REXROTH MKD071B-035-KG1-KN Servo Motor

The REXROTH MKD071B-035-KG1-KN is a servo motor from Bosch Rexroth’s MKD series, meticulously engineered to be a reliable performer in medium to heavy-duty motion control systems. As a crucial part of both centralized and decentralized automation frameworks, it efficiently converts electrical energy into highly precise mechanical motion. It works in harmony with Rexroth’s IndraDrive Cs and IndraDrive Mi controllers, enabling the execution of intricate movement sequences. Distinguished from smaller servo motors, it packs a punch with its increased torque capacity, allowing it to manage heavier loads. At the same time, it retains a relatively compact footprint compared to large industrial motors, making it suitable for installations where space constraints are a concern but performance cannot be sacrificed. It seamlessly integrates into Rexroth’s modular automation ecosystem, being compatible with a wide array of drives, human – machine interfaces (HMIs), and programming software. For engineers engaged in designing industrial systems of varying scales, the REXROTH MKD071B-035-KG1-KN presents an attractive proposition with its combination of power, precision, and adaptability, ensuring it can meet the exacting demands of diverse industrial applications.

Model MKD071B-035-KG1-KN
Brand REXROTH
Type Servo Motor
Rated Power 1.1 kW
Rated Torque 3.5 Nm
Rated Speed 3000 rpm
Maximum Speed 4500 rpm
Voltage 400 V AC (3 – phase)
Protection Rating IP65
Encoder Type Multi – turn absolute
Mounting Flange (IEC 94, 71 mm)
Weight 7.8 kg
Operating Temperature 0°C to 40°C (derated up to 60°C)
Cooling Natural convection
Certifications CE, UL, CSA

Description

The REXROTH MKD071B-035-KG1-KN is a servo motor from Bosch Rexroth’s MKD series, meticulously engineered to be a reliable performer in medium to heavy-duty motion control systems. As a crucial part of both centralized and decentralized automation frameworks, it efficiently converts electrical energy into highly precise mechanical motion. It works in harmony with Rexroth’s IndraDrive Cs and IndraDrive Mi controllers, enabling the execution of intricate movement sequences. Distinguished from smaller servo motors, it packs a punch with its increased torque capacity, allowing it to manage heavier loads. At the same time, it retains a relatively compact footprint compared to large industrial motors, making it suitable for installations where space constraints are a concern but performance cannot be sacrificed. It seamlessly integrates into Rexroth’s modular automation ecosystem, being compatible with a wide array of drives, human – machine interfaces (HMIs), and programming software. For engineers engaged in designing industrial systems of varying scales, the REXROTH MKD071B-035-KG1-KN presents an attractive proposition with its combination of power, precision, and adaptability, ensuring it can meet the exacting demands of diverse industrial applications.

MKD071B-035-KG1-KN

MKD071B-035-KG1-KN



Main features and advantages:

The REXROTH MKD071B-035-KG1-KN stands out for its remarkable torque output and dynamic performance. With a rated torque of 3.5 Nm, it can effortlessly handle medium to heavy loads, making it a top choice for applications such as conveyor systems in logistics centers that need to move large volumes of goods continuously. Its advanced motor design allows for rapid acceleration and deceleration, which is essential in applications like pick – and – place robots in electronics manufacturing, where quick and accurate positioning is required to meet high production rates.
Constructed with a durable cast aluminum housing, the motor offers robustness without adding excessive mass, weighing approximately 7.8 kg. It operates dependably within a temperature range of 0°C to 40°C (with derating up to 60°C) and features an IP65 protection rating. This makes it suitable for use in environments where there is a presence of light dust or moisture, such as in food and beverage production facilities where equipment may be subject to periodic cleaning. The integrated multi – turn encoder provides highly detailed position feedback. This ensures that even during extended operation and repeated movements, the motor maintains consistent accuracy, which is vital for applications that require batch – to – batch consistency, like in the production of precision components.
Compatibility is one of the key strengths of the REXROTH MKD071B-035-KG1-KN. It integrates smoothly with Rexroth’s IndraDrive Cs and IndraDrive Mi controllers. It also supports communication protocols like PROFINET and CANopen, which are fundamental for seamless integration into modern Industry 4.0 systems. This flexibility enables it to work in tandem with other components within the MKD series, as well as larger motors from different Rexroth product lines, such as the MHD115C – 058 – PG1 – BA. This creates scalable motion control solutions that can be tailored to evolving production requirements.
MKD071B-035-KG1-KN

MKD071B-035-KG1-KN



Technical specifications:
Model MKD071B-035-KG1-KN
Brand REXROTH
Type Servo Motor
Rated Power 1.1 kW
Rated Torque 3.5 Nm
Rated Speed 3000 rpm
Maximum Speed 4500 rpm
Voltage 400 V AC (3 – phase)
Protection Rating IP65
Encoder Type Multi – turn absolute
Mounting Flange (IEC 94, 71 mm)
Weight 7.8 kg
Operating Temperature 0°C to 40°C (derated up to 60°C)
Cooling Natural convection
Certifications CE, UL, CSA





contact us:
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq , com

MKD071B-035-KG1-KN

MKD071B-035-KG1-KN

Application areas:

In the dynamic landscape of industrial automation, the demand for motors that can handle a diverse range of tasks with finesse is ever-present. Consider the pharmaceutical industry, where tablet presses require motors to deliver consistent pressure for uniform tablet formation, ensuring each dose is of the correct strength. In the printing industry, web-fed presses rely on motors to precisely control the speed and tension of the paper, preventing misprints and material jams. Even in automated storage and retrieval systems, motors must provide smooth and accurate movement to locate and transport goods within warehouses efficiently. This is where the REXROTH MKD071B-035-KG1-KN comes into play. Widely used in industrial automation across these sectors, it offers a blend of power and precision, making it an excellent choice for applications that need to strike a balance between handling substantial loads and achieving high levels of accuracy. Whether integrated into high-speed production lines or complex material handling setups, the REXROTH MKD071B-035-KG1-KN proves its mettle in mid to high – end industrial operations.

MKD071B-035-KG1-KN

MKD071B-035-KG1-KN

Related products:

REXROTH IndraDrive Cs CSH01.1C – ET – EN1 – NNN – NN – S – NN – FW – This drive controller is perfectly matched to the REXROTH MKD071B-035-KG1-KN, optimizing torque and speed control for medium to heavy – duty applications. It enables precise regulation of the motor’s performance, ensuring efficient operation in various industrial scenarios.
REXROTH MKD041B-144-KG1-KN – A smaller – capacity sibling in the MKD series, often used in combination with the REXROTH MKD071B-035-KG1-KN in systems where different levels of load handling and precision are required. Together, they can form a versatile motion control solution for complex industrial processes.
REXROTH R911306029 – A high – quality shielded servo cable designed specifically to connect the REXROTH MKD071B-035-KG1-KN to its drive. It ensures reliable signal transmission even in electrically noisy industrial environments, minimizing the risk of interference that could affect the motor’s performance.
REXROTH HMI Comfort Panel KTP1200 – This touch – based human – machine interface allows operators to easily monitor and adjust the performance parameters of the REXROTH MKD071B-035-KG1-KN in real – time. It is particularly useful for mid to large – scale machinery control stations, providing an intuitive interface for operators to manage motor operations.
REXROTH HVE04.2 – W110N – A power supply module that pairs well with the REXROTH MKD071B-035-KG1-KN in larger systems. It supplies stable power to the drive controller, ensuring consistent and reliable motor operation, even under varying load conditions.
REXROTH R900946849 – A specially designed mounting bracket simplifies the installation of the REXROTH MKD071B-035-KG1-KN, especially in tight – space applications. It helps ensure proper alignment with the driven equipment, reducing the risk of misalignment – related issues such as premature wear and inefficiencies in power transmission.
MKD071B-035-KG1-KN

MKD071B-035-KG1-KN



Installation and maintenance:

Before installing the REXROTH MKD071B-035-KG1-KN, it is crucial to verify that the mounting surface can support its 7.8 kg weight without any vibration. Uneven mounting can lead to premature bearing failure and reduced motor lifespan. Use a precision laser alignment tool to ensure concentricity within 0.1 mm when aligning the motor with the driven load. This reduces shaft stress during operation and improves the overall efficiency of power transmission. The motor’s IP65 protection rating allows for use in environments with light dust or moisture, but it is essential to ensure that cable entries are properly sealed using compatible glands. This helps maintain the protection rating and prevents the ingress of contaminants that could damage the motor. In systems with multiple motors, carefully route encoder cables separately from power cables. This minimizes electromagnetic interference, which can otherwise affect the accuracy of the encoder’s position feedback and, in turn, the motor’s positioning accuracy.
Maintenance of the REXROTH MKD071B-035-KG1-KN is focused on preserving its high – performance capabilities over the long term. Conduct monthly visual inspections to check for any loose connections or signs of overheating, such as discolored wiring. Although the motor’s bearings are lifetime – lubricated, any unusual noise during operation should be investigated promptly. This could be an indication of misalignment or excessive load, both of which can cause damage if left unaddressed. Use the drive’s diagnostic tools to verify the encoder’s functionality quarterly. This ensures that the position feedback remains accurate, which is critical for applications that rely on precise positioning. When cleaning the motor’s exterior, use a dry cloth. Avoid using high – pressure water jets or harsh chemical cleaners, as these can damage the housing’s protective coating and compromise the IP65 protection rating over time.
