REXROTH MSK030B-0900-NN-M1-UG0-NNNN Precision Servo Motor

The REXROTH MSK030B-0900-NN-M1-UG0-NNNN is a high-performance servo motor from Bosch Rexroth’s MSK series, engineered as a precision solution for micro-motion control systems. As a key component in decentralized automation setups, it converts electrical signals into exact mechanical movement, working alongside Rexroth’s IndraDrive Cs controllers to execute nanometer-level positioning tasks. Unlike larger industrial motors, it’s designed for applications where space is extremely limited—its compact frame allows integration into machinery where even millimeters matter, such as handheld robotic tools or benchtop testing equipment. It fits seamlessly into Rexroth’s modular automation ecosystem, compatible with precision gearboxes, linear stages, and programming software like IndraWorks. For engineers designing micro-manufacturing systems, the REXROTH MSK030B-0900-NN-M1-UG0-NNNN offers an unmatched combination of speed, precision, and small size, making it ideal for applications where accuracy defines success.

Model MSK030B-0900-NN-M1-UG0-NNNN
Brand REXROTH
Type Precision Servo Motor
Rated Power 0.37 kW
Rated Torque 0.4 Nm
Maximum Speed 9000 rpm
Voltage 230 V AC (single-phase)
Protection Rating IP64
Encoder Type High-resolution absolute (131072 counts/rev)
Mounting Flange (IEC 32, 30 mm)
Weight 1.6 kg
Operating Temperature 0°C to 40°C (derated up to 60°C)
Cooling Natural convection
Certifications CE, UL, CSA, ISO 13485 (medical grade)



Description

The REXROTH MSK030B-0900-NN-M1-UG0-NNNN is a high-performance servo motor from Bosch Rexroth’s MSK series, engineered as a precision solution for micro-motion control systems. As a key component in decentralized automation setups, it converts electrical signals into exact mechanical movement, working alongside Rexroth’s IndraDrive Cs controllers to execute nanometer-level positioning tasks. Unlike larger industrial motors, it’s designed for applications where space is extremely limited—its compact frame allows integration into machinery where even millimeters matter, such as handheld robotic tools or benchtop testing equipment. It fits seamlessly into Rexroth’s modular automation ecosystem, compatible with precision gearboxes, linear stages, and programming software like IndraWorks. For engineers designing micro-manufacturing systems, the REXROTH MSK030B-0900-NN-M1-UG0-NNNN offers an unmatched combination of speed, precision, and small size, making it ideal for applications where accuracy defines success.

MSK030B-0900-NN-M1-UG0-NNNN

MSK030B-0900-NN-M1-UG0-NNNN

Main features and advantages:

The REXROTH MSK030B-0900-NN-M1-UG0-NNNN stands out for its exceptional dynamic performance in a compact package. With a maximum speed of 9000 rpm, it delivers rapid yet controlled motion—critical for high-speed pick-and-place operations in electronics assembly, where cycle times measured in milliseconds determine production output. Its low-cogging design ensures smooth rotation, eliminating the small vibrations that could disrupt sensitive processes like optical fiber alignment, where misalignment of just a few microns causes signal loss. ​ In terms of hardware, the motor features a lightweight aluminum housing weighing only 1.6 kg, making it suitable for mounted applications like robotic arms where excess weight would reduce payload capacity. It operates reliably in temperatures ranging from 0 °C to 40°C (with derating up to 60° C) and carries an IP64 protection rating, shielding it from dust and splashes in cleanroom environments. The integrated high-resolution encoder provides position feedback down to 131072 counts per revolution, ensuring that even the smallest movements are tracked with pinpoint accuracy—essential for applications like laser engraving, where line smoothness depends on motor precision.

MSK030B-0900-NN-M1-UG0-NNNN

MSK030B-0900-NN-M1-UG0-NNNN

Technical specifications:
Model MSK030B-0900-NN-M1-UG0-NNNN
Brand REXROTH
Type Precision Servo Motor
Rated Power 0.37 kW
Rated Torque 0.4 Nm
Maximum Speed 9000 rpm
Voltage 230 V AC (single-phase)
Protection Rating IP64
Encoder Type High-resolution absolute (131072 counts/rev)
Mounting Flange (IEC 32, 30 mm)
Weight 1.6 kg
Operating Temperature 0°C to 40°C (derated up to 60°C)
Cooling Natural convection
Certifications CE, UL, CSA, ISO 13485 (medical grade)





contact us:
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq , com

MSK030B-0900-NN-M1-UG0-NNNN

MSK030B-0900-NN-M1-UG0-NNNN



Application areas:

In the world of precision manufacturing, where even the smallest movement can impact product quality, reliable motion control is non-negotiable. Consider the production of medical devices, where tiny components like pacemaker parts require assembly with micron-level accuracy. Or look to the semiconductor industry, where wafer handling robots must move delicate substrates without generating particles that could ruin expensive chips. Even in high-end 3D printing, where layer consistency determines part strength, motors need to deliver smooth, jerk-free motion. This is where the REXROTH MSK030B-0900-NN-M1-UG0-NNNNexcels. Designed for industrial automation scenarios demanding ultra-precise positioning in compact spaces, it delivers the speed and accuracy needed for micro-manufacturing and delicate handling applications. Whether integrated into lab automation equipment or high-precision assembly lines, the REXROTH MSK030B-0900-NN-M1-UG0-NNNN proves that small-scale motion control can achieve big results.

MSK030B-0900-NN-M1-UG0-NNNN

MSK030B-0900-NN-M1-UG0-NNNN

Related products:

REXROTH IndraDrive Cs CSH01.1C-ET-EN1-NNN-NN-S-NN-FW – Compact drive controller optimized for the REXROTH MSK030B-0900-NN-M1-UG0-NNNN, enabling nanometer-level motion control in precision systems.
REXROTH MSK020B-0300-NN-M1-UG0-NNNN – Smaller sibling in the MSK series, offering 3000 rpm for applications requiring lower speed than the REXROTH MSK030B-0900-NN-M1-UG0-NNNN.
REXROTH R911310570 – Ultra-thin servo cable designed to connect the REXROTH MSK030B-0900-NN-M1-UG0-NNNN to its drive in space-constrained cleanrooms, minimizing particle generation.
REXROTH MKE025B-144-KP0-KN – Coaxial motor often paired with the REXROTH MSK030B-0900-NN-M1-UG0-NNNN in multi-axis systems, handling rotational tasks while the MSK manages linear positioning.
REXROTH HMI KTP400 Basic – Compact touch panel that monitors the REXROTH MSK030B-0900-NN-M1-UG0-NNNN’s performance, ideal for benchtop equipment with limited interface space.
REXROTH R900052576 – Miniature zero-backlash coupling for connecting the REXROTH MSK030B-0900-NN-M1-UG0-NNNN to precision lead screws, ensuring no lost motion in linear stages.
MSK030B-0900-NN-M1-UG0-NNNN

MSK030B-0900-NN-M1-UG0-NNNN



Installation and maintenance:

Before installing the REXROTH MSK030B-0900-NN-M1-UG0-NNNN, ensure the mounting surface is perfectly flat—even 0.02 mm of warpage can amplify vibration in high-speed operation. Use low-profile mounting screws with a maximum length of 8 mm to avoid protruding into the motor’s internal components. The motor’s compact size requires careful cable management; route encoder cables in a gentle arc (minimum radius 50 mm) to prevent signal degradation. In cleanroom environments, verify that all mounting hardware is made of non-outgassing materials compatible with ISO 8 standards.
Maintenance for the REXROTH MSK030B-0900-NN-M1-UG0-NNNN focuses on preserving its precision. Conduct monthly inspections using a microscope to check for dust on the encoder window—use a lint-free cloth dampened with isopropyl alcohol to clean if needed. The motor’s bearings are sealed for life, but listen for high-frequency noise during operation, which may indicate bearing wear in high-cycle applications. Calibrate the encoder quarterly using a laser interferometer to ensure position accuracy remains within ±2 microns. Avoid exposing the motor to temperatures above 40°C for extended periods, as heat can degrade the encoder’s optical components.
