Rexroth CSH01.3C-ET-ENS-NNN-CCD-NN-S-NN-FW Advanced Compact Motion Controller

The Rexroth CSH01.3C-ET-ENS-NNN-CCD-NN-S-NN-FW is an advanced compact motion controller designed to handle mid-sized multi-axis systems in demanding industrial environments. As a premium offering in Rexroth’s CSH01 series, it builds on the capabilities of its predecessors by adding enhanced processing power and Ethernet-based communication, making it ideal for connected factories and Industry 4.0 applications. Unlike basic motion controllers, this model combines high-speed axis synchronization with intelligent data processing, enabling real-time adjustment of motion profiles based on sensor feedback.

Model CSH01.3C-ET-ENS-NNN-CCD-NN-S-NN-FW
Brand Rexroth
Type Advanced Compact Motion Controller
Power Supply 24V DC ±10%
Operating Temperature 0°C to 60°C (32°F to 140°F)
Storage Temperature -25°C to 75°C (-13°F to 167°F)
Mounting DIN rail (35mm)
Dimensions 120mm x 90mm x 65mm (W x H x D)
Weight 0.65kg
Interfaces 2 x Ethernet (Ethernet/IP, PROFINET), 2 x RS-485, 8 x digital inputs, 4 x digital outputs
Axes SupportedUp to 8 axes (servo or stepper)
Certifications CE, UL, cUL, RoHS, ISO 13485
Cooling Passive (no fan)
Programming Interface Rexroth IndraWorks Engineering Suite (v6.1+)
