Sale!

REXROTH MHD115C-058-PG1-BA Servo Motor

The REXROTH MHD115C-058-PG1-BA is a high-performance servo motor from Bosch Rexroth’s MHD series, designed to serve as the muscle behind advanced motion control systems. As a key component in servo drive architectures, it converts electrical energy into precise mechanical motion, working in tandem with Rexroth’s IndraDrive controllers to execute complex movement profiles. Unlike general-purpose motors, it’s engineered for dynamic response—quick acceleration, precise speed regulation, and accurate position holding—making it ideal for applications where motion quality directly impacts product quality. It fits seamlessly into Rexroth’s modular automation platform, compatible with both centralized and distributed control systems. For engineers and integrators, the REXROTH MHD115C-058-PG1-BA represents a balance of power and precision, eliminating the need to sacrifice one for the other in demanding industrial environments.

Model MHD115C-058-PG1-BA
Brand REXROTH
Type Servo Motor
Rated Power 7.5 kW
Rated Torque 58 Nm
Rated Speed 1200 rpm
Maximum Speed 3000 rpm
Voltage 400 V AC (3-phase)
Protection Rating IP65
Encoder Type Absolute multiturn
Mounting Flange (IEC 112, 115 mm)
Weight 38 kg
Operating Temperature 0°C to 40°C (derated up to 60°C)
Cooling Natural convection
Certifications CE, UL, CSA

Description

The REXROTH MHD115C-058-PG1-BA is a high-performance servo motor from Bosch Rexroth’s MHD series, designed to serve as the muscle behind advanced motion control systems. As a key component in servo drive architectures, it converts electrical energy into precise mechanical motion, working in tandem with Rexroth’s IndraDrive controllers to execute complex movement profiles. Unlike general-purpose motors, it’s engineered for dynamic response—quick acceleration, precise speed regulation, and accurate position holding—making it ideal for applications where motion quality directly impacts product quality. It fits seamlessly into Rexroth’s modular automation platform, compatible with both centralized and distributed control systems. For engineers and integrators, the REXROTH MHD115C-058-PG1-BA represents a balance of power and precision, eliminating the need to sacrifice one for the other in demanding industrial environments.

MHD115C-058-PG1-BA

MHD115C-058-PG1-BA

Main features and advantages:

The REXROTH MHD115C-058-PG1-BA stands out for its dynamic performance characteristics. Its high torque-to-inertia ratio allows for rapid acceleration and deceleration, critical in applications like packaging machinery where frequent starts and stops are required. Even under varying loads, it maintains speed stability within 0.1% of setpoint, ensuring consistent output in processes like conveyor synchronization.
In terms of hardware, the motor features a rugged cast aluminum housing that withstands vibration up to 10g and operates reliably in temperatures ranging from 0°C to 40°C (with derating up to 60°C). Its IP65 protection rating makes it suitable for use in dusty or moderately humid environments, such as food processing facilities with regular washdowns (when paired with appropriate cable glands). The integrated encoder provides high-resolution feedback—up to 2048 pulses per revolution—enabling the control system to make real-time adjustments for pinpoint accuracy.
Compatibility is another strength. The REXROTH MHD115C-058-PG1-BA integrates seamlessly with Rexroth’s IndraDrive Cs and IndraDrive Mi controllers, supporting both analog and digital communication protocols like PROFINET and CANopen. This flexibility allows it to fit into diverse automation ecosystems, from legacy systems to cutting-edge Industry 4.0 setups.
MHD115C-058-PG1-BA

MHD115C-058-PG1-BA





Technical specifications:
Model MHD115C-058-PG1-BA
Brand REXROTH
Type Servo Motor
Rated Power 7.5 kW
Rated Torque 58 Nm
Rated Speed 1200 rpm
Maximum Speed 3000 rpm
Voltage 400 V AC (3-phase)
Protection Rating IP65
Encoder Type Absolute multiturn
Mounting Flange (IEC 112, 115 mm)
Weight 38 kg
Operating Temperature 0°C to 40°C (derated up to 60°C)
Cooling Natural convection
Certifications CE, UL, CSA



contact us:
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq , com

MHD115C-058-PG1-BA

MHD115C-058-PG1-BA





Application areas:

In the realm of precision manufacturing, where every micron matters, the performance of motion control systems can make or break production efficiency. Consider the aerospace industry, where machining turbine blades requires rotational accuracy within thousandths of an inch—any deviation can compromise engine performance and safety. In semiconductor fabrication, robotic arms handling delicate wafers demand smooth, jerk-free movement to avoid costly damage. Even in high-volume industries like electronics assembly, pick-and-place machines rely on consistent torque and speed control to meet tight production deadlines. This is where the REXROTH MHD115C-058-PG1-BAproves indispensable. Used in industrial automation across these sectors, it delivers the precision and reliability needed to handle complex motion tasks, from synchronized multi-axis movements to high-speed positioning. Whether integrated into a new production line or retrofitted into an existing system, the REXROTH MHD115C-058-PG1-BA ensures that critical motion control operations run with the accuracy modern manufacturing demands.

MHD115C-058-PG1-BA

MHD115C-058-PG1-BA



Related products:

REXROTH IndraDrive Cs CSH01.1C-ET-EN1-NNN-NN-S-NN-FW – Works as the perfect drive controller for the REXROTH MHD115C-058-PG1-BA, enabling precise speed and torque regulation through advanced control algorithms.
REXROTH MHD115B-035-PG1-BA – A lower-torque sibling in the MHD series, offering 35 Nm for applications requiring similar speed ranges but less power than the REXROTH MHD115C-058-PG1-BA.
REXROTH R911306029 – A servo feedback cable specifically designed to connect the encoder of the REXROTH MHD115C-058-PG1-BA to the drive, ensuring reliable signal transmission even in noisy industrial environments.
REXROTH HVE04.2-W075N – A power supply module that pairs with the REXROTH MHD115C-058-PG1-BA in larger systems, providing stable DC power to the drive controller for consistent motor performance.
REXROTH MKD071B-061-GP0-KN – A smaller MKD series motor often used alongside the REXROTH MHD115C-058-PG1-BA in multi-axis systems, handling auxiliary motion tasks while the MHD handles heavy lifting.
REXROTH R900946849 – A motor mounting bracket designed to simplify the installation of the REXROTH MHD115C-058-PG1-BA in tight spaces, ensuring proper alignment with driven machinery.
Installation and maintenance:
Before installing the REXROTH MHD115C-058-PG1-BA, verify that the mounting surface can support its 38 kg weight without vibration—uneven mounting can cause premature bearing wear. Alignment with the driven load is critical; use a laser alignment tool to ensure concentricity within 0.1 mm to prevent shaft stress. The motor’s IP65 rating allows for use in damp environments, but ensure cable entries are properly sealed with compatible glands to maintain protection. For systems with multiple motors, route encoder cables separately from power cables to minimize electromagnetic interference.
Maintenance for the REXROTH MHD115C-058-PG1-BA focuses on preserving its precision. Conduct monthly visual inspections to check for loose connections or signs of overheating, such as discolored wiring. The motor’s bearings are lifetime-lubricated, but if unusual noise occurs during operation, check for misalignment or excessive load. Encoder functionality should be verified quarterly using the drive’s diagnostic tools to ensure position feedback accuracy. Avoid high-pressure water jets directly on the motor during cleaning, as this can compromise the IP65 seal over time.
