RET620E-1G Advanced Bay Controller for Substation Automation

Description

RET620E-1G

The RET620E-1G functions as an advanced bay controller designed for medium-voltage substation automation. It occupies a central position in the substation automation architecture, acting as the interface between field devices (such as protection relays, circuit breakers, and sensors) and higher-level supervisory systems.

RET620E-1G

This controller connects to protection devices like the REM543BM215AAAB and other IEDs (Intelligent Electronic Devices) through a variety of communication protocols, enabling real-time data exchange and control commands. It processes incoming data from field devices, executes automation logic, and coordinates operations between different components of the substation. The RET620E-1G supports IEC 61850, the global standard for substation communication, which allows for interoperability with devices from different manufacturers. Its modular design allows for customization based on specific substation requirements, with options for expanded I/O and communication ports to accommodate growing system needs.

RET620E-1G

Main features and advantages:

Engineered for high performance in demanding substation environments, the RET620E-1G delivers reliable operation with advanced functionality. Its robust hardware design ensures stability in extreme temperature conditions, high electromagnetic interference environments, and voltage transients common in substations. The controller’s powerful processor handles complex automation tasks efficiently, ensuring fast response times for critical control operations.

The RET620E-1G offers significant value through its advanced integration capabilities. By serving as a centralized communication hub, it reduces the complexity of substation wiring and simplifies system expansion. Its support for IEC 61850 enables seamless integration with modern digital devices while providing gateways for legacy equipment, protecting existing investments during modernization. The controller’s built-in automation logic allows for the implementation of advanced functions such as interlocking, sequence control, and condition monitoring, enhancing substation efficiency and reducing the need for manual intervention. For utilities and industrial facilities, this translates to improved operational efficiency, reduced downtime, and enhanced system reliability.

RET620E-1G

Application areas:

The RET620E-1G is ideally suited for a range of substation automation applications. In utility distribution substations, it coordinates the operation of protection relays, circuit breakers, and sectionalizers, enabling fast fault isolation and service restoration. Its advanced communication capabilities allow for integration with SCADA systems, providing utilities with real-time visibility into substation operations and enabling remote control.

In industrial substations serving large manufacturing plants or processing facilities, the  RET620E-1G  integrates with plant-wide automation systems to ensure coordinated operation between the utility supply and on-site generation. It enables advanced load management, peak shaving, and backup power  Switching, supporting reliable power for critical industrial processes.

In renewable energy substations, such as those connecting wind farms or solar parks to the grid, the controller manages the interface between variable generation sources and the main grid. It coordinates protection devices and implements grid code requirements, ensuring stable integration of renewable energy while maintaining system reliability.

RET620E-1G

Related products:

RET620 – Premium bay controller with enhanced processing power for large substations.

RET615 – Compact bay controller for smaller substations with basic automation needs.

REM543BM215AAAB – Protection relay commonly integrated with RET620E-1G in medium-voltage bays.

REF620 NBFNAANNNDA1BBN1XF – Transformer protection relay compatible with the controller.

RET620E-2G – Variant with dual Gigabit Ethernet ports for redundant communication networks.

RET620E-1G-S – Security-enhanced version for critical infrastructure applications.

Installation and maintenance:

Before installing the RET620E-1G, verify compatibility with existing substation devices and ensure that communication protocols match between the controller and connected IEDs. Check that the mounting location provides adequate ventilation and space for cable management, especially when using Gigabit Ethernet connections. Confirm that the control power supply can accommodate the controller’s power requirements and that appropriate surge protection is in place to safeguard against voltage transients.

For ongoing maintenance, regularly monitor the controller’s health status through its built-in diagnostic tools, checking for communication errors, processor load, and memory usage. Perform quarterly inspections of physical connections, ensuring Ethernet and power cables are securely fastened and free from damage. Schedule firmware updates during planned outages, ensuring compatibility with connected devices like the REM543BM215AAAB. Regularly backup configuration files and automation logic to prevent data loss, and test restore procedures periodically to ensure system recoverability.
