REXROTH MKD071B-061-KG1-KN Servo Motor

The REXROTH MKD071B-061-KG1-KN is a standout servo motor within Bosch Rexroth’s esteemed MKD series. Engineered with meticulous attention to detail, it is designed to be a workhorse in medium – to – heavy – duty motion control systems. As an integral part of both centralized and decentralized automation architectures, it efficiently transforms electrical energy into highly accurate mechanical motion. It collaborates seamlessly with Rexroth’s IndraDrive Cs and IndraDrive Mi controllers, enabling the execution of complex movement patterns. Compared to smaller servo motors, it offers a significant boost in torque capacity, allowing it to manage substantial loads. At the same time, it maintains a relatively compact form factor when contrasted with large – scale industrial motors, making it a top choice for installations where space is at a premium but high – performance operation is non – negotiable. It fits right into Rexroth’s modular automation ecosystem, being compatible with a broad range of drives, human – machine interfaces (HMIs), and programming software. For engineers tasked with designing industrial systems of different scales, the REXROTH MKD071B-061-KG1-KN presents an appealing option with its blend of power, precision, and adaptability, ensuring it can meet the stringent demands of diverse industrial applications.

Model MKD071B-061-KG1-KN
Brand REXROTH
Type Servo Motor
Rated Power 1.8 kW
Rated Torque 6.1 Nm
Rated Speed 3000 rpm
Maximum Speed 4500 rpm
Voltage 400 V AC (3 – phase)
Protection Rating IP65
Encoder Type Multi – turn absolute
Mounting Flange (IEC 94, 71 mm)
Weight 9.5 kg
Operating Temperature 0°C to 40°C (derated up to 60°C)
Cooling Natural convection
Certifications CE, UL, CSA

Description

The REXROTH MKD071B-061-KG1-KN is a standout servo motor within Bosch Rexroth’s esteemed MKD series. Engineered with meticulous attention to detail, it is designed to be a workhorse in medium – to – heavy – duty motion control systems. As an integral part of both centralized and decentralized automation architectures, it efficiently transforms electrical energy into highly accurate mechanical motion. It collaborates seamlessly with Rexroth’s IndraDrive Cs and IndraDrive Mi controllers, enabling the execution of complex movement patterns. Compared to smaller servo motors, it offers a significant boost in torque capacity, allowing it to manage substantial loads. At the same time, it maintains a relatively compact form factor when contrasted with large – scale industrial motors, making it a top choice for installations where space is at a premium but high – performance operation is non – negotiable. It fits right into Rexroth’s modular automation ecosystem, being compatible with a broad range of drives, human – machine interfaces (HMIs), and programming software. For engineers tasked with designing industrial systems of different scales, the REXROTH MKD071B-061-KG1-KN presents an appealing option with its blend of power, precision, and adaptability, ensuring it can meet the stringent demands of diverse industrial applications.

MKD071B-061-KG1-KN

MKD071B-061-KG1-KN





Main features and advantages:

One of the most impressive aspects of the REXROTH MKD071B-061-KG1-KN is its remarkable torque output and dynamic response. With a rated torque of 6.1 Nm, it can effortlessly handle medium – to – heavy loads, making it an excellent choice for applications such as large – scale conveyor systems in major distribution centers. These conveyor systems need to move vast quantities of goods continuously, and the high torque of this motor ensures smooth and reliable operation. Additionally, its advanced motor design enables rapid acceleration and deceleration. This is crucial in applications like high – speed pick – and – place operations in the electronics manufacturing sector. Here, quick and accurate positioning is essential to keep up with high production rates and ensure the flawless assembly of delicate components.
The motor is constructed with a durable cast aluminum housing, which offers robustness without adding excessive weight, tipping the scales at around 9.5 kg. It operates dependably within a temperature range of 0°C to 40°C (with derating up to 60°C) and features an IP65 protection rating. This makes it suitable for use in environments where there is a presence of light dust or moisture, such as in food processing plants where equipment may be regularly cleaned to maintain hygiene standards. The integrated multi – turn encoder provides highly detailed position feedback. This ensures that even during extended periods of operation and repeated movement cycles, the motor maintains consistent accuracy. This level of accuracy is vital for applications that demand batch – to – batch consistency, such as in the production of precision – engineered parts.
Compatibility is a key strength of the REXROTH MKD071B-061-KG1-KN. It integrates smoothly with Rexroth’s IndraDrive Cs and IndraDrive Mi controllers. Moreover, it supports communication protocols like PROFINET and CANopen, which are essential for seamless integration into modern Industry 4.0 systems. This flexibility allows it to work in harmony with other components within the MKD series, as well as larger motors from different Rexroth product lines, such as the MHD132C – 070 – PG1 – BA. This creates scalable motion control solutions that can be customized to meet evolving production requirements.
MKD071B-061-KG1-KN

MKD071B-061-KG1-KN

Technical specifications:
Model MKD071B-061-KG1-KN
Brand REXROTH
Type Servo Motor
Rated Power 1.8 kW
Rated Torque 6.1 Nm
Rated Speed 3000 rpm
Maximum Speed 4500 rpm
Voltage 400 V AC (3 – phase)
Protection Rating IP65
Encoder Type Multi – turn absolute
Mounting Flange (IEC 94, 71 mm)
Weight 9.5 kg
Operating Temperature 0°C to 40°C (derated up to 60°C)
Cooling Natural convection
Certifications CE, UL, CSA





contact us:
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq , com

MKD071B-061-KG1-KN

MKD071B-061-KG1-KN

Application areas:

In the bustling world of industrial automation, the search for a motor that can handle a wide array of complex tasks with precision and power is constant. Take the automotive manufacturing industry, for example. In the assembly line, robotic arms need to precisely position and attach various components, from delicate electrical parts to heavy engine components. The motors powering these arms must offer a high degree of torque to lift and move the parts while maintaining pinpoint accuracy to ensure a perfect fit. Similarly, in the packaging industry for large – scale products, motors are required to handle the continuous movement of heavy boxes and pallets, all while ensuring smooth transitions and accurate positioning for labeling and sealing operations. This is where the REXROTH MKD071B-061-KG1-KN steps in. It has found its niche in a variety of industrial automation scenarios, providing an ideal combination of strength and finesse. Whether it’s integrated into high – speed production lines or intricate material handling systems, this servo motor has proven its worth in mid – to – high – end industrial operations.

MKD071B-061-KG1-KN

MKD071B-061-KG1-KN



Related products:

REXROTH IndraDrive Cs CSH01.1C – ET – EN1 – NNN – NN – S – NN – FW – This drive controller is an ideal match for the REXROTH MKD071B – 061 – KG1 – KN, optimizing torque and speed control for medium – to – heavy – duty applications. It allows for precise regulation of the motor’s performance, ensuring efficient operation across a wide range of industrial scenarios.
REXROTH MKD041B – 144 – KG1 – KN – A smaller – capacity motor in the MKD series, often used in tandem with the REXROTH MKD071B – 061 – KG1 – KN in systems where different levels of load handling and precision are required. Together, they can form a versatile motion control solution for complex industrial processes.
REXROTH R911306029 – A high – quality shielded servo cable designed specifically to connect the REXROTH MKD071B – 061 – KG1 – KN to its drive. It ensures reliable signal transmission even in electrically noisy industrial environments, minimizing the risk of interference that could impact the motor’s performance.
REXROTH HMI Comfort Panel KTP1200 – This touch – based human – machine interface allows operators to easily monitor and adjust the performance parameters of the REXROTH MKD071B – 061 – KG1 – KN in real – time. It is particularly useful for mid – to – large – scale machinery control stations, providing an intuitive interface for operators to manage motor operations.
REXROTH HVE04.2 – W150N – A power supply module that pairs well with the REXROTH MKD071B – 061 – KG1 – KN in larger systems. It supplies stable power to the drive controller, ensuring consistent and reliable motor operation, even under varying load conditions.
REXROTH R900946849 – A specially designed mounting bracket simplifies the installation of the REXROTH MKD071B – 061 – KG1 – KN, especially in tight – space applications. It helps ensure proper alignment with the driven equipment, reducing the risk of misalignment – related issues such as premature wear and inefficiencies in power transmission.
MKD071B-061-KG1-KN

MKD071B-061-KG1-KN



Installation and maintenance:

Before installing the REXROTH MKD071B-061-KG1-KN, it is of utmost importance to ensure that the mounting surface can support its 9.5 kg weight without any vibration. Uneven mounting can lead to premature bearing failure and a significant reduction in the motor’s lifespan. Use a precision laser alignment tool to ensure concentricity within 0.1 mm when aligning the motor with the driven load. This reduces shaft stress during operation and improves the overall efficiency of power transmission. The motor’s IP65 protection rating allows for use in environments with light dust or moisture, but it is crucial to ensure that cable entries are properly sealed using compatible glands. This helps maintain the protection rating and prevents the ingress of contaminants that could potentially damage the motor. In systems with multiple motors, carefully route encoder cables separately from power cables. This minimizes electromagnetic interference, which could otherwise affect the accuracy of the encoder’s position feedback and, in turn, the motor’s positioning accuracy.
Maintenance of the REXROTHMKD071B-061-KG1-KN is centered around preserving its high – performance capabilities over the long haul. Conduct monthly visual inspections to check for any loose connections or signs of overheating, such as discolored wiring. Although the motor’s bearings are lifetime – lubricated, any unusual noise during operation should be investigated immediately. This could be an indication of misalignment or excessive load, both of which can cause damage if left unattended. Use the drive’s diagnostic tools to verify the encoder’s functionality quarterly. This ensures that the position feedback remains accurate, which is critical for applications that rely on precise positioning. When cleaning the motor’s exterior, use a dry cloth. Avoid using high – pressure water jets or harsh chemical cleaners, as these can damage the housing’s protective coating and compromise the IP65 protection rating over time.
