REXROTH MKD071B-061-KP1-KN Compact Servo Motor

The REXROTH MKD071B-061-KP1-KN is a compact servo motor from Bosch Rexroth’s MKD series, engineered to serve as a versatile solution in space-constrained motion control systems. As a key component in both centralized and distributed automation setups, it converts electrical energy into precise mechanical motion, working in tandem with Rexroth’s IndraDrive Micro and IndraDrive Cs controllers to execute complex movement profiles. What sets it apart from its KG1-KN counterpart is its optimized design for tighter installations—maintaining the same core power while featuring a modified flange configuration that simplifies integration into compact machinery. It fits seamlessly into Rexroth’s modular automation ecosystem, compatible with a range of drives, HMIs, and programming tools. For engineers designing space-constrained systems, the REXROTH MKD071B-061-KP1-KN offers a unique blend of torque, precision, and compactness, making it ideal for applications where every millimeter counts.

Model MKD071B-061-KP1-KN
Brand REXROTH
Type Compact Servo Motor
Rated Power 1.8 kW
Rated Torque 6.1 Nm
Rated Speed 3000 rpm
Maximum Speed 4500 rpm
Voltage 400 V AC (3-phase)
Protection Rating IP65
Encoder Type Single-turn absolute
Mounting Flange (IEC 72, 71 mm compact design)
Weight 9.2 kg
Operating Temperature 0°C to 40°C (derated up to 60°C)
Cooling Natural convection
Certifications CE, UL, CSA

Description

The REXROTH MKD071B-061-KP1-KN is a compact servo motor from Bosch Rexroth’s MKD series, engineered to serve as a versatile solution in space-constrained motion control systems. As a key component in both centralized and distributed automation setups, it converts electrical energy into precise mechanical motion, working in tandem with Rexroth’s IndraDrive Micro and IndraDrive Cs controllers to execute complex movement profiles. What sets it apart from its KG1-KN counterpart is its optimized design for tighter installations—maintaining the same core power while featuring a modified flange configuration that simplifies integration into compact machinery. It fits seamlessly into Rexroth’s modular automation ecosystem, compatible with a range of drives, HMIs, and programming tools. For engineers designing space-constrained systems, the REXROTH MKD071B-061-KP1-KN offers a unique blend of torque, precision, and compactness, making it ideal for applications where every millimeter counts.

MKD071B-061-KP1-KN

MKD071B-061-KP1-KN

Main features and advantages:

The REXROTH MKD071B-061-KP1-KN stands out for its impressive torque density, delivering 6.1 Nm of rated torque in a package that’s tailored for tight spaces. This makes it perfect for applications like robotic arms in electronics assembly, where the motor must generate enough force to handle circuit boards and components while fitting within the arm’s slender structure. Its low-inertia rotor design enables rapid acceleration—critical for pick-and-place mechanisms that need to switch between positions in milliseconds without sacrificing accuracy.
In terms of hardware, the motor features a durable cast aluminum housing that weighs just 9.2 kg, slightly lighter than the KG1-KN variant, to ease installation in overhead or wall-mounted setups. It operates reliably in temperatures ranging from 0°C to 40°C (with derating up to 60°C) and carries an IP65 protection rating, making it suitable for use in environments with light dust or occasional moisture, such as pharmaceutical packaging rooms. The integrated single-turn encoder provides precise position feedback, ensuring that even the smallest adjustments—like those needed in 3D printing extruders—are tracked with accuracy. Unlike the multi-turn encoder in the KG1-KN model, this single-turn design simplifies wiring in compact enclosures, reducing cable clutter.
MKD071B-061-KP1-KN

MKD071B-061-KP1-KN



Technical specifications:
Model MKD071B-061-KP1-KN
Brand REXROTH
Type Compact Servo Motor
Rated Power 1.8 kW
Rated Torque 6.1 Nm
Rated Speed 3000 rpm
Maximum Speed 4500 rpm
Voltage 400 V AC (3-phase)
Protection Rating IP65
Encoder Type Single-turn absolute
Mounting Flange (IEC 72, 71 mm compact design)
Weight 9.2 kg
Operating Temperature 0°C to 40°C (derated up to 60°C)
Cooling Natural convection
Certifications CE, UL, CSA





contact us:
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq , com

MKD071B-061-KP1-KN

MKD071B-061-KP1-KN



Application areas:

In the realm of industrial automation, where precision and adaptability are paramount, certain applications demand motors that can deliver robust performance while fitting into constrained spaces. Consider the electronics manufacturing sector, where automated circuit board testers require motors to maneuver probes with pinpoint accuracy in tight enclosures. Or look to packaging machinery for cosmetics, where compact yet powerful motors must drive conveyor belts and labeling mechanisms without compromising the machine’s sleek design. Even in laboratory automation, where benchtop robots handle delicate samples, space is at a premium, and motors must balance power with a small footprint. This is where the REXROTH MKD071B-061-KP1-KN excels. Designed for industrial automation scenarios where space constraints meet medium-heavy load demands, it delivers the torque needed for reliable operation while maintaining a compact form. Whether integrated into precision testing equipment or space-saving production lines, the REXROTHMKD071B-061-KP1-KN proves that power and size can coexist effectively.

MKD071B-061-KP1-KN

MKD071B-061-KP1-KN

Related products:

REXROTH IndraDrive Micro CMM01.1-040-300-NNN-220-PE – Compact drive controller optimized for the REXROTH MKD071B-061-KP1-KN, ideal for space-constrained systems where both motor and drive must fit in tight enclosures.
REXROTH MKD041B-144-KP0-UN – Smaller sibling in the MKD series, often paired with the REXROTH MKD071B-061-KP1-KN in multi-axis compact systems, handling lighter loads while the KP1-KN manages heavier tasks.
REXROTH R911310569 – Slim-profile servo cable designed to connect the REXROTH MKD071B-061-KP1-KN to its drive in tight spaces, reducing cable bulk and minimizing interference.
REXROTH HMI MTX Micro – Miniature touch panel that monitors and adjusts the REXROTH MKD071B-061-KP1-KN’s performance, perfect for benchtop machinery with limited control panel space.
REXROTH HVE04.2-W110N – Power supply module that pairs with the REXROTH MKD071B-061-KP1-KN in compact systems, delivering stable power without excessive size.
REXROTH R900052575 – Low-profile coupling designed to connect the REXROTH MKD071B-061-KP1-KN to small-diameter shafts in tight gearboxes, ensuring efficient power transfer.
REXROTH IndraWorks Engineering Software – Enables programming of the REXROTH MKD071B-061-KP1-KN, with tools to optimize motion profiles for space-constrained applications.
MKD071B-061-KP1-KN

MKD071B-061-KP1-KN



Installation and maintenance:

Before installing the REXROTH MKD071B-061-KP1-KN, verify that the mounting surface can support its 9.2 kg weight without flexing—even minor vibrations in compact enclosures can amplify, affecting precision. Its compact flange design requires careful alignment; use a dial indicator to ensure parallelism within 0.05 mm per 100 mm to prevent shaft stress. The motor’s IP65 rating allows for use in damp environments, but ensure cable entries face downward to avoid moisture pooling at connections. In systems with multiple compact motors, route encoder cables through dedicated conduits to minimize interference in the confined space.
Maintenance for the REXROTH MKD071B-061-KP1-KN focuses on preserving performance in tight quarters. Conduct bi-monthly visual inspections to check for dust buildup around the encoder port, which can block signals—use compressed air at 2 bar to clean, avoiding direct blasts on the connector. The motor’s bearings are lifetime-lubricated, but unusual noise may indicate misalignment, common in compact setups; address promptly to prevent damage. Verify encoder calibration quarterly using the drive’s diagnostics, as position drift in tight spaces can compound quickly. Clean the housing with a dry cloth, avoiding chemical cleaners that can degrade the compact flange’s protective coating.
