The REXROTH HMS01.1N-W0070-A-07-NNNN is a high – performance single – axis inverter. As a key component of Bosch Rexroth’s advanced drive systems, it plays a pivotal role in industrial automation control architectures. Its primary function is to convert direct current (DC) into precisely controlled alternating current (AC) with variable amplitude and frequency. This conversion enables the smooth and accurate operation of motors, whether they are driving conveyor belts, robotic joints, or other mechanical components in an automated setup.
Model HMS01.1N-W0070-A-07-NNNN
Brand REXROTH
Type Single – axis inverter
Power Supply DC – bus nominal voltage: 700 VDC
Operating Temperature 0 °C – 40 °C
Mounting Cabinet – mountable
Weight 7.94 kg
Interfaces EtherCAT, SERCOS, etc.
Cooling Internal air – cooling (blower)
Environmental Rating IP20
Maximum Current 70 A
Continuous Current 42.4 A
Power Consumption 16 W
Encoder Compatibility Standard encoders via multi – encoder interface
Safety Features Safe Torque Off (STO)
The REXROTH HMS01.1N-W0070-A-07-NNNN is a high – performance single – axis inverter. As a key component of Bosch Rexroth’s advanced drive systems, it plays a pivotal role in industrial automation control architectures. Its primary function is to convert direct current (DC) into precisely controlled alternating current (AC) with variable amplitude and frequency. This conversion enables the smooth and accurate operation of motors, whether they are driving conveyor belts, robotic joints, or other mechanical components in an automated setup.
HMS01.1N-W0070-A-07-NNNN
For engineers and system integrators, its value is multi – fold. It offers an easy – to – integrate solution for both new and existing automation systems, simplifying the design process. With its ability to handle a wide range of motor types and sizes within its power capacity, it provides a cost – effective option for applications requiring single – axis control. The REXROTH HMS01.1N-W0070-A-07-NNNN comes with a variety of interfaces, making it compatible with different sensors, controllers, and other components in the automation ecosystem. This compatibility reduces the complexity of system integration and allows for seamless communication between various elements of the control system.
HMS01.1N-W0070-A-07-NNNN
Main features and advantages:
One of the standout technical features of the REXROTH HMS01.1N-W0070-A-07-NNNN is its impressive maximum current handling capacity of 70 A. This high – current capability enables it to power motors that demand substantial torque during startup or when performing heavy – duty operations. Whether it’s driving a large – scale industrial mixer or a high – speed conveyor belt, the inverter can deliver the necessary power to ensure smooth operation even under challenging load conditions. The device operates with a DC – bus nominal voltage of 700 VDC, which is well – suited for high – powered industrial applications where efficient energy transfer is essential.
In terms of hardware design, it features an internal air – cooling system via an integrated blower. This design ensures that the inverter remains at an optimal operating temperature, even during continuous and high – load operation. The IP20 protection rating safeguards it against dust ingress, making it suitable for use in industrial environments where dust particles are common. The compact form factor of the unit makes it easy to install in control cabinets, saving valuable space, which is often at a premium in industrial settings.
Compatibility is another strong point of the REXROTH HMS01.1N-W0070-A-07-NNNN. It is compatible with a wide range of motors, including various types of servo and asynchronous motors. Additionally, it can communicate with different control systems through interfaces such as EtherCAT and SERCOS, allowing for seamless integration into complex automation networks. This flexibility in compatibility means that it can be used in a diverse range of industries, from manufacturing to logistics, without the need for major system overhauls.
Technical specifications:
Model HMS01.1N-W0070-A-07-NNNN
Brand REXROTH
Type Single – axis inverter
Power Supply DC – bus nominal voltage: 700 VDC
Operating Temperature 0 °C – 40 °C
Mounting Cabinet – mountable
Weight 7.94 kg
Interfaces EtherCAT, SERCOS, etc.
Cooling Internal air – cooling (blower)
Environmental Rating IP20
Maximum Current 70 A
Continuous Current 42.4 A
Power Consumption 16 W
Encoder Compatibility Standard encoders via multi – encoder interface
Safety Features Safe Torque Off (STO)
contact us: Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq , com
Application areas:
In the dynamic realm of industrial automation, the pursuit of seamless motor control and high – performance drive solutions is unending. Picture a large – scale automotive assembly line where hundreds of robotic arms must move with split – second precision to weld, assemble, and paint vehicle components. Or a state – of – the – art pharmaceutical manufacturing plant where the filling and capping of vials demand extreme accuracy in motor – driven machinery. These are the complex and demanding scenarios where the REXROTH HMS01.1N-W0070-A-07-NNNN proves its mettle.
This remarkable product is widely deployed in industrial automation, particularly in applications where the precise control of a single motor axis is crucial. It is engineered to overcome the challenges of achieving accurate motion in industrial settings. In printing presses, for instance, it precisely controls the speed and position of the printing rollers, ensuring sharp and consistent prints. In packaging machinery, it manages the movement of conveyor belts and packaging arms, guaranteeing smooth product flow and accurate packaging. The REXROTH HMS01.1N-W0070-A-07-NNNN is designed to handle technical tasks such as precise torque regulation, high – speed motor commutation, and reliable position feedback, making it an indispensable part of any automated system that demands top – tier performance.
Related products:
HMS01.1N – W0012 – A – 07 – NNNN – A lower – current variant of the same series, ideal for applications with less demanding power requirements, such as small – scale laboratory equipment or low – load conveyors. HMS01.1N – W0030 – A – 07 – NNNN – Offers a higher maximum current capacity compared to some models, suitable for motors in applications like industrial mixers or pumps that require more torque. IndraDrive M Power Supply Unit (specific model) – Specifically designed to work in harmony with the REXROTH HMS01.1N – W0070 – A – 07 – NNNN, providing a stable and reliable power source for the inverter. IndraWorks Software – This software is essential for monitoring and configuring the REXROTH HMS01.1N – W0070 – A – 07 – NNNN. It allows engineers to easily adjust parameters, perform diagnostics, and optimize the performance of the drive system.
Installation and maintenance:
Before installing the REXROTH HMS01.1N-W0070-A-07-NNNN, it is vital to ensure that the control cabinet has sufficient space for proper ventilation. Given that the unit uses internal air – cooling, a clearance of at least [X] mm around the device is recommended to ensure efficient heat dissipation. Check the integrity of the DC power supply to make sure the voltage is stable and within the specified 700 VDC range. Proper grounding of the cabinet is also crucial to prevent electrical malfunctions and ensure the safety of the entire system. Additionally, verify that the communication cables are of the correct type and length. Incorrect cabling can lead to signal interference, which may cause erratic operation of the inverter.
For maintenance, a visual inspection should be carried out monthly to check for any signs of physical damage, such as cracks in the casing or loose connections. Every three months, it is advisable to use the IndraWorks software to perform a comprehensive diagnostic check. This includes verifying motor control parameters, monitoring the temperature of the inverter, and checking for any error codes. Periodically clean the air vents of the internal cooling system to prevent dust buildup, as dust can impede the cooling process and potentially lead to overheating. Firmware updates should be installed as recommended by Rexroth, usually on an annual basis, to benefit from the latest performance enhancements and bug fixes. However, always perform these updates during scheduled downtime to avoid disrupting ongoing operations.
