T9851 Multifunctional module

Description

T9851 is a multifunctional module with different configuration versions including digital output and analog output. It is a product of a well-known manufacturer in the field of industrial automation, and ICS Triplex is one of them. This module aims to become an indispensable part of industrial control systems, bridging the gap between central control units and field devices.

T9851

In industrial control architecture, if it is an analog output typeT9851 , it will receive digital signals from the central processing unit (CPU) of the control system. Then, these digital signals are converted into precise analog signals for driving various actuators such as frequency converters, proportional valves, and motor controllers. For the T9851 digital output type, it directly sends digital signals to control devices such as relays, solenoid valves, and digital motors.

For engineers and system integrators, T9851 has significant advantages. Its modular design facilitates integration into existing control systems, whether based on programmable logic controllers (PLCs), distributed control systems (DCS), or more advanced industrial control networks. It provides flexibility in terms of channel quantity, output type, and communication protocol, suitable for various industrial applications ranging from small manufacturing units to large industrial complexes.

T9851

Main features and advantages:
Taking theT9851 analog output module as an example, it usually has high-resolution output. The resolution reaches 0.1% ± 1 count, which can generate extremely accurate analog signals. This high resolution is very beneficial in applications where process parameters are finely adjusted, such as the high-precision manufacturing of pharmaceutical manufacturing or electronic components mentioned above.

In terms of output capacity, it usually has multiple channels. Some versions may have 8 or 16 channels. For example, the 16 channel version can simultaneously control 16 different actuators. This is very useful in complex industrial processes that require independent control of numerous devices. In a large manufacturing plant with multiple conveyor belts, robotic arms, and other equipment, each device needs to be individually controlled, and the 16 channel T9851can efficiently manage all of these outputs.

T9851 also supports multiple output ranges. It can provide outputs of 0-10V or 4-20mA, which are common industry standards. This flexibility enables it to interface with various devices. For example, in building automation systems, it can use 0-10V output to control the frequency converter to regulate the speed of ventilation fans, or use 4-20mA signal to control the opening of control valves.

In terms of communication, T9851 typically supports industry standard protocols such as Modbus RTU. This enables it to seamlessly integrate with other devices in the control system. It can easily communicate with PLC or SCADA systems for remote monitoring and control. In the power distribution network, T9851 can send status data of circuit breakers and other electrical equipment to the SCADA system located in the central control room, enabling operators to manage the network more effectively.

The design of this module also has robustness and reliability. It can operate within a wide temperature range of -20 ° C to+60 ° C. This makes it suitable for various environments ranging from refrigeration facilities to high-temperature industrial processing zones. In addition, it usually has the ability to resist vibration and electromagnetic interference, which is common in industrial environments. This anti-interference capability helps ensure the integrity of the output signal, preventing any interference that may affect the operation of connected devices and ultimately impact industrial processes.

T9851

Technical specifications:
Model T9851
Brand ICS Triplex
Type multifunctional module
Analog output of power supply: The working voltage can be 24V DC; Digital output: Supports 24V DC
Working temperature -20 ° C to+60 ° C
Storage temperature -40 ° C to+85 ° C
The installation method is usually designed to facilitate installation in the control cabinet, using standard installation mechanisms
Compact size 120 x 80 x 40mm
Lightweight, about 300 grams
Output channel analog output: There may be 8 or 16 channels
Digital output: 8-channel version is more common
Output type analog output: continuous analog signal, optional 0-10V, 4-20mA, etc; Digital output: a digital signal used to drive relays, solenoid valves, etc
Current capacity analog output: Depending on the model and application requirements, it can be 3A or higher; Digital output: Each channel may have a specific current carrying capacity, such as 0.75A per channel
Output resolution (analog) 0.1% ± 1 count
Communication protocols typically support Modbus RTU, but may also support other protocols depending on the model
Certification complies with industry standards such as CE, UL, CSA to ensure safety and quality
The environmental level has the ability to resist vibration and electromagnetic interference, suitable for industrial environments

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

T9851

Application areas:
T9851 plays a crucial role in the oil and gas industry, which demands extremely high reliability and precision. Taking offshore oil drilling platforms as an example, T9851 is usually used as an analog output module, responsible for controlling the opening and closing of key valves in oil extraction and processing systems. These valves are used to regulate the flow of crude oil, natural gas, and various chemicals. By sending precise analog signals, T9851 ensures that pressure and flow remain within optimal ranges. This is crucial for preventing leaks, as leaks can cause catastrophic environmental and economic losses. In addition, it also controls the speed of the pumps that transport the extracted resources to storage facilities or transport vessels. The ability of this module to finely control these mechanical components is crucial for the smooth and safe operation of the entire drilling platform.

In the field of pharmaceutical manufacturing, strict quality control and precise process control are essential, and T9851 has been widely used. In pharmaceutical production factories, it controls the amount of raw materials used in the mixing process. For example, when formulating liquid drugs, T9851 can precisely regulate the flow rate of different chemical compounds into the mixing tank. It ensures that each batch of drugs has the correct ingredients and meets the strict quality standards set by regulatory agencies. This module also controls the temperature and stirring speed during the mixing process, which play a critical role in the chemical reactions that occur during drug synthesis. Any deviation from these parameters may result in substandard or ineffective drug quality.

Related products:
T9801 and T9802-T9801 are digital input modules, while T9802 is a digital output module. Together with T9851, they can form a comprehensive input-output solution in industrial control systems. T9801 can collect digital signals from sensors, T9851 can provide analog or digital outputs for control, and T9802 can send digital control signals to actuators.
AADvance CPU module XYZ – This is the central processing unit of the control system, which communicates with T9851. It sends control commands to T9851 based on the data received from the input module and the executed control algorithm. Then, T9851 drives the corresponding devices based on these commands.
Analog input module ABC – Although T9851 may be an output oriented module, the analog input module is used to interface with sensors that provide analog signals. In a complete control system, the analog input module can provide data feedback to the control system, and then the control system can use T9851 to send control signals based on these input data.
Communication module DEF – facilitates communication between T9851 and other components in the control system with external devices or other control systems. It can transmit data through different protocols (such as Ethernet or other industrial specific protocols) to achieve system integration and remote monitoring. This is very useful in scenarios where remote monitoring of industrial processes is required or integrated into larger industrial ecosystems.
Power module GHI – ensures stable and reliable power supply for T9851 and other modules in the control system. For the accurate operation of T9851, a stable power supply is crucial, as any power fluctuations can lead to incorrect output signals, thereby interfering with industrial processes.
Terminal block module JKL – used to connect field devices to T9851. It provides a convenient and orderly electrical connection method, ensuring reliable signal transmission between the module and the connected actuator or sensor.

Installation and maintenance:
It is crucial to carefully plan the installation location before installing T9851. Ensure that the control cabinet has sufficient space to accommodate the module, while considering its size. Adequate ventilation should be provided inside the cabinet to dissipate the heat generated during module operation. Check the power requirements to ensure that the input voltage and current ratings match the requirements of T9851. When connecting to actuators, sensors, or other devices, use appropriate wiring techniques to prevent electromagnetic interference. Ensure all connections are secure to avoid unstable output signals or signal loss caused by loose connections.

For maintenance, it is recommended to conduct regular visual inspections. Check at least once a month for any signs of physical damage, such as cracks in the casing or loose connectors. Regularly (every three months) conduct functional testing to ensure that all output channels are functioning properly. Testing can be conducted by sending known control signals to T9851 and verifying whether the connected devices respond as expected. Pay attention to the operating temperature of the module, as overheating may cause component failure. If the module is installed in a dusty environment, it should be cleaned regularly with compressed air to prevent dust accumulation from affecting its performance. Stay up-to-date with the latest firmware versions released by manufacturers, as these versions may include bug fixes, performance improvements, and enhanced features.
