T9801 Digital Input Module

Description

T9801 is a digital input module designed to become a critical component in industrial control systems. It comes from ICS’ AADvance controller product line, a well-known manufacturer in the field of industrial automation. This module is designed to establish an interface between field level sensors and higher-level control systems, serving as a bridge for data transmission.

T9801

In industrial control architecture, T9801 belongs to the input subsystem. It is responsible for receiving digital signals from various sensors, including limit switches, proximity sensors, and photoelectric sensors. Once these signals are received, T9801 will process them and transmit the data to the central processing unit (CPU) of the control system. Then, the CPU uses this data to execute control algorithms and sends commands to actuators to regulate industrial processes.

For engineers and system integrators, T9801 has high value. Its simplex design and ability to handle different scanning times (such as 0.924 milliseconds, 1.676 milliseconds, and 2.453 milliseconds) provide flexibility for system design. It can be easily integrated into existing control systems, whether they are based on programmable logic controllers (PLCs) or more complex distributed control systems (DCS).

T9801

Main features and advantages:
One of the outstanding features of T9801 is its channel capacity. It has 16 input channels and is capable of processing a large number of sensor input signals simultaneously. This is very advantageous in industrial applications that require the use of multiple sensors to monitor different aspects of industrial processes. For example, in large manufacturing plants, there may be sensors used to monitor location, temperature, and pressure, all of which transmit data to T9801.

T9801 also provides flexibility in scanning time. Being able to use different scanning times enables engineers to optimize the performance of control systems according to the requirements of industrial processes. In high-speed processes, shorter scanning times can be chosen to ensure that data can be processed quickly and corresponding actions can be taken. On the contrary, in processes with slow data changes, longer scanning times can be used to reduce the computational burden on the system.

In terms of electrical ratings, T9801 is designed to be sturdy. It can handle an input voltage range of 0 to 32 volts DC and has a rated current of 6.5 amperes. This wide voltage range makes it suitable for various industrial environments, where power supply conditions may vary. The electrical rating of its backplane is 18 to 32 volts DC, with a maximum backplane current rating of 260 milliamps, ensuring reliable communication with other components in the control system.

This module also features a compact and lightweight design, weighing only 340 grams (12 ounces). This makes it easy to install in narrow spaces inside control cabinets, which is often common in industrial environments where space is often very valuable. In addition, its design is easy to install and configure, without the need for complex wiring or special tools. All 16 input channels are isolated, which helps prevent electrical interference and ensure accurate data transmission.

T9801

Technical specifications:
Model T9801
Brand ICS
Type number input module
Power input voltage range: 0-32V DC, rated current: 6.5A; backplane voltage range: 18-32V DC, backplane current: 260mA
The working temperature is suitable for industrial environments, typically ranging from -20 ° C to+60 ° C
The installation method is designed for easy installation inside the control cabinet
Size 163 × 38 × 58 millimeters
Weight 340 grams (12 ounces)
Interface with sensors to obtain digital inputs; Interface with the backplane to transmit data to the control system
Certification approval for non hazardous and hazardous environments, with a hazardous environment rating of Class 1, Zone 2, Groups A, B, C, and D for North American industrial environments
Natural convection for heat dissipation, suitable for normal industrial operation
The environmental level can resist common vibrations and electrical interference in industrial environments

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

T9801

Application areas:
In the manufacturing industry, especially in automobile production factories, T9801 plays a crucial role in ensuring the smooth operation of assembly lines. It serves as a digital input module, collecting data from various sensors on the assembly line. For example, a position sensor installed at a specific workstation to detect whether car parts are in place will send a signal to T9801. With its 16 channel capacity, it can efficiently process these input signals in real-time. Subsequently, these data will be transmitted to the central control system, which will use them to coordinate the movements of robotic arms, conveyors, and other mechanical equipment. T9801 is capable of processing multiple input signals simultaneously with extremely high accuracy, which is crucial for maintaining high-speed and error free operation of the assembly line.

In the oil and gas industry, safety and reliability are crucial, and T9801 is applied in control systems for drilling platforms and refineries. In drilling operations, it monitors sensor signals that measure parameters such as drill bit depth, torque, and pressure. By accurately processing these digital input signals, T9801 enables operators to make informed decisions in real-time, thereby preventing equipment failures and potential safety hazards. In refineries, it is used to control the opening and closing of valves, ensuring the normal flow of crude oil and its derivatives in complex pipelines and processing unit networks.

T9801

Related products:
T9802- Digital output module, can be used in conjunction with T9801 to complete input-output cycles in control systems. It sends control signals to the actuator based on data processed by T9801 and other input modules.
The AADvance CPU module XYZ – the central processing unit of the AADvance system, receives data from T9801 and executes control algorithms. It is the ‘brain’ of the control system, coordinating the overall operation based on input data.
Analog input module ABC – This module is used to interface with sensors that provide analog signals. Although T9801 handles digital inputs, the analog input module extends the system’s functionality to handle a wider range of sensor types, such as temperature sensors that output analog voltage signals.
Communication module DEF – helps T9801 and other components in the control system communicate with external devices or other control systems. It supports data transmission through different protocols such as Ethernet or Modbus, facilitating system integration and remote monitoring.
Power module GHI – ensures stable and reliable power supply for T9801 and other modules in the control system. Appropriate power supply is crucial for the accurate operation of T9801 and the overall performance of the control system.
Terminal block module JKL – used to connect sensors and other field devices to T9801. It provides a convenient and orderly electrical connection method, ensuring reliable signal transmission between on-site devices and input modules.

T9801

Installation and maintenance:
Before installing T9801, it is necessary to carefully plan the installation location. Ensure that the control cabinet has sufficient space to accommodate the module, considering its dimensions of 163 × 38 × 58 millimeters. Adequate ventilation should also be provided to dissipate the heat generated during operation. Check the power requirements and ensure that the input voltage and current ratings match T9801. When connecting sensors and backplates, use appropriate wiring techniques to prevent electrical interference. Ensure all connections are secure to avoid data transmission errors caused by loose connections.

For maintenance, it is recommended to conduct regular visual inspections. Check at least once a month for any signs of physical damage, such as cracks in the casing or loose connectors. It is recommended to conduct a functional test every three months to ensure that all 16 input channels are functioning properly. This can be achieved by using a signal generator to send known digital signals to the module and verifying whether the control system is receiving and processing these data correctly. Pay attention to the operating temperature of the module, as overheating can affect its performance. If the module is installed in a dusty environment, it should be cleaned regularly with compressed air to prevent dust accumulation, which may also affect its operation. Stay up-to-date with the latest firmware versions released by manufacturers, as these versions may include bug fixes, performance improvements, and enhanced features.
