REF610C11HCNR01 Medium-Voltage Feeder Protection Relay

Description

REF610C11HCNR01

The ABB REF610C11HCNR01 functions as a dedicated protection and control device for medium-voltage feeders, positioned between the feeder’s current and voltage transformers and the substation control system. It continuously monitors key electrical parameters such as phase currents, neutral currents, line voltages, and power flows, analyzing these data in real time to detect abnormal conditions. Advanced protection algorithms identify faults including overcurrents, short circuits, earth faults, and voltage disturbances, initiating rapid tripping actions to isolate faulty feeders and prevent fault propagation.

REF610C11HCNR01

This relay integrates seamlessly into modern substation automation architectures through support for IEC 61850 Ed. 2, enabling efficient data exchange with SCADA systems, HMI platforms, and other protection relays. It features configurable logic to adapt to various feeder types—including radial, looped, and meshed configurations—with customizable protection schemes for different network topologies. Built-in event recording and waveform capture tools provide detailed fault analysis, supporting post-incident investigations and system optimization.

REF610C11HCNR01

Main features and advantages:

Choosing the ABB REF610C11HCNR01 brings significant operational advantages to feeder protection strategies. Engineered specifically for feeder applications, its adaptive protection algorithms reduce false tripping caused by transient conditions like inrush currents or lightning strikes—common issues with generic relays that can lead to unnecessary outages. This precision ensures reliable protection while maximizing feeder availability, a critical benefit in industries where power interruptions disrupt production processes or critical services.

The relay’s comprehensive monitoring capabilities eliminate the need for separate metering devices and fault recorders, simplifying system architecture and reducing installation costs. Its ability to communicate seamlessly with other substation devices enables coordinated protection schemes, minimizing fault clearing times and reducing stress on network equipment. Configurable via ABB’s user-friendly PCM600 software, the ABB REF610C11HCNR01 reduces engineering time during setup and allows for easy adjustments as network loads or configurations change over time.

REF610C11HCNR01

Application fields:

The ABB REF610C11HCNR01 excels in applications where feeder reliability directly impacts operational continuity. In utility distribution networks, it protects overhead lines and underground cables connecting substations to residential, commercial, and industrial areas, minimizing the number of customers affected during fault conditions. Its ability to handle looped and meshed network configurations makes it ideal for urban power grids requiring high reliability and flexibility.

In industrial complexes such as manufacturing plants and refineries, the relay safeguards critical feeder circuits powering production equipment, ensuring uninterrupted operation of process control systems. Commercial facilities like data centers and hospitals rely on the ABB REF610C11HCNR01 to protect feeder lines supplying backup power systems, enhancing resilience against utility grid disturbances. Its wide operating temperature range ensures reliable performance in both indoor switchgear and outdoor substation environments.

REF610C11HCNR01

Related products:

REF610C11HCNR02 – Enhanced version with built-in synchrocheck function for feeder synchronization applications.

REF610C11HCNR03 – Variant with advanced arc flash protection for high-risk industrial environments.

REF543KM127AAAA – Companion transformer protection relay for coordinated substation protection.

RET670 – High-voltage feeder relay that integrates with REF610 for complete system protection.

ABB REX640 – Bay control unit that communicates seamlessly with REF610C11HCNR01.

PCM600 – ABB’s configuration software for programming and monitoring REF610 series relays.

REF610C11HCNR04 – Redundant power supply version for mission-critical feeder applications.

REF610C11HCNR01

Before installing the ABB REF610C11HCNR01, verify the feeder type (overhead line, cable, or mixed) and network configuration to ensure proper protection logic setup. Confirm auxiliary power supply compatibility (110-250 V AC/DC) and check that communication networks support required protocols, with IEC 61850 recommended for modern digital substations. Ensure panel cutouts match the 144x144mm dimensions and allow at least 50mm clearance around the device for adequate ventilation, as excessive heat can affect measurement accuracy and performance.

For ongoing maintenance, conduct monthly reviews of status indicators and alarm logs to identify potential issues early. Quarterly, inspect current transformer (CT) and voltage transformer (VT) connections to ensure secure and corrosion-free contacts. Annually, use PCM600 software to validate protection settings against current network conditions and update firmware to access the latest protection algorithms and security enhancements. Perform a full functional test every two years to verify tripping logic and communication functionality.
