REF615A_E HAFAABAAABE1BCA1XE Advanced Digital Busbar Protection Relay

Description

REF615A_E HAFAABAAABE1BCA1XE

The ABB REF615A_E HAFAABAAABE1BCA1XE operates as a high-performance protection hub for busbar systems, utilizing advanced differential protection principles with a next-generation processing platform. It continuously monitors current flows across bus sections, analyzing data from up to 30 current transformer (CT) inputs via its multi-core processor architecture. This enables the relay to detect internal faults within 7-12 milliseconds while maintaining strict security against false operations—a critical capability given the destructive potential of busbar fault currents.

REF615A_E HAFAABAAABE1BCA1XE

Optimized for hybrid and fully digital substations, this relay natively supports IEC 61850 Ed. 2.1 with enhanced GOOSE and sampled value (SV) processing for sub-millisecond communication. It accommodates both conventional CT inputs and digital signals from non-conventional instrument transformers, providing flexibility during substation modernization projects. The relay’s configurable logic adapts to diverse busbar topologies, including double-bus with transfer switches, ring bus configurations, and breaker-and-a-half designs, while advanced disturbance recording captures high-resolution waveform data for post-event analysis and compliance reporting.

REF615A_E HAFAABAAABE1BCA1XE

Main features and advantages:

Selecting the ABB REF615A_E HAFAABAAABE1BCA1XE delivers significant advantages for critical busbar protection strategies. Its advanced processing architecture reduces fault detection time by up to 25% compared to previous generations, minimizing equipment exposure to damaging fault currents and extending asset lifespan. The relay’s dedicated security processor ensures compliance with IEC 62443 cybersecurity standards, protecting against unauthorized access and ensuring data integrity in connected substation environments.

Engineered for future readiness, this relay supports seamless integration with digital twins and substation automation systems, enabling predictive maintenance through continuous health monitoring and performance analytics. Its expanded memory capacity allows for extended fault recording and power quality data storage, supporting regulatory compliance and system optimization initiatives. Configurable via ABB’s PCM600 software with intelligent busbar configuration tools, the ABB REF615A_E HAFAABAAABE1BCA1XE simplifies complex protection schemes while reducing engineering time during commissioning and upgrades.

REF615A_E HAFAABAAABE1BCA1XE

Application fields:

The ABB REF615A_E HAFAABAAABE1BCA1XE excels in the most demanding busbar protection applications. In utility transmission substations, it protects main busbars facilitating power transfer between regional grids, where rapid fault isolation is critical to prevent widespread outages. Its ability to handle complex multi-section busbar configurations makes it ideal for large generating stations and interconnection hubs requiring maximum availability.

In industrial environments such as petrochemical complexes and manufacturing plants, the relay safeguards critical busbars supplying multiple production lines, ensuring localized faults don’t escalate into facility-wide shutdowns. Renewable energy parks with high concentrations of wind and solar resources rely on the ABB REF615A_E HAFAABAAABE1BCA1XE to protect collector busbars, managing bidirectional power flows while maintaining compliance with grid codes. Its rugged design ensures reliable operation in harsh environments with high electromagnetic interference and temperature variations.

REF615A_E HAFAABAAABE1BCA1XE

Related products:

REF615A_E HAFAABAAABE1BCA1YE – Variant with enhanced cybersecurity features for critical infrastructure applications.

REF615A_E HAFAABAAABE1BCA1ZE – Version with redundant power supplies for mission-critical installations.

REF615 HBFEAEAGNDA1ABA1XG – Premium sibling model with extended CT input capacity.

REX640 – Advanced bay control unit for seamless integration in digital substations.

RET670 – High-voltage feeder relay for coordinated protection in transmission networks.

REF543KM127AAAA – Transformer protection relay for substation-wide protection coordination.

ABB PQM600 – Power quality monitoring solution that integrates with REF615A_E data.

ABB Relion 670 Series Secure Gateway – Add-on for encrypted communication in critical networks.

REF615A_E HAFAABAAABE1BCA1XE

Installation and maintenance:

Before installing the ABB REF615A_E HAFAABAAABE1BCA1XE, verify the substation’s digital infrastructure compatibility, ensuring support for IEC 61850 Ed. 2.1 and adequate network bandwidth for sampled value transmission. Confirm auxiliary power supply stability, as voltage fluctuations can affect high-speed processing functions. For installations using digital instrument transformers, validate synchronization sources to ensure time alignment within 1 microsecond for accurate differential protection.

Check panel dimensions to accommodate the 144x144mm cutout and allow 100mm clearance for ventilation, as the advanced electronics generate moderate heat. Ensure CT secondary circuits are properly configured with appropriate burden resistors and shielded cabling to minimize noise, particularly when combining conventional and digital inputs. Verify cybersecurity settings align with site security policies before commissioning network connectivity.

For maintenance, conduct monthly reviews of health status indicators and event logs using PCM600 software’s diagnostic dashboard. Quarterly, verify time synchronization and test GOOSE message latency to ensure sub-10ms performance. Annually, perform firmware updates to access the latest protection algorithms and security patches, and validate protection settings against current system conditions.

Every two years, conduct primary injection testing to verify differential protection operation, and calibrate analog input circuits if conventional CTs are in use. Perform annual cybersecurity audits including password rotation, firmware integrity checks, and access control reviews to maintain IEC 62443 compliance.
