REF615C_C HCFFAEAGANB2BAN1XC Ruggedized Busbar Protection Relay

Description

REF615C_C HCFFAEAGANB2BAN1XC

The ABB REF615C_C HCFFAEAGANB2BAN1XC operates as a versatile protection and control device for busbar systems, utilizing proven differential protection principles with a robust processing platform. It continuously monitors current flows across bus sections, analyzing data from up to 24 current transformer (CT) inputs through its dedicated protection processor. This enables the relay to detect internal faults within 10-15 milliseconds while maintaining high security against false trips, a critical balance for industrial environments where nuisance outages can disrupt production.

REF615C_C HCFFAEAGANB2BAN1XC

Designed for hybrid substation environments, this relay supports both conventional hardwired inputs and digital communication via IEC 61850 Ed. 2.1, making it ideal for modernization projects where legacy equipment coexists with new installations. It handles various busbar topologies, including single-bus, double-bus, and sectionalized configurations, with configurable logic for bus transfer schemes and breaker failure protection. Advanced event recording captures fault data and waveform snapshots, providing valuable insights for post-incident analysis and system optimization in industrial settings.

REF615C_C HCFFAEAGANB2BAN1XC

Main features and advantages:

Selecting the ABB REF615C_C HCFFAEAGANB2BAN1XC delivers practical advantages tailored to industrial and hybrid substation environments. Its wide-range auxiliary power supply (24-250 V AC/DC) simplifies installation in facilities with varying power standards, reducing the need for additional power conversion equipment. The relay’s ruggedized design features enhanced vibration and shock resistance, ensuring reliable operation in industrial settings with heavy machinery or harsh conditions.

Engineered for integration flexibility, this relay bridges legacy and digital systems, allowing phased modernization of protection schemes without complete infrastructure overhauls. Its intuitive configuration via ABB’s PCM600 software reduces engineering time, with preset templates for common industrial busbar configurations. The dedicated cybersecurity processor ensures compliance with IEC 62443-4-2, protecting against unauthorized access while maintaining essential communication with SCADA and HMI systems—critical for industrial networks requiring both security and visibility.

REF615C_C HCFFAEAGANB2BAN1XC

Application fields:

The ABB REF615C_C HCFFAEAGANB2BAN1XC excels in applications where durability and compatibility are paramount. In industrial plants such as chemical processing facilities and manufacturing complexes, it protects busbars supplying multiple production lines, ensuring that electrical faults are isolated quickly to prevent widespread production stoppages. Its ability to withstand harsh environments with high electromagnetic interference makes it ideal for steel mills and mining operations.

In distributed generation facilities, including biomass plants and small-scale wind farms, the relay safeguards collector busbars connecting generation units to the grid, managing variable power flows while maintaining protection reliability. Utility substations undergoing gradual modernization rely on the ABB REF615C_C HCFFAEAGANB2BAN1XC to protect busbars during the transition from traditional to digital systems, ensuring continuous protection throughout the upgrade process.

REF615C_C HCFFAEAGANB2BAN1XC

Related products:

REF615C_C HCFFAEAGANB2BAN1YC – Variant with enhanced arc flash protection for high-risk industrial zones.

REF615C_C HCFFAEAGANB2BAN1ZC – Version with redundant Ethernet ports for critical communication paths.

REF615A_E HAFAABAAABE1BCA1XE – Advanced sibling model with higher CT input capacity for large substations.

REX640 – Bay control unit for seamless integration in hybrid automation systems.

REF610C11LCLR – Feeder protection relay for coordinated industrial network protection.

REF543KM127AAAA – Transformer protection relay for complete industrial substation coverage.

ABB PCS600 – Configuration and monitoring software optimized for REF615C_C series.

ABB Relion 670 Series Communication Adapter – Add-on for legacy protocol conversion.

Installation and maintenance:

Before installing the ABB REF615C_C HCFFAEAGANB2BAN1XC, verify the auxiliary power supply parameters to ensure compatibility with the relay’s wide-range input (24-250 V AC/DC). Check busbar configuration and connected equipment to determine appropriate CT sizing and connection schemes, ensuring accuracy of differential protection. For hybrid installations, confirm compatibility between existing SCADA protocols and the relay’s communication capabilities.

Ensure the mounting location provides adequate protection from environmental factors—while ruggedized, the relay performs best with proper enclosure in extremely dusty or humid environments. Allow 80mm clearance for ventilation and verify panel cutout dimensions (144x144mm) if using panel mount. For IEC 61850 integration, validate network infrastructure capacity and time synchronization sources to ensure reliable GOOSE messaging.

For maintenance, conduct monthly visual inspections of status indicators and review event logs using PCM600 software. Quarterly, check CT connections for tightness and corrosion, particularly in industrial environments with high humidity. Annually, update firmware to access the latest protection algorithms and security patches, and validate protection settings against current system loads.

Perform primary injection testing every two years to verify differential protection operation, and calibrate analog inputs if necessary. Conduct annual cybersecurity reviews, including password updates and verification of access control lists, to maintain IEC 62443 compliance. In harsh environments, inspect the relay’s physical condition semi-annually for signs of dust accumulation or environmental damage.
