RXTUG Industrial Terminal Unit

Description

RXTUG

The RXTUG is a high-density industrial terminal unit designed specifically for use with ABB’s AC 800M distributed control system and I/O modules, providing a secure interface between field wiring and control system components. As an essential connectivity component in control system architecture, this terminal unit serves as the physical connection point where field devices interface with I/O modules, consolidating wiring and providing protection for critical signal paths.

RXTUG

Its design focuses on simplifying installation and maintenance while ensuring reliable signal transmission, making it ideal for complex industrial environments with numerous field connections. What distinguishes the RXTUG is its combination of compact design and robust construction, providing system integrators with an organized wiring solution that reduces installation time while enhancing long-term reliability.

Main features and advantages:

A key advantage of the RXTUG is its high-density terminal configuration, featuring multiple connection points that accommodate various wire sizes (0.5 mm² to 2.5 mm²) without requiring specialized tools for termination. The terminal unit incorporates spring-clamp or screw-terminal technology that ensures secure connections even in vibrating industrial environments, preventing the signal interruptions that can cause process disruptions. Hardware-wise, the RXTUG features a rugged plastic housing with flame-retardant properties and protection against dust ingress, ensuring reliable operation in temperatures ranging from -40°C to 70°C. Its modular design allows for easy mounting alongside ABB I/O modules, while clear labeling and color-coded terminals simplify wiring identification and troubleshooting during maintenance procedures.

Application areas:

In industrial control cabinets, distributed control system (DCS) installations, and process automation racks, reliable physical connection between field devices and control modules forms the critical link in data transmission. These environments require terminal units that can securely terminate wiring from sensors, actuators, and other field equipment while protecting connections from vibration, dust, and electrical interference. Whether connecting thermocouples in a chemical reactor control system, wiring pressure transmitters in an oil refinery, or linking motor starters in a manufacturing plant, engineers need robust terminal solutions that ensure consistent signal integrity. This is where the RXTUG excels, serving as a vital connection hub in industrial automation setups where secure, organized wiring directly impacts system reliability and maintenance efficiency. Used in industrial automation applications ranging from DCS I/O racks to machine control panels, the RXTUG addresses key challenges such as wiring management, connection security, and seamless integration with ABB’s control system modules.

Related products:

ABB RXIIK 4 – Analog input module that connects to field sensors through the RXTUG’s terminal connections.

ABB RYDDI 2H 1MRK000842-HA – Digital output module requiring the RXTUG for secure actuator wiring termination.

ABB RXPPK – Power supply module that distributes power to connected devices through the RXTUG’s power terminals.

ABB CI858 3BSE058459R1 – Communication module that uses the RXTUG for auxiliary wiring connections in networked systems.

ABB PM866K01 3BSE022496R1 – AC 800M processor module that interfaces with field devices via the RXTUG terminal unit.

ABB TB851 3BSE008512R1 – Terminal base that mates with the RXTUG to provide mechanical support in I/O racks.

ABB AI893 3BSE013230R1 – High-accuracy analog module that relies on the RXTUG for noise-free signal transmission.

ABB SD831 3BSE036207R1 – Safety controller module requiring the RXTUG for secure wiring in SIL 3 applications.

Installation and maintenance:

Before installing the RXTUG, ensure the mounting rail is properly aligned and securely fastened to prevent movement that could strain connections. Verify that the terminal unit is positioned to allow easy access for wiring and future maintenance, with adequate clearance for wire bending radius (minimum 8 mm for 2.5 mm² wires). Check that the ambient temperature in the installation location remains within the specified operating range, as extreme temperatures can affect connection integrity. Ensure the mounting surface is clean and free from debris that could interfere with the module’s seating or cause electrical insulation issues. For safety-critical applications, confirm that the RXTUG is properly grounded according to local electrical codes and ABB’s installation guidelines.

For optimal maintenance of the RXTUG, implement a quarterly inspection schedule to check for loose connections, signs of corrosion, or wire damage. Tighten any terminals showing signs of loosening using the recommended torque setting (0.5-0.6 Nm for spring-clamp terminals). Clean dust and debris from terminal surfaces semi-annually using compressed air or a dry cloth, taking care not to disturb existing connections. During system upgrades or modifications, label all wires before disconnecting them from the RXTUG to simplify reconnection. Inspect terminal markings regularly to ensure they remain legible, as clear identification is critical for accurate troubleshooting and maintenance.
