REC670 1MRK002814-AB Substation Protection and Control IED

Description

REC670 1MRK002814-AB

The ABB REC670 1MRK002814-AB functions as a multi-functional protection and control IED, serving as the central intelligence for transformer and feeder protection in medium to high-voltage substations. Positioned at the core of substation automation architecture, it connects to current transformers (CTs), voltage transformers (VTs), and substation equipment to monitor electrical parameters continuously, detect faults within milliseconds, and initiate protective actions to isolate faulty sections. The device integrates seamlessly with ABB’s MicroSCADA Pro and Symphony Plus systems, as well as third-party SCADA and EMS platforms through its extensive communication interfaces.

REC670 1MRK002814-AB

This connectivity enables real-time data exchange, remote configuration, and centralized monitoring of protection settings and system status. The ABB REC670 1MRK002814-AB features advanced protection algorithms for transformer differential protection, overcurrent, earth fault, and thermal overload protection, while its built-in control logic allows for automated sequence of operations, enhancing substation operational efficiency.

REC670 1MRK002814-AB

Main features and advantages:

Selecting the ABB REC670 1MRK002814-AB delivers significant operational advantages to power distribution systems. Its high-speed processing capabilities enable fault detection and isolation within 10-20 milliseconds, minimizing fault duration and reducing equipment damage during network disturbances. Unlike traditional protection relays with fixed functionality, this IED offers configurable protection schemes, allowing engineers to tailor settings to specific network requirements—from radial distribution feeders to complex meshed networks.

The device’s ruggedized design, including reinforced isolation and surge withstand capabilities, ensures reliable operation in the harsh electromagnetic environments typical of high-voltage substations. Its compliance with IEC 61850, the global standard for substation automation, simplifies integration with smart grid initiatives and enables interoperability with multi-vendor systems, reducing lifecycle costs. For maintenance teams, the advanced diagnostic features provide detailed event records, waveform captures, and self-monitoring capabilities, enabling faster post-fault analysis and reducing mean time to repair. Additionally, its support for remote configuration eliminates the need for on-site visits for routine setting changes, improving operational efficiency.

REC670 1MRK002814-AB

Application fields:

The ABB REC670 1MRK002814-AB excels in protecting critical assets across diverse power system applications. In utility substations, it provides primary protection for distribution transformers, ensuring rapid isolation during internal faults while maintaining supply to unaffected areas. Its ability to handle complex protection logic makes it ideal for industrial power systems in manufacturing plants and refineries, where it protects critical equipment like motors, generators, and capacitor banks from electrical faults.

In renewable energy installations, such as wind farms and solar parks, the device protects collection system feeders and step-up transformers, ensuring safe integration with the main grid while maximizing energy export. For urban distribution networks with high reliability requirements, the ABB REC670 1MRK002814-AB supports advanced features like adaptive protection and fault location, enabling utilities to reduce outage durations and improve customer satisfaction. Its reliability in continuous operation makes it a critical component in mission-critical power systems where network stability directly impacts public safety and economic activity.

REC670 1MRK002814-AB

Related products:

ABB REC650 1MRK002810-AB – Feeder protection IED for distribution network applications.

ABB REL670 1MRK003129-AB – Advanced version with enhanced transformer protection features.

ABB RED670 1MRK003130-AB – Busbar protection IED for substation bus protection.

ABB REX640 1MRK004221-AB – Compact protection IED for secondary distribution networks.

ABB COM600 1MRK004138-AB – Communication gateway for IEC 61850 network integration.

ABB M102-T – Merging unit for analog signal conversion in digital substations.

ABB HMI602 1MRK005212-AB – Local HMI panel for direct IED configuration and monitoring.

ABB PQ3000 1MRK006663-AB – Power quality analyzer for enhanced disturbance monitoring.

REC670 1MRK002814-AB

Installation and maintenance:

Before installing the ABB REC670 1MRK002814-AB, verify that the auxiliary power supply matches the device’s requirements (110/220 V DC or 100/240 V AC) and that it provides stable operation during voltage fluctuations. Ensure CT and VT connections are correctly sized and wired according to polarity requirements to prevent protection misoperation. Check network infrastructure compatibility for IEC 61850 communication, ensuring proper switch configuration and sufficient bandwidth for GOOSE messages and sampled values. Confirm the mounting location provides adequate cooling, with at least 50 mm clearance around the device, and that environmental conditions remain within the -40 to 70 °C operating range.

For ongoing maintenance, establish a quarterly review schedule of protection logs and event records to identify emerging issues or configuration discrepancies. Perform annual verification of protection settings against current network requirements, updating as needed through the IEC 61850 configuration tool. Inspect physical connections annually, ensuring terminal blocks remain tight and free from corrosion, particularly in humid environments. Keep firmware updated through ABB’s secure portal, applying updates during planned outages to avoid disrupting protection functionality.
