REXROTH MSK040C-0600-NN-M1-UG1-NNNN High – Performance Servo Motor

The REXROTH MSK040C-0600-NN-M1-UG1-NNNN is a high – performance servo motor hailing from Bosch Rexroth’s advanced MSK series. It is meticulously crafted as a top – tier solution for complex motion control scenarios within the realm of industrial automation. In the era of Industry 4.0, where smart factories are becoming the norm, this motor serves as a vital cog in the machinery of connected manufacturing systems. It efficiently converts electrical energy into precisely controlled mechanical motion, working in seamless harmony with Rexroth’s state – of – the – art IndraDrive Cs and IndraDrive Mi controllers. Together, they are capable of executing intricate multi – axis motion profiles with sub – micron accuracy. What sets the REXROTH MSK040C-0600-NN-M1-UG1-NNNN apart is its optimized design for applications that require a balance of substantial torque and moderate speed, all within a relatively compact footprint. This makes it an ideal choice for integration into machinery where space is at a premium, yet high – performance motion control is non – negotiable, such as in automated inspection systems or high – precision material handling equipment. It fits snugly into Rexroth’s comprehensive modular automation ecosystem, being fully compatible with a wide range of precision linear actuators, gear reducers, and the latest IndraWorks Engineering Suite, which allows for in – depth motion tuning and system optimization. For engineers and system integrators looking to build cutting – edge manufacturing systems, the REXROTH MSK040C-0600-NN-M1-UG1-NNNN offers an unrivaled blend of performance features, making it a go – to option for applications where precision and reliability are paramount.

Model MSK040C-0600-NN-M1-UG1-NNNN
Brand REXROTH
Type High – Performance Servo Motor
Rated Power 0.65 kW
Rated Torque 0.8 Nm
Maximum Speed 6000 rpm
Voltage 400 V AC (three – phase)
Protection Rating IP65
Encoder Type High – resolution absolute (262144 counts/rev)
Mounting Flange (IEC 56, 40 mm)
Weight 2.8 kg
Operating Temperature – 10°C to 45°C (derated up to 55°C)
Cooling Natural convection with enhanced heat dissipation fins
Certifications CE, UL, CSA, ISO 14001 (environmental), ISO 45001 (occupational health and safety)

Description

The REXROTH MSK040C-0600-NN-M1-UG1-NNNN is a high – performance servo motor hailing from Bosch Rexroth’s advanced MSK series. It is meticulously crafted as a top – tier solution for complex motion control scenarios within the realm of industrial automation. In the era of Industry 4.0, where smart factories are becoming the norm, this motor serves as a vital cog in the machinery of connected manufacturing systems. It efficiently converts electrical energy into precisely controlled mechanical motion, working in seamless harmony with Rexroth’s state – of – the – art IndraDrive Cs and IndraDrive Mi controllers. Together, they are capable of executing intricate multi – axis motion profiles with sub – micron accuracy. What sets the REXROTH MSK040C-0600-NN-M1-UG1-NNNN apart is its optimized design for applications that require a balance of substantial torque and moderate speed, all within a relatively compact footprint. This makes it an ideal choice for integration into machinery where space is at a premium, yet high – performance motion control is non – negotiable, such as in automated inspection systems or high – precision material handling equipment. It fits snugly into Rexroth’s comprehensive modular automation ecosystem, being fully compatible with a wide range of precision linear actuators, gear reducers, and the latest IndraWorks Engineering Suite, which allows for in – depth motion tuning and system optimization. For engineers and system integrators looking to build cutting – edge manufacturing systems, the REXROTH MSK040C-0600-NN-M1-UG1-NNNN offers an unrivaled blend of performance features, making it a go – to option for applications where precision and reliability are paramount.

MSK040C-0600-NN-M1-UG1-NNNN

MSK040C-0600-NN-M1-UG1-NNNN





Main features and advantages:

The REXROTH MSK040C-0600-NN-M1-UG1-NNNN boasts several key performance features that make it stand out in the crowded servo motor market. Its rated torque of 0.8 Nm enables it to handle heavier loads with ease compared to some of its counterparts in the same size class. This is particularly advantageous in applications like heavy – duty robotic arms used in automotive part assembly, where the motor needs to lift and position large components with high precision. The motor can reach a maximum speed of 6000 rpm, providing a good balance between speed and torque for a variety of industrial processes. This speed – torque combination is well – suited for applications such as high – speed stamping machines, where rapid movement of the stamping head is required, but enough torque is needed to ensure a clean and accurate stamp.
The motor features a low – inertia design, which allows for quick acceleration and deceleration. This is crucial in applications that require rapid start – stop cycles, such as pick – and – place operations in electronics manufacturing. In these scenarios, the ability of the motor to change its speed rapidly without overshooting or oscillating is essential for maintaining high production rates and minimizing errors. The integrated high – resolution encoder provides extremely accurate position feedback, with up to 262144 counts per revolution. This level of precision ensures that the motor can be controlled with sub – micron accuracy, making it suitable for applications like micro – machining, where the slightest deviation in the tool’s position can result in a defective product.
In terms of environmental resilience, the REXROTH MSK040C-0600-NN-M1-UG1-NNNN has an IP65 protection rating. This means it is well – protected against dust ingress and water splashing from any direction, making it suitable for use in a wide range of industrial environments, including those with some degree of humidity or where cleaning operations involve water – based agents. The motor can operate reliably in temperatures ranging from – 10°C to 45°C (with derating up to 55°C), further expanding its applicability across different manufacturing settings.
MSK040C-0600-NN-M1-UG1-NNNN

MSK040C-0600-NN-M1-UG1-NNNN

Technical specifications:
Model MSK040C-0600-NN-M1-UG1-NNNN
Brand REXROTH
Type High – Performance Servo Motor
Rated Power 0.65 kW
Rated Torque 0.8 Nm
Maximum Speed 6000 rpm
Voltage 400 V AC (three – phase)
Protection Rating IP65
Encoder Type High – resolution absolute (262144 counts/rev)
Mounting Flange (IEC 56, 40 mm)
Weight 2.8 kg
Operating Temperature – 10°C to 45°C (derated up to 55°C)
Cooling Natural convection with enhanced heat dissipation fins
Certifications CE, UL, CSA, ISO 14001 (environmental), ISO 45001 (occupational health and safety)



contact us:
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq , com

MSK040C-0600-NN-M1-UG1-NNNN

MSK040C-0600-NN-M1-UG1-NNNN

Application areas:

REXROTH IndraDrive Cs CSH02.1C – ET – EN1 – NNN – NN – S – NN – FW – A high – performance drive controller specifically optimized for the REXROTH MSK040C – 0600 – NN – M1 – UG1 – NNNN. It enables seamless communication and precise control, allowing the motor to achieve its full potential in terms of speed, torque, and positioning accuracy. This controller is equipped with advanced algorithms for motion control, which can compensate for any external disturbances and ensure smooth operation even in challenging industrial environments.
REXROTH MSK030C – 0900 – NN – M1 – UG1 – NNNN – A smaller sibling in the MSK series, the MSK030C offers a different speed – torque profile. It has a higher maximum speed of 9000 rpm but a lower rated torque of 0.5 Nm. In some multi – axis systems, the MSK030C can be used for tasks that require higher speed and less torque, while the REXROTH MSK040C – 0600 – NN – M1 – UG1 – NNNN handles the heavier – load and more torque – intensive operations.
REXROTH R911310572 – A high – quality servo cable designed to connect the REXROTH MSK040C – 0600 – NN – M1 – UG1 – NNNN to its drive. This cable is constructed with special shielding materials to minimize electromagnetic interference, ensuring stable and reliable signal transmission. In industrial settings where there are numerous electrical devices operating simultaneously, this cable helps maintain the integrity of the motor’s control signals, preventing any signal degradation that could lead to performance issues.
REXROTH MKE040B – 144 – KP0 – KN – A coaxial motor that is often paired with the REXROTH MSK040C – 0600 – NN – M1 – UG1 – NNNN in complex multi – axis systems. The MKE040B can handle rotational tasks with high precision, complementing the linear positioning capabilities of the MSK040C. Together, they can enable a wide range of motion profiles in applications such as 5 – axis machining centers, where both linear and rotational movements need to be coordinated with sub – micron accuracy.
REXROTH HMI KTP700 Basic – A user – friendly touch panel that provides an intuitive interface for monitoring and controlling the REXROTH MSK040C – 0600 – NN – M1 – UG1 – NNNN. It can display real – time data such as motor speed, torque, temperature, and encoder position. In addition, it allows operators to adjust various motor parameters, set up motion profiles, and receive diagnostic alerts. This HMI is particularly useful in applications where easy access to motor information and control is required, such as in standalone manufacturing equipment or small – scale production lines.
REXROTH R900052578 – A high – precision zero – backlash coupling that is used to connect the REXROTH MSK040C – 0600 – NN – M1 – UG1 – NNNN to other mechanical components, such as lead screws or gears. This coupling ensures that there is no lost motion between the motor and the driven component, maximizing the transfer of torque and maintaining the accuracy of the motion control system. In applications where high – precision positioning is critical, such as in semiconductor wafer handling equipment, this coupling plays a vital role in ensuring the reliable operation of the system.
MSK040C-0600-NN-M1-UG1-NNNN

MSK040C-0600-NN-M1-UG1-NNNN



Installation and maintenance:

Installation of the REXROTH MSK040C-0600-NN-M1-UG1-NNNN requires careful attention to detail to ensure optimal performance. Given its 2.8 kg weight, it is essential to mount it on a rigid and flat surface. The mounting surface should have a maximum warpage of 0.015 mm to prevent any unwanted vibrations during high – speed operation. When using mounting screws, select low – profile ones with a maximum length of 10 mm to avoid any interference with the motor’s internal components. Due to the motor’s high – resolution encoder and the need for stable signal transmission, proper cable management is crucial. Route the encoder cables in a gentle arc with a minimum radius of 60 mm to prevent signal degradation. In environments where electromagnetic interference is a concern, such as near large electrical motors or power distribution panels, use shielded cables and ensure proper grounding. For applications in cleanrooms or other sensitive environments, verify that all mounting hardware and associated components are made of non – outgassing materials that comply with relevant cleanliness standards, such as ISO 7 for cleanrooms.
Maintenance of the REXROTH MSK040C-0600-NN-M1-UG1-NNNN is designed to be straightforward, yet regular checks are essential to maintain its high – performance capabilities. Conduct visual inspections on a monthly basis to check for any signs of physical damage, such as cracks in the housing or loose connections. Use a magnifying glass to inspect the encoder window for dust or debris, and clean it with a lint – free cloth dampened with isopropyl alcohol if necessary. The motor’s bearings are sealed for life, but it is advisable to monitor the motor for any unusual noises during operation. High – frequency noises may indicate bearing wear, especially in applications with high – cycle operation. Calibrate the encoder every six months using a laser interferometer to ensure that the position accuracy remains within ±1 micron. Keep an eye on the motor’s operating temperature, especially in high – load applications. Avoid exposing the motor to temperatures above 45°C for extended periods, as excessive heat can degrade the performance of the encoder and other internal components.
MSK040C-0600-NN-M1-UG1-NNNN

MSK040C-0600-NN-M1-UG1-NNNN
