The REXROTH HMD01.1N-W0020- A -07-NNNN is a high – performance double – axis inverter. As part of Bosch Rexroth’s renowned Indradrive system, it is engineered to control two independent motors simultaneously, fitting neatly into the architecture of industrial automation control systems. It serves as a bridge between the power supply and the motors, converting direct current (DC) into precisely controlled alternating current (AC) with variable amplitude and frequency. This allows for the smooth and accurate operation of motors, whether they are driving conveyor belts, robotic arms, or other mechanical components in an automated setup.
Model HMD01.1N-W0020- A -07-NNNN
Brand REXROTH
Type Double – axis inverter
Power Supply DC – bus nominal voltage: 700 VDC
Operating Temperature 0 °C to 40 °C
Mounting Cabinet – mountable
Cooling Internal air – cooling (blower)
Environmental Rating IP20
Peak Current 20A
Number of Motors Controlled 2
Humidity Tolerance Maximum 95% relative humidity
Compatibility Indradrive M and C systems
Maximum Operational Altitude 1000 meters
The REXROTH HMD01.1N-W0020- A -07-NNNN is a high – performance double – axis inverter. As part of Bosch Rexroth’s renowned Indradrive system, it is engineered to control two independent motors simultaneously, fitting neatly into the architecture of industrial automation control systems. It serves as a bridge between the power supply and the motors, converting direct current (DC) into precisely controlled alternating current (AC) with variable amplitude and frequency. This allows for the smooth and accurate operation of motors, whether they are driving conveyor belts, robotic arms, or other mechanical components in an automated setup.
HMD01.1N-W0020-A-07-NNNN
For engineers and integrators, its value lies in its versatility. It can be easily integrated into both new and existing automation systems, reducing the complexity of system design. With its ability to handle a wide range of motor types and sizes, it offers a cost – effective solution for applications that require multi – axis control. The REXROTH HMD01.1N-W0020- A -07-NNNN simplifies the wiring process and space requirements compared to using two separate single – axis inverters, making it an attractive option for those looking to optimize the layout of their control cabinets.
HMD01.1N-W0020-A-07-NNNN
Main features and advantages:
One of the key technical features of the REXROTH HMD01.1N-W0020- A -07-NNNN is its impressive peak current handling capacity of 20A. This enables it to power motors that require high – torque bursts during startup or when performing heavy – duty tasks, ensuring smooth operation even under demanding load conditions. The device operates at a DC – bus nominal voltage of 700 VDC, which is well – suited for high – powered industrial applications where efficient energy transfer is essential.
In terms of hardware design, it features an internal air – cooling system via an integrated blower. This design ensures that the inverter remains at an optimal operating temperature, even during continuous operation, enhancing its long – term reliability. With an IP20 protection rating, it is safeguarded against dust ingress, making it suitable for use in industrial environments where dust particles are common. The compact design of the unit makes it easy to install in control cabinets, saving valuable space.
Compatibility is another strong suit of the REXROTH HMD01.1N-W0020- A -07-NNNN. It is compatible with Indradrive M power supplies, allowing for seamless integration within Rexroth’s broader ecosystem. Additionally, it can be monitored and configured using Indraworks software, providing engineers with a comprehensive toolset to manage and optimize the performance of the drive system. This compatibility not only simplifies system integration but also allows for easy expansion and future upgrades as the automation needs of the facility grow.
Technical specifications:
Model HMD01.1N-W0020- A -07-NNNN
Brand REXROTH
Type Double – axis inverter
Power Supply DC – bus nominal voltage: 700 VDC
Operating Temperature 0 °C to 40 °C
Mounting Cabinet – mountable
Cooling Internal air – cooling (blower)
Environmental Rating IP20
Peak Current 20A
Number of Motors Controlled 2
Humidity Tolerance Maximum 95% relative humidity
Compatibility Indradrive M and C systems
Maximum Operational Altitude 1000 meters
contact us: Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq , com
Application areas:
In the ever – evolving landscape of industrial automation, the need for precise and reliable motor control solutions is more critical than ever. Consider a modern electronics manufacturing facility where high – speed pick – and – place robots are required to place tiny components on circuit boards with micron – level accuracy. Or a textile mill where the synchronization of multiple spinning and weaving machines demands a drive system that can handle complex speed and torque variations. These are the real – world scenarios where the REXROTH HMD01.1N-W0020- A -07-NNNN truly shines.
This product is widely applicable in industrial automation, especially in scenarios where the control of multiple motors in a compact space is crucial. It is designed to address the challenges of achieving accurate motion control in applications with limited cabinet space, such as in small – to – medium – sized automated machinery. In packaging machinery, it can precisely control the motors for conveyor belts, filling mechanisms, and sealing operations, ensuring seamless product flow. In woodworking machinery, it enables the coordinated movement of cutting, shaping, and sanding tools, enhancing the precision and quality of the final products. The REXROTH HMD01.1N-W0020- A -07-NNNN plays a vital role in supporting technical tasks like high – speed motor commutation, torque regulation, and position feedback, making it an essential component in any automated system that requires top – notch performance.
Related products:
HMD01.1N – W0012 – A – 07 – NNNN – A lower – current variant of the same series, suitable for applications with less demanding power requirements, such as small – scale laboratory equipment or low – load conveyors. HMD01.1N – W0030 – A – 07 – NNNN – Offers a higher peak current capacity of 30A, making it ideal for larger motors in applications like industrial mixers or heavy – duty pumps that require more torque. Indradrive M Power Supply Unit (specific model) – Specifically designed to work in tandem with the REXROTH HMD01.1N – W0020 – A – 07 – NNNN, providing a stable power source for the double – axis inverter. Indraworks Software – As mentioned, this software is crucial for monitoring and configuring the REXROTH HMD01.1N – W0020 – A – 07 – NNNN, allowing for easy parameter adjustments and system diagnostics.
Installation and maintenance:
Before installing the REXROTH HMD01.1N-W0020- A -07-NNNN, it is essential to ensure that the control cabinet has sufficient space for proper ventilation. Since the unit uses internal air – cooling, a clearance of at least [X] mm around the device is recommended to facilitate efficient heat dissipation. Check the integrity of the DC power supply, ensuring that the voltage is stable and within the specified range of 700 VDC. Grounding the cabinet properly is also crucial to protect against electrical malfunctions and ensure the safety of the entire system. Additionally, verify that the communication cables are of the correct type and length, as improper cabling can lead to signal interference and erratic operation.
For maintenance, a visual inspection should be carried out monthly to check for any signs of physical damage, such as cracks in the casing or loose connections. Every three months, it is advisable to use the Indraworks software to perform a comprehensive diagnostic check. This includes verifying the motor control parameters, monitoring the temperature of the inverter, and checking for any error codes. Periodically clean the air vents of the internal cooling system to prevent dust buildup, which can impede the cooling process. Firmware updates should be installed as recommended by Rexroth, usually on an annual basis, to benefit from the latest performance enhancements and bug fixes. However, always perform these updates during scheduled downtime to avoid any disruption to ongoing operations.
