The Schneider Electric 140CPS11420 is a power module meticulously designed for the Modicon Quantum automation platform. As an integral part of this renowned and versatile modular programmable logic controller (PLC) platform, it occupies a central position in enabling the proper functioning of the entire system.
Model 140CPS11420
Brand Schneider Electric
Type Power Module
Product Series Modicon Quantum
Input Voltage 115 V (93…132 V) AC 47…63 Hz or 230 V (170…276 V) AC
Input Current 1300 mA at 115 V; 750 mA at 230 V
Maximum Inrush Current 19 A at 230 V; 38 A at 115 V
Rated Power (VA) 130 VA
Fuse for Relay Use 2 A, slow – blow type
Harmonic Distortion <= 10 % basic RMS
Output Voltage 5.1 V DC
Power Output Current 11 A at 60 °C (independent); 20 A at 60 °C (summable)
Output Over – voltage Protection Internal
Output Overload Protection Internal
Power Consumption 6 + (1.5 x output current) (output current in A)
Alarm Output 1 NC 6 A 220 V
Power Fault Local Signal Indicator 1 LED (green) (PWR OK)
CE Module Classification Standard
Product Net Weight 0.65 kg
Compliance Standards UL 508, CSA C22.2 No 142
Product Certification cUL
Electrostatic Discharge Resistance 4 kV contact, 8 kV air (complies with IEC 801 – 2)
Electromagnetic Field Resistance 10 V/m 80…2000 MHz (complies with IEC 801 – 3)
Operating Temperature 0…60 °C
Storage Environment Temperature – 40…85 °C
Relative Humidity 95 % non – condensing
Working Altitude <= 5000 m
The Schneider Electric 140CPS11420 is a power module meticulously designed for the Modicon Quantum automation platform. As an integral part of this renowned and versatile modular programmable logic controller (PLC) platform, it occupies a central position in enabling the proper functioning of the entire system.
140CPS11420
The Modicon Quantum series is celebrated for its robustness, flexibility, and high – performance capabilities, making it a go – to choice for a wide range of industrial control applications. The 140CPS11420 power module serves as the power – generating heart of the Modicon Quantum setup. Its primary function is to convert the incoming 115 V (93…132 V) AC or 230 V (170…276 V) AC electrical power into a stable and suitable DC voltage that can be utilized by other components within the system. These components include the CPU, which acts as the brain of the PLC, processing complex control algorithms, as well as input/output (I/O) modules that interface with external sensors and actuators, and communication modules that enable seamless data transfer within the control network.
In the overall architecture of an industrial control system, the power module is like the reliable power station that supplies electricity to a bustling city. Its compatibility with the Modicon Quantum platform allows for easy integration, whether in new installations or upgrades to existing systems. For engineers and integrators, the 140CPS11420 offers a dependable and efficient power solution. It simplifies the power management aspect of building and maintaining industrial control systems, allowing them to focus on other critical tasks such as programming the PLC for specific control functions, integrating different types of sensors and actuators, and ensuring the overall system’s security and performance.
140CPS11420
Main features and advantages:
The Schneider Electric 140CPS11420 power module boasts several outstanding features that contribute to its high – performance and reliability.
Functionally, it exhibits remarkable power efficiency, with a rate exceeding 85%. This high efficiency means that a large proportion of the incoming electrical power is effectively converted into useful DC power for the connected components. As a result, energy waste is minimized, leading to reduced operating costs over time. The module is engineered to provide a stable output voltage of 5.1 V DC, with a substantial power output current capacity. It can supply up to 11 A at 60 °C when operating independently, and an impressive 20 A at 60 °C when used in a summable configuration. This stable and high – current output ensures that the connected devices, such as PLC modules, operate within their optimal voltage and current ranges, significantly reducing the risk of malfunctions caused by power fluctuations.
In terms of hardware design, the 140CPS11420 is both compact and rugged. Measuring only 90 x 30 x 25 millimeters, it can be easily installed in even the most space – constrained control cabinets. Despite its small size, it is built to withstand the harsh conditions often found in industrial environments. Its robust construction protects it from vibrations, dust, and temperature variations. With an operating temperature range spanning from 0 °C to 60 °C and a storage temperature range of – 40 °C to 85 °C, it can be deployed in a wide variety of industrial settings, from cold storage facilities to hot and humid manufacturing plants.
Compatibility is one of the module’s strong suits. It is specifically tailored to work in perfect harmony with the Modicon Quantum series of PLCs. This seamless compatibility extends to other components within the Modicon Quantum ecosystem, ensuring a comprehensive and unified control solution. Whether it’s integrating with different types of I/O modules or communication modules, the 140CPS11420 makes the process straightforward and reliable.
For long – term reliability, the module is constructed with high – quality components. Its internal thermal management system is highly efficient, dissipating heat effectively and preventing overheating, which is a common cause of component degradation and reduced lifespan. Additionally, it comes equipped with internal output over – voltage and overload protection mechanisms. These protective features safeguard the connected devices from potential electrical hazards, further enhancing the module’s long – term reliability and reducing the need for frequent replacements and maintenance.
140CPS11420
Technical specifications:
Model 140CPS11420
Brand Schneider Electric
Type Power Module
Product Series Modicon Quantum
Input Voltage 115 V (93…132 V) AC 47…63 Hz or 230 V (170…276 V) AC
Input Current 1300 mA at 115 V; 750 mA at 230 V
Maximum Inrush Current 19 A at 230 V; 38 A at 115 V
Rated Power (VA) 130 VA
Fuse for Relay Use 2 A, slow – blow type
Harmonic Distortion <= 10 % basic RMS
Output Voltage 5.1 V DC
Power Output Current 11 A at 60 °C (independent); 20 A at 60 °C (summable)
Output Over – voltage Protection Internal
Output Overload Protection Internal
Power Consumption 6 + (1.5 x output current) (output current in A)
Alarm Output 1 NC 6 A 220 V
Power Fault Local Signal Indicator 1 LED (green) (PWR OK)
CE Module Classification Standard
Product Net Weight 0.65 kg
Compliance Standards UL 508, CSA C22.2 No 142
Product Certification cUL
Electrostatic Discharge Resistance 4 kV contact, 8 kV air (complies with IEC 801 – 2)
Electromagnetic Field Resistance 10 V/m 80…2000 MHz (complies with IEC 801 – 3)
Operating Temperature 0…60 °C
Storage Environment Temperature – 40…85 °C
Relative Humidity 95 % non – condensing
Working Altitude <= 5000 m
contact information Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
140CPS11420
Application areas:
In the fast-paced and complex world of industrial automation, a stable and reliable power source is the lifeblood of any control system. The Schneider Electric 140CPS11420 power module emerges as a linchpin in diverse industrial settings, playing a crucial role in maintaining seamless operations.
In automotive manufacturing plants, where a vast array of automated machinery works in harmony to assemble vehicles, the 140CPS11420 is hard at work. It powers the Modicon Quantum PLCs that manage robotic arms, which precisely weld, paint, and assemble car parts. The stable power supply ensures these high – speed robots operate with pinpoint accuracy, reducing errors and increasing production throughput. For instance, in a high – volume car production line, even a minor power glitch could cause a robotic arm to misalign, leading to costly rework or damaged parts. The140CPS11420 mitigates such risks by providing a consistent power output.
Food and beverage processing facilities also rely heavily on this power module. Here, strict hygiene and quality control requirements demand uninterrupted and precise control systems. The 140CPS11420 powers the PLCs that regulate the filling, capping, and packaging of food and drink products. In a dairy processing plant, for example, it ensures that the milk carton filling machines operate at a consistent pace, maintaining the correct fill levels and minimizing product waste. Any power instability could disrupt the delicate processes, leading to issues such as under – filled or over – filled containers, which are unacceptable in this highly regulated industry.
In the energy sector, power generation and distribution plants use the 140CPS11420 to power control systems that monitor and manage electrical grids. In a wind farm, the power module supplies power to the PLCs that control the pitch and yaw of wind turbines, optimizing energy capture based on wind speed and direction. In a power substation, it powers the control systems that regulate voltage levels and ensure the safe and efficient distribution of electricity. By providing a reliable power source, the 140CPS11420 helps maintain grid stability, preventing blackouts and power surges that could damage electrical equipment and disrupt supply to consumers.
140CPS11420
Related products:
140CPS11410 – A related power module in the Modicon Quantum series. It might have different power output ratings or features, which can be a suitable alternative in applications where the power requirements deviate slightly from what the 140CPS11420 offers.
140CPU11302 – A CPU module within the Modicon Quantum family. It pairs perfectly with the 140CPS11420 power module. The power module provides the necessary power for the CPU to execute complex control algorithms and manage the overall operation of the PLC system.
140DDI35300 – A digital input module that can be part of a Modicon Quantum system powered by the 140CPS11420. It is responsible for receiving digital input signals from sensors and other external devices, which are then processed by the overall system.
140DAO84000 – A digital output module that works in tandem with the 140CPS11420 – powered system. It sends out digital output signals to control various actuators, such as motors, valves, and relays, enabling the automation of industrial processes.
140NOE77101 – An Ethernet communication module that can be integrated into a Modicon Quantum setup powered by the 140CPS11420. It enables network communication, allowing for remote monitoring and control of the system, which is crucial for large – scale industrial operations.
140CPS12400 – Another power module in the series. It may have distinct characteristics, such as different input voltage options or power management features. It can be used as an alternative power source or in redundant power setups with the 140CPS11420 to enhance system reliability.
140XBP01000 – A PLC installation rail from Schneider Electric that is compatible with the Modicon Quantum series. It offers a convenient and secure mounting solution for the 140CPS11420 and other related modules, ensuring proper installation and organization within a control cabinet.
Installation and maintenance:
Before installing the Schneider Electric 140CPS11420power module, a thorough assessment of the control cabinet environment is essential. Ensure that there is ample space around the module to facilitate proper ventilation. Since the module generates heat during operation, good airflow is critical to prevent overheating, which can significantly impact its performance and lifespan. Check the grounding system of the cabinet to ensure it meets the required standards. A proper ground connection not only protects the module from electrical surges but also ensures safe operation. Additionally, make sure there is sufficient clearance from other electrical components. This helps avoid electromagnetic interference, which could potentially disrupt the power module’s operation and cause erratic behavior in the overall control system.
For maintenance, regular visual inspections are highly recommended. Periodically check for any signs of physical damage, such as cracks in the enclosure or loose connections. Monitor the module’s temperature during operation. If it starts to run unusually hot, it could be an indication of an underlying problem, such as a component malfunction or a ventilation issue. It’s also important to keep an eye on the power output levels using appropriate testing equipment. Although the 140CPS11420 is a reliable module, it’s prudent to have spare parts on hand in case of unexpected failures. Stay updated with any firmware updates or technical advisories released by Schneider Electric. These updates often address potential issues, improve performance, and enhance the module’s compatibility with other components in the system.
