RET650 Numerical Line Protection Relay

Description

RET650

The ABB RET650 is an advanced numerical relay designed as a core component of ABB’s Relion® product family, specialized in protecting and controlling high-voltage transmission lines and substation equipment. As a key element in modern power system automation, it combines protection, control, measurement, and monitoring functions in a single device, eliminating the need for multiple standalone components in substation architectures.

RET650

This relay integrates seamlessly into digital substation environments, supporting both traditional hardwired connections and modern IEC 61850 communication protocols for interoperability with other intelligent electronic devices (IEDs). Its modular design allows customization to specific application requirements, whether for radial lines, mesh networks, or transformer feeder protection. What makes the ABB RET650 particularly valuable is its ability to balance ultra-fast protection performance with extensive data logging and diagnostic capabilities, providing engineers with both real-time fault mitigation and long-term system analysis tools.

RET650

Main features and advantages:

The ABB RET650 delivers exceptional protection performance with a 32-bit microprocessor that executes protection algorithms in less than 10 milliseconds, ensuring rapid fault detection and isolation to minimize equipment damage. It supports a comprehensive range of protection functions including distance protection, overcurrent protection, earth fault protection, and breaker failure protection, making it suitable for diverse transmission and distribution applications.

Hardware design highlights include a ruggedized enclosure that meets IEC 61850-3 environmental standards, withstanding operating temperatures from -25°C to +70°C and vibration up to 5g. The relay features multiple communication interfaces including Ethernet, RS485, and optical fiber ports, enabling secure data exchange with substation automation systems using protocols like IEC 61850, DNP3, and Modbus. Its redundant power supply inputs ensure continuous operation even during temporary power interruptions, a critical feature for mission-critical power infrastructure.

RET650

Application areas:

In high-voltage substations, renewable energy plants, and industrial power distribution networks, protecting critical electrical infrastructure from faults, overloads, and operational anomalies is paramount to preventing costly downtime and ensuring personnel safety. These environments require intelligent protection devices that can detect electrical disturbances within milliseconds, isolate faulty sections, and communicate critical status information to supervisory systems. Whether safeguarding transformers in a utility substation, protecting feeder circuits in a manufacturing facility, or managing grid connections for solar farms, engineers need reliable relays that combine precision protection with advanced communication capabilities.

This is where the ABB RET650 excels, serving as a multifunctional numerical relay in power system protection and control applications across the energy sector. In transmission networks, it provides primary protection for high-voltage lines, detecting faults and initiating tripping sequences to prevent cascading failures. In industrial plants with complex power distribution systems, it monitors load currents and voltage levels, ensuring equipment operates within safe parameters. Used in power system automation for over a decade, the ABB RET650 has proven its reliability in applications requiring fast response times and seamless integration with SCADA and substation automation systems, making it a trusted choice for power utilities and industrial operators worldwide.

RET650

Related products:

ABB RET670 – Sister model optimized for transformer protection, with specialized algorithms for winding and core fault detection.

ABB REL650 – Compact version of the ABB RET650 designed for medium-voltage distribution networks with reduced I/O requirements.

ABB REX640 – Auxiliary relay that enhances the ABB RET650’s control capabilities for complex substation interlocking schemes.

ABB SPACOM S200 – Communication gateway that connects the ABB RET650 to legacy SCADA systems using non-IEC 61850 protocols.

ABB PSE600 – Power supply unit providing redundant 24V DC output specifically for the ABB RET650 and associated substation devices.

ABB HMI60.1 – Local operator panel that displays real-time status and allows configuration of the ABB RET650 without external software.

ABB CMU800 – Circuit breaker monitoring unit that integrates with the ABB RET650 to provide breaker health diagnostics.

ABB REF615 – Feeder protection relay that coordinates with the ABB RET650 in distributed power distribution systems.

Installation and maintenance:

Before installing the ABB RET650, verify that the mounting location provides adequate ventilation with a minimum of 100mm clearance on all sides to dissipate heat generated during operation. Ensure the substation grounding system meets IEEE 80 standards, with the relay’s protective earth terminal connected to the substation’s main grounding grid using a 6mm² copper conductor to achieve proper noise immunity. Check that input voltage matches the relay’s rated power supply specifications to prevent damage during initial power-up.

For maintenance, schedule quarterly inspections using ABB’s PCM600 software to verify protection setting integrity and log file completeness. Perform visual checks every six months to inspect terminal connections for corrosion or looseness, particularly on current transformer (CT) and voltage transformer (VT) inputs. Firmware updates should be applied during scheduled outages, with a backup of all configuration files stored securely before proceeding. The ABB RET650 includes built-in test functions that allow engineers to verify protection logic without interrupting normal operation, facilitating safe maintenance activities.
