Name: SCHNEIDER TSXCUSBMBP Multi - function Communication Module | Qiming Automation
Brand: Schneider

Description

The SCHNEIDER TSXCUSBMBP is a multi – function communication module that serves as a crucial link in industrial automation systems. It’s designed to facilitate data exchange between different devices and control platforms, enabling seamless integration and enhanced system performance. With its USB and Modbus communication capabilities, the module provides a flexible and versatile interface for connecting a wide range of industrial equipment.

TSXCUSBMBP

The module interfaces with devices through its USB port, which allows for easy connection to external devices such as laptops for programming and configuration, or to storage devices for data logging. It also supports Modbus communication, a widely used protocol in industrial automation, enabling it to communicate with other Modbus – compatible devices, including PLCs, sensors, and actuators. This dual – communication capability makes the SCHNEIDER TSXCUSBMBP highly adaptable, as it can integrate into existing systems with different communication requirements. It can handle data transfer at high speeds, ensuring that real – time data from the field is quickly processed and acted upon by the control system. Additionally, the module features built – in diagnostic functions, which help engineers quickly identify and resolve communication issues, minimizing downtime and maximizing system availability.

TSXCUSBMBP

Technical specifications:
Model Number TSXCUSBMBP
Brand Schneider
Type Multi – function Communication Module
Interface USB 2.0, Modbus RTU/ASCII
Baud Rate 1200 – 115200 bps (Modbus), up to 480 Mbps (USB)
Operating Temp Range 0 °C to + 55 °C
Mounting Style DIN Rail
Dimensions 100mm x 50mm x 30mm
Weight 0.1 kg
Input Voltage24 V DC
ComplianceCE, RoHS, and other relevant industrial standards
Supported ProtocolsModbus RTU, Modbus ASCII
Typical Power Draw3 W

contact information
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

TSXCUSBMBP

Main features and advantages:

Opting for the SCHNEIDER TSXCUSBMBP brings a host of real – world benefits. Engineered for industrial reliability, its operating temperature range ensures consistent performance in typical industrial environments. The high – speed data transfer capabilities of the USB interface and the wide – range baud rate support for Modbus communication enable it to handle large volumes of data efficiently, reducing the risk of bottlenecks and ensuring smooth operation even during peak production periods. This significantly cuts down on engineering overhead, as engineers spend less time troubleshooting communication issues and more time optimizing processes.

The dual – communication interface of the SCHNEIDERTSXCUSBMBP provides flexibility in system integration. The USB port simplifies device configuration and data management, allowing for easy updates and backups. The Modbus compatibility ensures seamless connection with a vast array of industrial devices, making it easier to expand and upgrade existing automation systems. The built – in diagnostic tools simplify maintenance, allowing engineers to quickly pinpoint and resolve communication failures, which in turn reduces downtime and maintenance costs. Its compact design and DIN – rail mounting style make installation straightforward, saving time and space in industrial control panels.

TSXCUSBMBP

Application areas:

The SCHNEIDER TSXCUSBMBP finds extensive use across various industries. In the food and beverage industry, it’s used to connect sensors monitoring temperature, humidity, and ingredient levels to the control system, ensuring precise process control and product quality. The ability to handle real – time data and communicate with multiple devices simultaneously makes it ideal for managing complex production lines with numerous interconnected components.

In the packaging industry, the module coordinates the operation of different packaging machines, ensuring smooth material handling and accurate product packaging. Its reliable communication capabilities are crucial for maintaining production efficiency and minimizing downtime.

In building automation systems, the SCHNEIDERTSXCUSBMBP connects various building management devices, such as HVAC systems, lighting controls, and security sensors, to a central control unit. This enables integrated management and optimization of building operations, improving energy efficiency and occupant comfort.

TSXCUSBMBP

Related products:

TSXCFY21 – A communication module with different interface options, suitable for applications that require Ethernet or other communication protocols instead of USB and Modbus.

TSXASY41 – Offers additional analog input/output capabilities along with communication functions, making it a better fit for applications that need to handle both data communication and analog signal processing.

TM221M16R – A compact PLC with built – in communication features, providing an alternative for smaller – scale automation projects where a combination of control and communication is required.

TSXDMZ28DRT – Has more digital I/O points and communication interfaces, suitable for larger – scale applications that demand higher I/O capacity and enhanced communication capabilities.

TSXETZ20 – Focuses on Ethernet – based communication, ideal for modern industrial networks that rely heavily on Ethernet for data transfer and device integration.

TSXDSY82 – A specialized module for serial communication, useful for applications where legacy serial – based devices need to be integrated into the automation system.

TSXDSZ16D2 – Offers digital input/output functionality along with communication features, providing a more comprehensive solution for applications that require both data exchange and device control.

Installation and maintenance:

Before installing the SCHNEIDER TSXCUSBMBP it’s essential to verify its compatibility with the existing control system and connected devices. Ensure that the power supply meets the specified 24 V DC requirement. Check the communication settings of the module and the connected devices to ensure they match, especially for Modbus communication, where parameters such as baud rate, parity, and data bits need to be correctly configured. When using the USB interface, make sure the connected device, such as a laptop, has the necessary drivers installed for proper communication.

For ongoing maintenance, regularly monitor the module’s diagnostic indicators to detect any potential communication issues at an early stage. Check the communication status with connected devices to ensure seamless data transfer. Periodically update the module’s firmware to benefit from the latest features, security patches, and performance improvements. Inspect the connections and cables for any signs of wear and tear, as loose or damaged connections can lead to communication failures or data loss.
