REC670 1MRK002814-AC Advanced Substation Protection and Control IED

Description

REC670 1MRK002814-AC

The ABB REC670 1MRK002814-AC functions as a high-performance protection and control IED, serving as the intelligent core for transformer, feeder, and busbar protection in medium to high-voltage substations. Positioned at the center of modern substation automation architectures, it connects to current transformers (CTs), voltage transformers (VTs), and substation equipment to monitor electrical parameters in real time, detect faults within milliseconds, and execute protective actions to isolate disturbances.

This upgraded model integrates seamlessly with ABB’s latest MicroSCADA Pro and Symphony Plus systems, as well as third-party SCADA/EMS platforms through its enhanced communication interfaces. The ABB REC670 1MRK002814-AC features advanced protection algorithms including improved transformer differential protection with adaptive restraint, high-speed overcurrent detection, and enhanced earth fault protection, while its expanded control logic capabilities enable more complex automated sequences, further optimizing substation operations.

Main features and advantages:

Choosing the ABB REC670 1MRK002814-AC brings significant advancements to power protection systems. Its upgraded processor enables fault detection and isolation within 8-15 milliseconds—faster than its predecessor—minimizing fault impact and reducing equipment stress during network disturbances. Unlike earlier models, this IED offers enhanced adaptive protection capabilities that automatically adjust settings based on real-time network conditions, making it ideal for grids with high renewable energy penetration where load profiles fluctuate frequently.

The device’s reinforced ruggedized design extends the operating temperature range to 75°C, ensuring reliable performance in extreme environmental conditions, while improved EMI/EMC immunity enhances operation in high-electromagnetic interference environments typical of modern substations. Its compliance with IEC 61850 Ed. 2.1 ensures seamless integration with the latest smart grid technologies and digital substation architectures, supporting future-proofing of infrastructure. For maintenance teams, advanced diagnostic features include improved waveform capture with higher resolution, automated test sequences, and predictive health monitoring, enabling more proactive maintenance and reducing unplanned downtime.

Application fields:

The ABB REC670 1MRK002814-AC excels in the most demanding power system applications, particularly those requiring advanced protection and smart grid integration. In utility smart substations, it provides enhanced protection for transformers and feeders while supporting advanced functions like automatic network reconfiguration and distributed energy resource (DER) management. Its improved processing power makes it ideal for industrial power systems in large manufacturing complexes and data centers, where it protects critical equipment while integrating with energy management systems for optimized power usage.

In renewable energy installations such as large-scale solar farms and offshore wind parks, the device ensures safe integration of variable generation into the main grid through enhanced fault ride-through capabilities and improved synchronization logic. For urban distribution networks with high reliability requirements, the ABB REC670 1MRK002814-AC offers advanced features like self-healing network support and enhanced fault location accuracy, enabling utilities to achieve faster restoration times and improve overall service quality.

Related products:

ABB REC670 1MRK002814-AB – Previous generation with baseline protection features for standard applications.

ABB REL670 1MRK003129-AC – Advanced transformer protection IED with enhanced differential logic.

ABB RED670 1MRK003130-AC – Upgraded busbar protection IED with high-speed communication.

ABB REX640 1MRK004221-AC – Compact IED with REC670-derived features for secondary distribution.

ABB COM600 1MRK004138-AC – Enhanced communication gateway with gigabit capability.

ABB M103-T – Next-gen merging unit with higher sampling rates for digital substations.

ABB HMI602 1MRK005212-AC – Touchscreen HMI panel with improved configuration tools.

ABB PQ3000 1MRK006663-AC – Advanced power quality analyzer with IEC 61850 Ed. 2.1 support.

Installation and maintenance:

Before installing the ABB REC670 1MRK002814-AC, verify that the auxiliary power supply can deliver stable output during voltage transients, as the upgraded processor has slightly higher power requirements. Ensure CT and VT connections are properly sized for the device’s enhanced input range and that polarity is correctly maintained to ensure accurate differential protection operation. Check network infrastructure for gigabit Ethernet compatibility to fully utilize the device’s high-speed communication capabilities. Confirm the mounting location allows for adequate airflow, particularly in applications approaching the 75°C operating limit, and that fiber optic cabling meets recommended specifications for reliable high-speed data transmission.

For ongoing maintenance, leverage the device’s enhanced diagnostic capabilities by establishing monthly reviews of predictive health indicators and event logs. Perform semi-annual verification of adaptive protection settings to ensure they align with current network conditions, especially after significant grid modifications or DER additions. Update firmware through ABB’s secure portal at least annually to access the latest protection algorithms and security enhancements, scheduling updates during planned outages. Calibrate analog input channels every two years using certified test equipment to maintain measurement accuracy critical for protection operation.
