REXROTH MSK076C-0450-NN-M1-UG1-NNNN High – Performance Servo Motor
Sale!
REXROTH MSK076C-0450-NN-M1-UG1-NNNN High – Performance Servo Motor
The REXROTH MSK076C-0450-NN-M1-UG1-NNNN is a powerhouse when it comes to performance. It offers a rated torque of 2.5 Nm, enabling it to handle substantial loads with remarkable ease. This makes it an ideal choice for applications such as heavy – duty conveyor systems in the logistics industry, where large – scale movement of goods is required. The motor can achieve a maximum speed of 4500 rpm, providing a well – balanced combination of speed and torque for a diverse range of industrial operations. For instance, in the metal stamping industry, this speed – torque ratio allows for rapid yet forceful stamping actions, ensuring efficient production of high – quality metal components.
Model MSK076C-0450-NN-M1-UG1-NNNN
Brand REXROTH
Type High – Performance Servo Motor
Rated Power 2.2 kW
Rated Torque 2.5 Nm
Maximum Speed 4500 rpm
Voltage 400 V AC (three – phase)
Protection Rating IP65
Encoder Type High – resolution absolute (262144 counts/rev)
Mounting Flange (IEC 112, 71 mm)
Weight 11 kg
Operating Temperature – 10°C to 45°C (derated up to 55°C)
Cooling Natural convection with enhanced heat dissipation fins
Certifications CE, UL, CSA, ISO 14001 (environmental), ISO 45001 (occupational health and safety)
The REXROTH MSK076C-0450-NN-M1-UG1-NNNN is a powerhouse when it comes to performance. It offers a rated torque of 2.5 Nm, enabling it to handle substantial loads with remarkable ease. This makes it an ideal choice for applications such as heavy – duty conveyor systems in the logistics industry, where large – scale movement of goods is required. The motor can achieve a maximum speed of 4500 rpm, providing a well – balanced combination of speed and torque for a diverse range of industrial operations. For instance, in the metal stamping industry, this speed – torque ratio allows for rapid yet forceful stamping actions, ensuring efficient production of high – quality metal components.
MSK076C-0450-NN-M1-UG1-NNNN
Main features and advantages:
One of the key features that sets the MSK076C-0450-NN-M1-UG1-NNNN apart is its low – inertia design. This characteristic enables the motor to accelerate and decelerate with lightning – fast speed, which is of utmost importance in applications involving frequent start – stop cycles. In pick – and – place operations within the electronics manufacturing sector, where components need to be moved rapidly and precisely, the low – inertia design of this motor ensures minimal settling times and high – accuracy positioning, thus significantly enhancing production throughput.
The motor is equipped with an integrated high – resolution encoder that provides extremely accurate position feedback, with up to 262144 counts per revolution. This level of precision is indispensable for applications such as precision machining, where even the slightest deviation in the tool’s position can lead to defective products. In a CNC machining center, the high – resolution encoder of the MSK076C-0450-NN-M1-UG1-NNNN ensures that the cutting tool moves with sub – micron accuracy, resulting in the production of parts with tight tolerances.
In terms of environmental adaptability, the REXROTH MSK076C-0450-NN-M1-UG1-NNNNhas an IP65 protection rating. This means it is highly resistant to dust ingress and water splashing from any direction, making it suitable for use in a wide variety of industrial environments. Whether it’s a dusty foundry or a humid food processing plant, this motor can operate reliably. It can function within a temperature range of – 10°C to 45°C (with derating up to 55°C), further expanding its applicability across different manufacturing settings.
MSK076C-0450-NN-M1-UG1-NNNN
Technical specifications:
Model MSK076C-0450-NN-M1-UG1-NNNN
Brand REXROTH
Type High – Performance Servo Motor
Rated Power 2.2 kW
Rated Torque 2.5 Nm
Maximum Speed 4500 rpm
Voltage 400 V AC (three – phase)
Protection Rating IP65
Encoder Type High – resolution absolute (262144 counts/rev)
Mounting Flange (IEC 112, 71 mm)
Weight 11 kg
Operating Temperature – 10°C to 45°C (derated up to 55°C)
Cooling Natural convection with enhanced heat dissipation fins
Certifications CE, UL, CSA, ISO 14001 (environmental), ISO 45001 (occupational health and safety)
REXROTH IndraDrive Cs CSH04.1C – ET – EN1 – NNN – NN – S – NN – FW: This high – performance drive controller is specifically tailored for the REXROTH MSK076C – 0450 – NN – M1 – UG1 – NNNN. It enables seamless communication and precise control, allowing the motor to reach its full potential in terms of speed, torque, and positioning accuracy. The controller incorporates advanced motion control algorithms that can counteract external disturbances, ensuring smooth operation even in challenging industrial conditions. For example, in a high – vibration industrial environment, the controller’s algorithms can adjust the motor’s performance in real – time to maintain accurate motion.
REXROTH MSK050C – 0600 – NN – M1 – UG1 – NNNN: A smaller model in the MSK series, the MSK050C has a different speed – torque profile. It has a maximum speed of 6000 rpm but a lower rated torque of 1.2 Nm. In certain multi – axis systems, the MSK050C can be utilized for tasks that demand higher speed and less torque, while the REXROTH MSK076C – 0450 – NN – M1 – UG1 – NNNN takes care of the heavier – load and more torque – intensive operations. In a 3 – axis robotic arm system, the MSK050C might be used for the fast – moving joints that require less force, while the MSK076C is employed for the joints that need to support and move heavier payloads.
REXROTH R911310575: This is a high – quality servo cable designed to connect the REXROTH MSK076C – 0450 – NN – M1 – UG1 – NNNN to its drive. Constructed with special shielding materials, it effectively minimizes electromagnetic interference, guaranteeing stable and reliable signal transmission. In industrial settings teeming with numerous electrical devices, this cable plays a crucial role in maintaining the integrity of the motor’s control signals. In a large factory filled with multiple motors, variable frequency drives, and other electrical equipment, the R911310575 cable ensures that the control signals for the MSK076C motor remain undistorted, preventing any performance degradation.
REXROTH MKE076B – 144 – KP0 – KN: A coaxial motor often paired with the REXROTH MSK076C – 0450 – NN – M1 – UG1 – NNNN in complex multi – axis systems. The MKE076B can handle rotational tasks with high precision, complementing the linear positioning capabilities of the MSK076C. Together, they can enable a wide array of motion profiles in applications such as 5 – axis machining centers. In a 5 – axis milling machine, the MKE076B can precisely control the rotational movement of the workpiece, while the MSK076C controls the linear movements of the cutting tool, resulting in highly complex and accurate machining operations.
REXROTH HMI KTP1200 Basic: A user – friendly touch panel that offers an intuitive interface for monitoring and controlling the REXROTH MSK076C – 0450 – NN – M1 – UG1 – NNNN. It can display real – time data such as motor speed, torque, temperature, and encoder position. Additionally, it allows operators to adjust various motor parameters, set up motion profiles, and receive diagnostic alerts. In a standalone manufacturing cell, the KTP1200 Basic HMI provides operators with easy access to motor information and control, enabling them to quickly make adjustments and ensure optimal motor performance.
REXROTH R900052580: A high – precision zero – backlash coupling used to connect the REXROTH MSK076C – 0450 – NN – M1 – UG1 – NNNN to other mechanical components, such as lead screws or gears. This coupling ensures that there is no lost motion between the motor and the driven component, maximizing the transfer of torque and maintaining the accuracy of the motion control system. In a precision – positioning system for semiconductor manufacturing, the R900052580 coupling ensures that the motor’s motion is precisely transferred to the positioning stage, resulting in accurate placement of semiconductor wafers.
REXROTH IndraWorks Engineering Software 7.0: The latest iteration of Rexroth’s powerful engineering software suite, which is fully compatible with the REXROTH MSK076C – 0450 – NN – M1 – UG1 – NNNN. This software offers a plethora of features for motor configuration, motion profile tuning, and system diagnostics. It includes advanced simulation tools that allow engineers to test and optimize the performance of the motor and the overall system before physical implementation. With its intuitive user interface and comprehensive functionality, IndraWorks Engineering Software 7.0 simplifies the process of integrating the REXROTH MSK076C – 0450 – NN – M1 – UG1 – NNNN into complex industrial automation systems. For example, engineers can use the simulation tools to model different operating scenarios and fine – tune the motor’s performance parameters to achieve the best possible results in a real – world application.
Installation of the REXROTH MSK076C – 0450 – NN – M1 – UG1 – NNNN demands meticulous attention to detail to ensure optimal performance. Given its 11 kg weight, it is imperative to mount it on a rigid and flat surface. The mounting surface should have a maximum warpage of 0.02 mm to prevent any unwanted vibrations during high – speed operation. When using mounting screws, choose low – profile ones with a maximum length of 12 mm to avoid any interference with the motor’s internal components. Due to the motor’s high – resolution encoder and the need for stable signal transmission, proper cable management is of great significance. Route the encoder cables in a gentle arc with a minimum radius of 80 mm to prevent signal degradation. In environments where electromagnetic interference is a concern, such as near large electrical motors or power distribution panels, use shielded cables and ensure proper grounding. For applications in cleanrooms or other sensitive environments, verify that all mounting hardware and associated components are made of non – outgassing materials that comply with relevant cleanliness standards, such as ISO 7 for cleanrooms.
MSK076C-0450-NN-M1-UG1-NNNN
Installation and maintenance:
Maintenance of the REXROTH MSK076C-0450-NN-M1-UG1-NNNN is designed to be straightforward, yet regular checks are essential to uphold its high – performance capabilities. Conduct visual inspections on a monthly basis to look for any signs of physical damage, such as cracks in the housing or loose connections. Use a magnifying glass to inspect the encoder window for dust or debris, and clean it with a lint – free cloth dampened with isopropyl alcohol if necessary. The motor’s bearings are sealed for life, but it is advisable to monitor the motor for any unusual noises during operation. High – frequency noises may indicate bearing wear, especially in applications with high – cycle operation. Calibrate the encoder every six months using a laser interferometer to ensure that the position accuracy remains within ±1 micron. Keep an eye on the motor’s operating temperature, especially in high – load applications. Avoid exposing the motor to temperatures above 45°C for extended periods, as excessive heat can degrade the performance of the encoder and other internal components.
