SA9923A-E Multi-channel Analog Output Module

Description

SA9923A-E

The SA9923A-E is a high-performance analog output module designed specifically for integration with ABB’s Symphony Plus and AC 800M control systems, converting digital control signals into precise analog outputs for controlling industrial actuators and final control elements. As a critical interface between control systems and field devices, this module translates controller commands into proportional electrical signals that regulate the operation of valves, dampers, variable frequency drives, and other process equipment.

SA9923A-E

Its design focuses on delivering exceptional accuracy and stability across a wide range of operating conditions, making it ideal for mission-critical applications in power generation, chemical processing, and pharmaceutical manufacturing. What distinguishes the SA9923A-E is its combination of multi-channel capability and advanced signal conditioning, providing system integrators with a flexible solution that reduces cabinet space while ensuring precise control of multiple process variables.

SA9923A-E

Main features and advantages:

A key advantage of the SA9923A-E is its exceptional output accuracy, with a total error budget of less than 0.1% of full scale, ensuring precise control of critical process variables. The module features 8 independent analog output channels, each configurable for either 4-20mA current output or 0-10V voltage output, providing flexibility to interface with various field devices without requiring multiple specialized modules. Advanced signal filtering technology minimizes the impact of electrical noise common in industrial environments, ensuring stable output signals even when installed near high-power equipment. Hardware-wise, the SA9923A-E features a rugged construction with conformal coating on circuit boards, providing protection against dust, moisture, and chemical contaminants. Its modular design allows for easy installation in standard control cabinets, while built-in self-diagnostic capabilities continuously monitor channel health and signal integrity, simplifying troubleshooting.

SA9923A-E

Application areas:

In industrial process control systems, accurate and reliable signal transmission to final control elements is critical for maintaining product quality, process efficiency, and operational safety. Power plants, chemical processing facilities, and manufacturing lines require analog output modules that can convert digital control signals into precise analog outputs to regulate valves, variable speed drives, and other actuators. Whether controlling flow rates in a petroleum refinery, adjusting temperature in a batch reactor, or regulating pressure in a water treatment plant, engineers need modules that deliver consistent performance even in harsh industrial environments. This is where the SA9923A-E excels, serving as a high-precision analog output module in industrial automation setups where signal accuracy directly impacts process control and product consistency. Used in industrial automation applications ranging from distributed control systems (DCS) to machine-level control, the SA9923A-E addresses key challenges such as signal stability, noise immunity, and seamless integration with ABB’s control platforms.

SA9923A-E

Related products:

ABB SA811F – Communication module that transmits control signals to the SA9923A-E from supervisory systems.

ABB S-073N 3BHB009884R0021 – Power module providing stable 24V DC power to the SA9923A-E in control cabinet installations.

ABB PM866K01 3BSE022496R1 – Processor module that generates digital control signals for the SA9923A-E.

ABB RXTUG – Terminal unit that provides secure field wiring connections for the SA9923A-E’s output channels.

ABB RXIIK 4 – Analog input module whose measured data is used by controllers to generate setpoints for the SA9923A-E.

ABB CI854A 3BSE036411R1 – Communication module that interfaces with the SA9923A-E in Profibus-based systems.

ABB TU847 3BSE008511R1 – Terminal unit that houses the SA9923A-E in distributed I/O racks.

ABB SD831 3BSE036207R1 – Safety controller that monitors the SA9923A-E’s status in safety-critical applications.

SA9923A-E

Installation and maintenance:

Before installing the SA9923A-E, ensure the mounting location provides protection from extreme temperatures, vibration, and direct exposure to moisture or corrosive substances. Verify that the control cabinet has adequate ventilation to maintain ambient temperatures within the module’s specified operating range. The module should be connected to a clean 24V DC power supply with appropriate filtering to minimize electrical noise, preferably from a redundant power source for critical applications. Maintain a minimum clearance of 30 mm around the module to facilitate airflow and simplify wiring access. When connecting field devices, use shielded cables with the shields properly grounded at both ends to maximize noise immunity, and route output wiring separately from high-voltage power cables.

For optimal maintenance of the SA9923A-E, implement a quarterly calibration schedule using traceable standards to ensure output accuracy is maintained within specifications. Perform monthly visual inspections to check for loose connections, signs of corrosion, or damage to terminal blocks. Use the module’s built-in diagnostic capabilities and ABB’s control system software to monitor channel performance, checking for drift or offset errors that could indicate potential issues. During scheduled maintenance windows, verify that overcurrent protection features are functioning correctly by performing controlled test procedures. Keep firmware updated to the latest version available through ABB’s support portal to ensure compatibility with system updates and access to new diagnostic features.
