REF615C_C HCFFAEAGANB2BAN1XC Numerical Protection Relay for Medium-Voltage Networks

Description

REF615C_C HCFFAEAGANB2BAN1XC

The REF615C_C HCFFAEAGANB2BAN1XC functions as an advanced numerical protection relay designed specifically for medium-voltage switchgear and distribution networks. It occupies a central position in the power system automation stack, combining protection, control, measurement, and communication functionalities into a single device.

REF615C_C HCFFAEAGANB2BAN1XC

This relay connects directly to current and voltage transformers in the power network, continuously analyzing electrical parameters to detect faults such as overcurrent, earth faults, and overloads. It communicates seamlessly with supervisory systems via industrial protocols, enabling remote monitoring and control. The REF615C_C HCFFAEAGANB2BAN1XC integrates with digital substations through IEC 61850 communication, supporting both sampled values and GOOSE messaging for interoperability with other intelligent electronic devices (IEDs). Its modular design allows customization with optional function blocks, adapting to specific network requirements while maintaining system integrity.

REF615C_C HCFFAEAGANB2BAN1XC

Main features and advantages:

Engineered for industrial ruggedness, the REF615C_C HCFFAEAGANB2BAN1XC ensures uninterrupted performance in harsh electrical environments. Its robust hardware design withstands voltage transients, electromagnetic interference, and extreme temperature fluctuations common in power substations, reducing the risk of false trips or protection failures. The relay’s advanced signal processing algorithms provide accurate fault detection even in noisy networks, minimizing unnecessary interruptions while ensuring rapid response to genuine faults.

The integration capabilities of the REF615C_C HCFFAEAGANB2BAN1XC significantly reduce engineering complexity. Its native support for IEC 61850 eliminates the need for proprietary communication converters, streamlining digital substation deployments. Pre-configured protection templates allow engineers to quickly adapt the relay to common applications such as feeder, transformer, or motor protection, reducing commissioning time. Built-in self-diagnostic features continuously monitor device health, providing early warnings of potential issues and enabling proactive maintenance that minimizes unplanned downtime.

REF615C_C HCFFAEAGANB2BAN1XC

Application areas:

The REF615C_C HCFFAEAGANB2BAN1XC is widely deployed across critical power infrastructure. In industrial plants, it protects medium-voltage feeders supplying motors, compressors, and production lines, ensuring uninterrupted operation of manufacturing processes. Its precise fault location capabilities reduce troubleshooting time, helping maintenance teams restore power quickly after incidents.

In renewable energy installations, such as wind farms and solar parks, the relay safeguards collection networks connecting generation assets to the grid. It coordinates with grid codes to manage voltage and frequency fluctuations, supporting stable integration of variable renewable energy.

In municipal power distribution systems, the REF615C_C HCFFAEAGANB2BAN1XC protects substations and feeder circuits, enhancing reliability for residential and commercial customers. Its ability to communicate with SCADA systems enables remote monitoring, allowing utilities to optimize network performance and reduce operational costs.

REF615C_C HCFFAEAGANB2BAN1XC

Related products:

REF615C_C HCFFAEAGANB2BAN2XC – Enhanced version with additional arc flash protection functionality.

REF615E – Economy model for standard protection applications with reduced feature set.

REF620 – Advanced relay for transformer protection with differential protection capabilities.

REF650 – Feeder protection relay with advanced automation functions for smart grids.

RET670 – Bay controller for integrating multiple protection devices in substation automation.

REF542plus – Legacy relay upgrade option, compatible with existing REF615C_C installations.

REL650 – Overcurrent and earth fault relay for distribution networks requiring basic protection.

REF615C_C HCFFAEAGANB2BAN1XC

Installation and maintenance:

Before installing the REF615C_C HCFFAEAGANB2BAN1XC, verify control power compatibility and ensure proper isolation from high-voltage components. Check that current and voltage transformer ratios match the relay’s input ranges to ensure measurement accuracy. For digital substations, confirm IEC 61850 configuration consistency with other IEDs and SCADA systems.

For ongoing maintenance, schedule annual verification of protection settings using certified test equipment to ensure compliance with network requirements. Inspect communication connections quarterly for tightness and corrosion, especially in humid environments. Utilize the relay’s event log and oscillography features to analyze fault events, which helps optimize protection coordination over time. Always backup configuration files before performing firmware updates, and ensure updates are compatible with existing system architecture.
