REXROTH HNC100 SYHNC100-BLA-23W-08-C-0-E23-A014 Digital Axis Controller

The REXROTH HNC100 SYHNC100-BLA-23W-08-C-0- E23-A014 is a high – performance digital axis controller. As part of Bosch Rexroth’s advanced control system lineup, it occupies a central position in the architecture of industrial automation control systems. Its primary function is to process control signals and translate them into precise commands for the motors or actuators connected to the axes it controls. Whether it’s a hydraulic – driven axis in a heavy – duty manufacturing machine or an electric – powered axis in a more delicate precision – engineering setup, this controller ensures that the movement is smooth, accurate, and synchronized with the overall system requirements.

Model HNC100 SYHNC100-BLA-23W-08-C-0- E23-A014
Brand REXROTH
Type Digital Axis Controller
Processor 16/32 – bit MC 68376
Operating Voltage Range 18 – 36 VDC
Inputs 8 flexible switching inputs (up to 1.5 mm²), 4 analog current inputs (4 – 20 mA)
Position Transducers 2 inductive
Memory 1 MB flash EPROM, 8 KB EEPROM, 256 KB RAM
Transducer Support Incremental and SSI
Max Current per Channel 30 mA
Dimensions 263 × 58 × 28 mm (approximate, check official docs)
Operating Temperature 0 – 50 °C
Country of Origin Germany (usually)
Bus Connection PROFIBUS DP (varies, check model)
Output Signals Signals for motor/actuator control
Compliance EC guidelines



Description

The REXROTH HNC100 SYHNC100-BLA-23W-08-C-0- E23-A014 is a high – performance digital axis controller. As part of Bosch Rexroth’s advanced control system lineup, it occupies a central position in the architecture of industrial automation control systems. Its primary function is to process control signals and translate them into precise commands for the motors or actuators connected to the axes it controls. Whether it’s a hydraulic – driven axis in a heavy – duty manufacturing machine or an electric – powered axis in a more delicate precision – engineering setup, this controller ensures that the movement is smooth, accurate, and synchronized with the overall system requirements.

HNC100 SYHNC100-BLA-23W-08-C-0-E23-A014

HNC100 SYHNC100-BLA-23W-08-C-0-E23-A014



For engineers and integrators, the value of the REXROTH HNC100 SYHNC100-BLA-23W-08-C-0- E23-A014 is manifold. It offers a highly versatile solution that can be easily integrated into both new and existing automation systems. Its compatibility with a wide range of motors, sensors, and other components in the industrial automation ecosystem simplifies the system – building process. With its ability to handle complex control algorithms, it provides a reliable and efficient way to manage the motion of multiple axes, reducing the complexity of programming and system operation. This controller also allows for easy customization, enabling engineers to fine – tune the control parameters according to the specific needs of the application, whether it’s a high – speed, high – precision operation or a more heavy – duty, torque – intensive task.

HNC100 SYHNC100-BLA-23W-08-C-0-E23-A014

HNC100 SYHNC100-BLA-23W-08-C-0-E23-A014



Main features and advantages:

One of the key technical features of the REXROTH HNC100 SYHNC100-BLA-23W-08-C-0- E23-A014 is its powerful 16/32 – bit MC 68376 processor. This processor enables precise open and closed – loop control of position, velocity, and pressure for electro – hydraulic axes. It can quickly process the incoming signals from sensors and adjust the control outputs accordingly, ensuring that the axes move with the required accuracy. For example, in a hydraulic press application, it can precisely control the pressure applied by the hydraulic cylinder, ensuring consistent and accurate pressing operations.



In terms of input and output capabilities, it comes equipped with 8 flexible switching inputs (up to 1.5 mm²), which can be used to interface with various sensors and switches in the system. It also has two inductive position transducers, allowing for accurate position feedback. The maximum current per channel of 30 mA ensures reliable operation of connected devices. With an operating voltage range of 18 to 36 VDC, it can adapt to different power supply setups in industrial environments. It also features four analog current inputs that can accept 4 to 20 mA signals, providing flexibility in interfacing with a wide range of analog sensors.



The controller has a substantial memory configuration with 1 MB of flash EPROM, 8 KB of EEPROM, and 256 KB of RAM. This ample memory allows for the storage of complex control programs and data, enabling it to handle sophisticated motion control tasks. It supports both incremental and SSI transducers, providing flexibility in choosing the type of position feedback device according to the requirements of the application. The unit is designed to meet EC guidelines, ensuring its compliance with safety and electromagnetic compatibility standards in the European market.
HNC100 SYHNC100-BLA-23W-08-C-0-E23-A014

HNC100 SYHNC100-BLA-23W-08-C-0-E23-A014

Technical specifications:
Model HNC100 SYHNC100-BLA-23W-08-C-0- E23-A014
Brand REXROTH
Type Digital Axis Controller
Processor 16/32 – bit MC 68376
Operating Voltage Range 18 – 36 VDC
Inputs 8 flexible switching inputs (up to 1.5 mm²), 4 analog current inputs (4 – 20 mA)
Position Transducers 2 inductive
Memory 1 MB flash EPROM, 8 KB EEPROM, 256 KB RAM
Transducer Support Incremental and SSI
Max Current per Channel 30 mA
Dimensions 263 × 58 × 28 mm (approximate, check official docs)
Operating Temperature 0 – 50 °C
Country of Origin Germany (usually)
Bus Connection PROFIBUS DP (varies, check model)
Output Signals Signals for motor/actuator control
Compliance EC guidelines

contact us:
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq , com

HNC100 SYHNC100-BLA-23W-08-C-0-E23-A014

HNC100 SYHNC100-BLA-23W-08-C-0-E23-A014



Application areas:

In the intricate world of industrial automation, where precision and efficiency are the driving forces behind seamless operations, the REXROTH HNC100 SYHNC100-BLA-23W-08-C-0- E23-A014 emerges as a crucial component. Consider a high – tech manufacturing facility that produces micro – electronic components. Here, the machinery demands pinpoint – accurate movement of robotic arms to place minuscule parts with micron – level precision. Or think about a large – scale printing press where the cylinders need to rotate with utmost synchronization to create sharp, high – quality prints. These are the types of real – world scenarios where the REXROTH HNC100 SYHNC100-BLA-23W-08-C-0- E23-A014 truly shines.



This product is widely applied in industrial automation, specifically in systems that require the precise control of axes. It is designed to tackle the challenges of achieving accurate motion control in various industrial environments. In the field of machine tools, it can precisely regulate the movement of the cutting tools, ensuring smooth and accurate machining of workpieces. In automated assembly lines, it controls the movement of conveyors and robotic grippers, guaranteeing that components are assembled in the correct sequence and with the right positioning. The REXROTH HNC100 SYHNC100-BLA-23W-08-C-0- E23-A014 plays a pivotal role in enabling technical tasks such as closed – loop control of hydraulic and electric drives, position, velocity, and pressure regulation, making it an essential element in any modern automated setup.
HNC100 SYHNC100-BLA-23W-08-C-0-E23-A014

HNC100 SYHNC100-BLA-23W-08-C-0-E23-A014





Related products:

HNC100 – variant with fewer inputs – A model with a reduced number of switching inputs, suitable for applications where a simpler input configuration is sufficient, such as in some small – scale automated test equipment.
HNC100 – higher – performance processor model – Features a more advanced processor, which can be beneficial for applications that require extremely fast processing of control algorithms, like high – speed pick – and – place robots in electronics manufacturing.





Installation and maintenance:

Before installing the REXROTH HNC100 SYHNC100-BLA-23W-08-C-0- E23-A014, it is essential to carefully plan the installation location. Ensure that the control cabinet or mounting area has sufficient space around the unit to allow for proper ventilation. Since the controller may generate heat during operation, a clearance of at least [recommended clearance value] mm around all sides is advisable to prevent overheating. Check the integrity of the power supply wiring to ensure that the voltage is within the specified 18 – 36 VDC range. Proper grounding of the installation site is also crucial to protect against electrical malfunctions and ensure the safety of the entire system. Additionally, verify that the communication cables, such as those for PROFIBUS DP, are of the correct type and length. Incorrect cabling can lead to signal interference and erratic operation of the controller.



For maintenance, a visual inspection should be carried out monthly. Check for any signs of physical damage, such as cracks in the casing or loose connections. Every three months, it is recommended to use the appropriate software tools (usually provided by Rexroth) to perform a comprehensive diagnostic check. This includes verifying the control parameters, monitoring the temperature of the controller, and checking for any error codes. Periodically clean the unit to remove dust and debris, especially from the ventilation openings, as dust accumulation can affect the cooling efficiency. Firmware updates should be installed as recommended by Rexroth, typically on an annual basis. However, always perform these updates during scheduled downtime to avoid disrupting ongoing operations. Before applying any firmware update, it is advisable to backup all the existing control programs and data to prevent data loss.
