as external computers used for configuration and monitoring.
2301E 8273-1011
Main features and advantages:
This module is designed specifically for harsh industrial environments to ensure long-term stable operation. Its ability to precisely control engine speed can reduce wear on engine components, thereby lowering long-term maintenance costs. Its load distribution function can improve the efficiency of the power generation system. By evenly distributing the load between generators, any generator overload can be prevented, which not only extends the service life of the generators but also improves the overall reliability of power supply. Woodward 2301E 8273-1011 adopts software configuration to reduce engineering costs. Engineers can easily adjust settings to accommodate different engine types, speed ranges, and load requirements without the need for complex hardware modifications.
2301E 8273-1011
Technical specifications:
Model 2301E 8273-1011
Brand Woodward
Type: Digital Load Distribution and Speed Control Module
Input voltage 18-36 VDC
Working temperature range -40 ° C to+85 ° C
Interface/Bus RS-232, RS-422
Certification CE, UL
Contact Us
Phone:+86 16626708626
WhatsApp/WeChat:+86 16626708626
Email: 3772179818@qq.com
2301E 8273-1011
Application areas:
In the power generation industry, especially in off grid power plants that rely on diesel or gas generators, it plays a crucial role in maintaining stable power output.
In remote mining operations that require on-site power generation, Woodward 2301E 8273-1011 ensures that generators work together to provide continuous power to mining equipment.
In the shipbuilding industry, for ships that use diesel engines to drive generators, this module is used to control engine speed, which is crucial for maintaining the normal operation of critical systems and ensuring smooth operation of onboard systems. It can also be found in large manufacturing plants, where reliable electricity is crucial for continuous production processes.
2301E 8273-1011
Related products:
Woodward 2301A: equipped with basic load distribution and speed control functions, suitable for simpler application scenarios.
Woodward 2301D: backward compatible with 2301E, but with a relatively limited feature set.
Woodward 2301E – HAZ: Designed specifically for hazardous locations with enhanced safety features.
Woodward 2301E – High Density: Higher channel density, suitable for applications that require more inputs and outputs for comprehensive control.
Woodward 2301E – Pro, equipped with advanced diagnostic features for deeper system monitoring.
Installation and maintenance:
Before installing Woodward 2301E 8273-1011, it is essential to check the compatibility of its input voltage with the existing power system to ensure that the voltage is within the range of 18-36 VDC. At the same time, verify the compatibility between the communication ports (RS-232 and RS-422) and the connected devices (such as external computers used for configuration). Check if the software used for configuration (Servlink/Watch Windows or Control Assistant) is the latest version.
For daily maintenance, it is necessary to regularly check the status indicator lights on the module, which can indicate power issues or communication failures. Regularly check the connection of the module to ensure it is secure and free from corrosion. It is also a good practice to conduct functional testing at least once a year to verify the proper functioning of load distribution and speed control functions.
