REF610C11LCLR Advanced Medium-Voltage Feeder Protection Relay

Description

REF610C11LCLR

The ABB REF610C11LCLR operates as a versatile protection and control device for medium-voltage feeders, positioned at the intersection of primary feeder equipment and the substation’s digital automation layer. It continuously monitors electrical parameters including phase and neutral currents, line-to-line and line-to-ground voltages, power quality metrics, and directional power flows, processing these data through advanced algorithms to detect faults and abnormal conditions. Specialized protection functions address overcurrents, earth faults, voltage sags, and frequency deviations, with directional elements to accurately identify fault locations in meshed or bidirectional networks.

REF610C11LCLR

This relay integrates seamlessly into next-generation substation architectures through enhanced IEC 61850 Ed. 2 compliance, supporting fast GOOSE messaging for inter-relay coordination and MMS for data exchange with SCADA and HMI systems. It features programmable logic controllers (PLC) functionality for custom control schemes, enabling adaptation to unique network requirements such as renewable energy integration or microgrid operation. Built-in power quality monitoring and disturbance recording tools provide granular insights into feeder performance, supporting network optimization and compliance reporting.

REF610C11LCLR

Main features and advantages:

Selecting the ABB REF610C11LCLR delivers substantial operational benefits tailored to modern feeder protection challenges. Its advanced directional protection algorithms accurately distinguish between internal and external faults in meshed networks, reducing fault clearing times and minimizing the impact of outages—critical advantages in urban grids and industrial campuses where feeder interconnections are common. The relay’s power quality monitoring capabilities eliminate the need for separate metering devices, providing comprehensive visibility into voltage harmonics, flicker, and unbalance that can affect sensitive equipment.

Engineered for flexibility, the ABB REF610C11LCLR supports seamless integration of distributed energy resources (DERs) by handling bidirectional power flows and adapting protection settings dynamically. This future-proof design reduces the need for hardware upgrades as network configurations evolve. Configurable via ABB’s intuitive PCM600 software, it simplifies complex protection schemes, reducing engineering time during commissioning and allowing for remote adjustments that minimize site visits and associated costs.

REF610C11LCLR

Application fields:

The ABB REF610C11LCLR excels in applications requiring advanced protection and smart grid capabilities. In utility distribution networks with integrated solar or wind generation, it manages bidirectional power flows and prevents islanding events, ensuring grid stability while maximizing renewable energy utilization. Its ability to handle complex network topologies makes it ideal for smart cities and urban distribution systems where feeder reliability directly impacts quality of life.

In industrial environments such as semiconductor plants and data centers, the relay protects critical feeder circuits from power quality issues that could disrupt sensitive equipment, supporting uninterrupted operation of process control systems. Renewable energy parks rely on the ABB REF610C11LCLR to protect collection feeders connecting multiple generation units, ensuring efficient energy transfer to the main grid while safeguarding equipment from fault conditions. Its wide operating temperature range ensures reliable performance in both indoor switchgear and harsh outdoor substations.

Related products:

REF610C11LCLR01 – Enhanced variant with advanced arc flash protection for high-risk industrial zones.

REF610C11LCLR02 – Version with built-in synchrocheck for feeder synchronization applications.

REF610C11HCNR01 – Base model with core feeder protection features for standard applications.

REX640 – ABB’s bay control unit that integrates seamlessly with REF610C11LCLR for complete bay automation.

RET670 – High-voltage feeder relay for coordinated protection in transmission-distribution interfaces.

REF543KM127AAAA – Companion transformer protection relay for substation-wide protection coordination.

PCM600 – Configuration and monitoring software optimized for REF610 series advanced features.

ABB Relion 670 Series Communication Module – Add-on for extended fiber optic communication capabilities.

Installation and maintenance:

Before installing the ABB REF610C11LCLR, verify the feeder’s operational parameters including maximum current rating, fault level, and presence of DERs to configure appropriate protection settings. Confirm auxiliary power supply compatibility (110-250 V AC/DC) and ensure network infrastructure supports required communication protocols, with IEC 61850 Ed. 2 recommended for optimal performance in digital substations. Check panel cutout dimensions (144x144mm) and allow 70mm clearance for ventilation, as the advanced electronics generate slightly more heat than basic models.

For maintenance, conduct monthly reviews of status indicators, event logs, and power quality metrics using PCM600 software. Quarterly, inspect communication connections and terminal blocks for corrosion or 松动，paying special attention to current transformer (CT) and voltage transformer (VT) connections. Annually, validate protection settings against current network conditions, update firmware to access new features, and perform a full functional test. For networks with DERs, schedule bi-annual reviews of directional element calibration to ensure accurate operation with bidirectional flows.
