UR8LH Universal Relay I/O & Control Module

Description

UR8LH

The GE UR8LH functions as a modular I/O and control relay within GE’s Universal Relay series, serving as a critical link between field devices (such as current transformers, voltage transformers, and circuit breakers) and central SCADA or control systems. Positioned in the middle of the power system automation stack, it connects to GE’s UR-series controllers (like the UR6AE or UR8AE) via a dedicated backplane, enabling real-time data exchange and coordinated protection actions.

UR8LH

Unlike standalone relays that require complex programming or third-party adapters, the GE UR8LH leverages GE’s EnerVista software suite for configuration, allowing engineers to set up protection logic, I/O mapping, and diagnostic parameters in a user-friendly interface. It supports redundancy for mission-critical applications—such as substation bus protection—ensuring that if a primary module experiences a fault, a backup GE UR8LH takes over without interrupting protection functions. The module also includes advanced diagnostics, such as self-monitoring for hardware failures and communication status checks, which alert operators to issues before they impact system performance. By fitting seamlessly into GE’s UR ecosystem, the GE UR8LH simplifies integration while enhancing the overall resilience of power protection systems.

UR8LH

Main features and advantages:

Choosing the GE UR8LH delivers tangible, long-term value for power system engineers tasked with maintaining reliable operations. Engineered for the harsh conditions of substations and industrial power networks, its wide operating temperature range and rugged enclosure (rated for dust and humidity resistance) ensure consistent performance in environments where extreme weather or electrical noise could disrupt lesser relays. This durability translates to reduced replacement costs and unplanned downtime—critical for networks where even a 10-minute outage can result in significant financial losses.

Integration ease is another key benefit: as part of GE’s UR series, the GE UR8LH works seamlessly with existing UR controllers, EnerVista software, and SCADA systems. This compatibility eliminates the need for custom programming or proprietary adapters, reducing engineering time and minimizing the risk of integration errors. The module’s flexible I/O configuration—supporting both analog and digital signals—also allows it to adapt to diverse protection needs, from monitoring transformer temperatures to controlling circuit breakers. For engineers focused on grid modernization, the GE UR8LH’s support for IEC 61850 (the global standard for substation automation) ensures future-proofing, enabling easy integration with smart grid technologies as networks evolve.

UR8LH

Application fields:

The GE UR8LH is deployed across industries where reliable power protection is non-negotiable, starting with electric utilities. In high-voltage substations, it’s used to monitor transmission line currents and voltages, enabling fast fault detection (within milliseconds) to isolate faulty sections and prevent cascading outages—critical for maintaining grid stability in urban or remote areas. In industrial settings, such as oil refineries or manufacturing plants, the GE UR8LH protects critical equipment like motors, transformers, and generators by detecting overcurrents, voltage sags, or phase imbalances, ensuring that costly machinery is not damaged and production remains uninterrupted.

It’s also a staple in renewable energy facilities, such as wind farms or solar parks, where it integrates with inverter systems to protect against grid faults and ensure compliance with utility interconnection standards. In all these use cases, the GE UR8LH excels in environments requiring continuous uptime and fast response times—its support for GOOSE messaging (via IEC 61850) enables near-instantaneous communication between relays, a must for protecting large-scale power systems. Whether in a utility substation, industrial plant, or renewable energy facility, the GE UR8LH delivers the reliability and flexibility needed for critical power system protection.

UR8LH

Related products:

GE UR8AE – Full-featured universal relay controller, ideal for pairing with the UR8LH for complete substation protection.

GE UR6LH – Compact version of the UR8LH with reduced I/O count, designed for space-constrained applications like small substations.

GE UR8LH-B – Enhanced UR8LH model with built-in battery backup for uninterrupted operation during power sags.

GE UR8LH-S – SIL 3-certified variant of the UR8LH, suitable for safety-critical applications like nuclear power plant auxiliary systems.

GE UR8LH-C – Communication-focused version with additional Ethernet ports for integrating with multiple SCADA systems.

GE UR7LH – Legacy UR-series module, compatible with the UR8LH for gradual system upgrades from older GE relay platforms.

GE UR8LH-F – Fan-cooled model of the UR8LH, optimized for high-temperature environments (up to +75 °C) like desert substations.

GE UR8LH-I – Isolated I/O version of the UR8LH, designed for environments with high electrical interference (e.g., near large motors or arc furnaces).

Installation and maintenance:

Before installing the GE UR8LH, verify compatibility with your existing GE UR controller firmware—ensure the controller runs version V4.0 or higher to support all the module’s advanced features, such as IEC 61850 GOOSE messaging. Check the mounting location for adequate clearance: the module requires at least 50 mm of space on all sides for airflow, as overheating can degrade performance. Inspect the input power supply to confirm it falls within the 85–265 V AC / 85–300 V DC range; unstable power can cause false fault alarms or module lockups. Additionally, pre-configure the module’s I/O settings in EnerVista software before installation—this reduces on-site setup time and ensures alignment with your system’s protection logic.

Ongoing maintenance for the GE UR8LH is focused on proactive monitoring: monthly, review the module’s front-panel LED status (green for normal operation, amber for warnings, red for faults) and check communication logs in EnerVista to identify potential issues like dropped Modbus connections. Every six months, inspect the module’s wiring terminals for corrosion or loose connections—especially in humid or coastal environments—and tighten them to the recommended torque (0.8 Nm for signal wires, 1.2 Nm for power wires). Once a year, perform a full functional test: inject test signals (e.g., simulated overcurrents) into the module and verify that it triggers the correct protection actions (such as tripping a circuit breaker) and communicates the fault to the SCADA system. This routine ensures the GE UR8LH remains reliable and ready to respond to real-world faults.
