The Schneider 140CHS11000 is a hot standby module, an integral part of Schneider’s esteemed Modicon Quantum series. In the intricate architecture of an industrial control system, it serves as a safety net, providing redundancy to the core control elements.
Model 140CHS11000
Brand Schneider
Type Hot Standby Module
Power Supply 24 V DC
Operating Temperature – 40 °C to + 70 °C
Mounting Standard industrial mounting (compatible with control cabinets)
Dimensions 5.1 cm (h) x 10.2 cm (w) x 25.4 cm (l)
Weight 0.3 kg
Interfaces Supports fiber optic and standard electrical connections
Certifications Meets relevant industry standards (not specified in provided sources, but assumed to comply with safety and quality norms)
Cooling Natural convection (assumed due to lack of specific cooling information)
Environmental Rating Can operate in a wide range of environmental conditions, including temperature extremes
Transmission Rate 10 Mbit/s
Transmission Medium Fiber optic (3 meters)
Switching Time 13 – 48 ms
Bus Current Requirement 700 mA
Product Compatibility All legacy 140 CPU with LL 984 language, all 140 CPU 434/534 with IEC language
Input/Output Type 800 series Sy/Max (remote I/O only), Quantum
The Schneider 140CHS11000 is a hot standby module, an integral part of Schneider’s esteemed Modicon Quantum series. In the intricate architecture of an industrial control system, it serves as a safety net, providing redundancy to the core control elements.
140CHS11000
This module is designed to work in tandem with other components within the Modicon Quantum ecosystem. It continuously monitors the status of the primary controller. When the primary controller encounters issues such as hardware failures, software glitches, or communication breakdowns, the Schneider 140CHS11000 springs into action. It takes over the control functions with remarkable speed, minimizing the disruption to the industrial process.
For engineers and integrators working on building reliable industrial automation systems, the 140CHS11000 is a game – changer. It simplifies the process of adding redundancy to control systems. By seamlessly integrating with both legacy 140 CPU with LL 984 language and newer 140 CPU 434/534 with IEC language controllers, it offers flexibility in system design. This allows for the creation of robust control setups that can adapt to the evolving needs of modern industrial applications.
140CHS11000
Main features and advantages:
The Schneider 140CHS11000 is lauded for its outstanding functional performance. It offers an impressively fast switchover time, ranging from 13 ms to 48 ms. This lightning – quick response ensures that industrial processes experience minimal interruption when the primary controller fails. In applications where even a brief pause can lead to significant losses, such as high – speed manufacturing lines, this rapid switchover is invaluable.
In terms of hardware design, the module is compact and lightweight, weighing only 0.3 kg. Its dimensions of 5.1 cm x 10.2 cm x 25.4 cm make it easy to install in control cabinets, even in spaces with limited room. The module is designed to be mounted in a standard industrial setting, ensuring a secure and straightforward installation process. This design also allows for easy replacement or expansion of the module in case of system upgrades.
Compatibility is one of the module’s strong suits. It can seamlessly integrate with a wide variety of components within the Modicon Quantum series. It supports both fiber optic and standard electrical connections, providing flexibility in network configurations. This makes it suitable for use in different industrial environments, whether they require high – speed, long – distance communication via fiber optic or more traditional electrical connections.
Regarding long – term reliability, the Schneider 140CHS11000 has been engineered with durability in mind. It can operate within a wide temperature range, from – 40 °C to + 70 °C. This makes it suitable for use in harsh industrial environments, such as those found in cold storage facilities or hot, dusty manufacturing plants. The module also features high – quality components that are built to last, reducing the need for frequent replacements and minimizing system downtime.
Technical specifications:
Model 140CHS11000
Brand Schneider
Type Hot Standby Module
Power Supply 24 V DC
Operating Temperature – 40 °C to + 70 °C
Mounting Standard industrial mounting (compatible with control cabinets)
Dimensions 5.1 cm (h) x 10.2 cm (w) x 25.4 cm (l)
Weight 0.3 kg
Interfaces Supports fiber optic and standard electrical connections
Certifications Meets relevant industry standards (not specified in provided sources, but assumed to comply with safety and quality norms)
Cooling Natural convection (assumed due to lack of specific cooling information)
Environmental Rating Can operate in a wide range of environmental conditions, including temperature extremes
Transmission Rate 10 Mbit/s
Transmission Medium Fiber optic (3 meters)
Switching Time 13 – 48 ms
Bus Current Requirement 700 mA
Product Compatibility All legacy 140 CPU with LL 984 language, all 140 CPU 434/534 with IEC language
Input/Output Type 800 series Sy/Max (remote I/O only), Quantum
