Rexroth DKC10.3-018-3-MGP-01VRS Compact, High – Performance Servo Drive

The Rexroth DKC10.3-018-3-MGP-01VRS is a state – of – the – art servo drive engineered to manage brushless servo motors in a wide range of medium – duty industrial applications. As part of Rexroth’s advanced DKC series, it acts as the crucial interface between intelligent motion controllers (such as the Rexroth CSH01.3C – ET – ENS – NNN – CCD – NN – S – NN – FW) and high – precision servo motors. It takes digital commands and converts them into extremely accurate mechanical motions. Distinguished from larger, bulkier servo drives, this model combines a robust power output with a remarkably compact design, making it an ideal choice for machinery where space is at a premium.

Model DKC10.3-018-3-MGP-01VRS
Brand Rexroth
Type Compact, High – Performance Servo Drive
Power Supply 3 – phase AC 200 – 240V ±10%
Continuous Output Current 6A
Peak Output Current 18A (10ms duration)
Operating Temperature 0°C to 50°C (32°F to 122°F)
Storage Temperature – 20°C to 60°C (- 4°F to 140°F)
Mounting DIN rail (35mm)
Dimensions 100mm x 160mm x 120mm (W x H x D)
Weight 1.2kg
Interfaces 1 x EtherNet/IP, 2 x analog inputs, 4 x digital inputs, 2 x digital outputs
Motor Compatibility Brushless servo motors (up to 1.2kW)
Certifications CE, UL, cUL, RoHS
Cooling Passive (integrated heat sink)
Control Modes Position, velocity, torque, and position – based torque control

Description

The Rexroth DKC10.3-018-3-MGP-01VRS is a state – of – the – art servo drive engineered to manage brushless servo motors in a wide range of medium – duty industrial applications. As part of Rexroth’s advanced DKC series, it acts as the crucial interface between intelligent motion controllers (such as the Rexroth CSH01.3C – ET – ENS – NNN – CCD – NN – S – NN – FW) and high – precision servo motors. It takes digital commands and converts them into extremely accurate mechanical motions. Distinguished from larger, bulkier servo drives, this model combines a robust power output with a remarkably compact design, making it an ideal choice for machinery where space is at a premium.

DKC10.3-018-3-MGP-01VRS

DKC10.3-018-3-MGP-01VRS



The Rexroth DKC10.3-018-3-MGP-01VRS can be easily integrated into both stand – alone industrial systems and complex, networked automation architectures. It supports a diverse set of communication protocols, allowing it to function seamlessly in various industrial communication environments. Its value lies in its ability to offer high – level dynamic performance, including swift acceleration and deceleration, while maintaining the stability necessary for precision – intensive tasks.

DKC10.3-018-3-MGP-01VRS

DKC10.3-018-3-MGP-01VRS

Main features and advantages:

One of the standout features of the Rexroth DKC10.3-018-3-MGP-01VRSis its exceptional power – to – size ratio. It can supply a peak current of 18A to drive servo motors with an output power of up to 1.2kW, all within a housing that is only 100mm wide. This makes it particularly suitable for multi – axis systems like small robotic pick – and – place units, where multiple drives need to be installed in close proximity. Its advanced control algorithms, which include sophisticated field – oriented control (FOC) and intelligent feedforward compensation, can significantly reduce position error, even during rapid speed changes. This is crucial for applications like laser micromachining, where the slightest deviation in path can ruin a high – value workpiece. Unlike basic servo drives, the Rexroth DKC10.3-018-3-MGP-01VRS offers a wide array of connectivity options. It includes analog inputs, digital I/O, and a high – speed EtherNet/IP interface for seamless communication with motion controllers. This enables it to be integrated effortlessly into both legacy industrial setups and the latest Industry 4.0 – compliant environments.
Durability is built into every aspect of the Rexroth DKC10.3-018-3-MGP-01VRS. It features a rugged metal housing that provides efficient heat dissipation, allowing it to operate reliably in temperatures ranging from 0°C to 50°C without the need for additional forced cooling. The drive’s circuit design incorporates comprehensive protection features, such as overcurrent, overvoltage, and short – circuit protection. These features safeguard both the drive and the connected motor from damage during abnormal operating conditions. Engineers highly appreciate its low electromagnetic emissions, which minimize interference with nearby sensitive electronic equipment. This is a significant advantage in industries like electronics manufacturing and medical device production, where EMI can disrupt delicate operations.
DKC10.3-018-3-MGP-01VRS

DKC10.3-018-3-MGP-01VRS

Technical specifications:
Model DKC10.3-018-3-MGP-01VRS
Brand Rexroth
Type Compact, High – Performance Servo Drive
Power Supply 3 – phase AC 200 – 240V ±10%
Continuous Output Current 6A
Peak Output Current 18A (10ms duration)
Operating Temperature 0°C to 50°C (32°F to 122°F)
Storage Temperature – 20°C to 60°C (- 4°F to 140°F)
Mounting DIN rail (35mm)
Dimensions 100mm x 160mm x 120mm (W x H x D)
Weight 1.2kg
Interfaces 1 x EtherNet/IP, 2 x analog inputs, 4 x digital inputs, 2 x digital outputs
Motor Compatibility Brushless servo motors (up to 1.2kW)
Certifications CE, UL, cUL, RoHS
Cooling Passive (integrated heat sink)
Control Modes Position, velocity, torque, and position – based torque control





Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

DKC10.3-018-3-MGP-01VRS

DKC10.3-018-3-MGP-01VRS

Application areas:

In the intricate world of precision dispensing in the cosmetics industry, where every drop of a high – value serum must be accurately measured and deposited, and in the assembly of micro – electromechanical systems (MEMS), where components are minuscule and require ultra – precise positioning, the Rexroth DKC10.3-018-3-MGP-01VRS plays a pivotal role. This servo drive is specifically tailored for industrial automation setups that demand a blend of high – performance motion control and adaptability in a compact footprint. In small – scale 3D printing, it enables the precise movement of print heads, ensuring the creation of detailed and accurate prototypes. In the food packaging sector, it synchronizes the delicate operations of filling and capping machines, guaranteeing product integrity and consistent packaging quality. Its capacity to provide smooth, responsive motor control within limited space makes it an invaluable asset in modern, space – conscious automation facilities.

DKC10.3-018-3-MGP-01VRS

DKC10.3-018-3-MGP-01VRS





Related products:

Rexroth DKC10.3 – 012 – 3 – MGP – 01VRS – A lower – current variant of the Rexroth DKC10.3 – 018 – 3 – MGP – 01VRS, suitable for motors with up to 0.8kW output. This is a great option for applications where power requirements are less demanding, such as small – scale conveyor systems in a laboratory setting.
Rexroth DKC10.3 – 025 – 3 – MGP – 01VRS – A higher – power model with increased thermal handling capabilities, compatible with motors up to 1.8kW. This can be used in more power – hungry applications like medium – sized robotic arms in a light – manufacturing environment.
Rexroth MHD108A – 041 – PG0 – AN – A servo motor that pairs perfectly with the Rexroth DKC10.3 – 018 – 3 – MGP – 01VRS for achieving optimal performance. The combination provides high torque at low speeds, which is beneficial for applications that require precise movement of heavy loads in a small workspace.
Rexroth CSH01.3C – ET – ENS – NNN – CCD – NN – S – NN – FW – A motion controller that can effectively synchronize multiple Rexroth DKC10.3 – 018 – 3 – MGP – 01VRS drives in complex multi – axis systems. It enables coordinated movement of various axes, ensuring smooth operation in applications like multi – axis milling machines.
Rexroth R911306060 – A specialized feedback cable set designed for secure and accurate signal transmission between encoders and the Rexroth DKC10.3 – 018 – 3 – MGP – 01VRS. This ensures that the drive receives precise position feedback, enhancing the overall accuracy of the motion control system.
Rexroth DKC10.3 – 018 – 3 – MGP – 01VRS/BR – A variant of the Rexroth DKC10.3 – 018 – 3 – MGP – 01VRS with enhanced braking functionality, ideal for applications with high – inertia loads. This is useful in scenarios where the motor needs to stop quickly, such as in a packaging machine when the product flow needs to be halted immediately.
Rexroth PSB3AC/380 – 24 – A power supply unit optimized to provide stable and clean power to the Rexroth DKC10.3 – 018 – 3 – MGP – 01VRS in three – phase industrial systems. It ensures that the drive operates under consistent power conditions, reducing the risk of performance issues due to voltage fluctuations.
Installation and maintenance:
Before installing the Rexroth DKC10.3-018-3-MGP-01VRS, it is essential to ensure that the mounting surface, preferably a metal panel with good heat – conducting properties, can effectively dissipate heat. Avoid installing it near components that generate excessive heat, such as high – power heaters. Verify that the DIN rail is rated to support the drive’s weight, and use appropriate DIN rail accessories to prevent any movement during transportation or in the presence of vibrations. For electrical installation, use shielded power cables with a minimum cross – sectional area of 1mm² to handle the peak current without significant voltage drops. Ensure proper grounding of both the drive and the motor to minimize electromagnetic interference. When installing multiple Rexroth DKC10.3-018-3-MGP-01VRS units, maintain a minimum clearance of 25mm between drives to ensure good airflow and prevent overheating.
Maintenance of the Rexroth DKC10.3-018-3-MGP-01VRS mainly focuses on maintaining electrical connections and ensuring optimal thermal performance. Every two months, inspect the power terminals for any signs of overheating, such as discoloration or oxidation. If necessary, retighten the terminals to the specified torque of 2Nm. The drive’s status LEDs provide real – time information about its operation. Train operators to recognize normal and abnormal LED patterns to quickly identify issues such as overcurrent, overvoltage, or encoder malfunctions. Firmware updates are released quarterly and can be installed using Rexroth’s IndraWorks software and a suitable programming cable. Always back up the current parameters before performing a firmware update. Although the Rexroth DKC10.3-018-3-MGP-01VRS has no moving parts, it is recommended to check the cooling surfaces for dust accumulation every four months to maintain its thermal efficiency.
