PROSOFT MVI69- PDPMV1 High Performance Network Interface Module

Description

PROSOFT MVI69-PDPMV1 is a high-performance network interface module that serves as a gateway between the CompactLogix/MicroLogix platform and the PROFIBUS network. It fully supports the master specification defined by IEC 61158, ensuring compatibility with a wide range of slave devices that comply with the PROFIBUS standard.

MVI69-PDPMV1

This module is capable of processing non cyclic parameter data transmission through Class 1 or Class 2 DPV1 services, facilitating communication with slave devices that comply with the PROFIBUS DPV0/V1 standard. The data transmission from the controller to the module is asynchronous and independent of the I/O data transmission on the PROFIBUS network, which helps ensure the integrity of the data stream. The module is equipped with a user-defined database for storing the data required by the protocol. MVI69-PDPMV1 is designed for easy integration into CompactLogix and MicroLogix systems, perfectly adapting to available slots and utilizing the native programming environment of these controllers. This module has built-in diagnostic functions that can continuously monitor its operating status and network communication. Once potential problems are discovered, it will promptly issue alerts to operators.

MVI69-PDPMV1

Technical specifications:
Model MVI69-PDPMV1
Brand PROSOFT
Type PROFIBUS DP-V1 main station network interface module
Input voltage 10-30 VDC
Working temperature range -40 ° C to 75 ° C
Installation method: Install in the CompactLogix or MicroLogix slot
Interface/Bus PROFIBUS network interface, compatible with CompactLogix and MicroLogix
Certification standards CE, UL, cUL, ATEX
Supports protocols PROFIBUS DP-V0 and DP-V1
Typical power consumption backplane current load: 450 mA @ 5 VDC, 20 mA @ 24 VDC

contact information
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

MVI69-PDPMV1

Main features and advantages:
Its sturdy design allows it to operate for a long time even in harsh industrial environments, reducing the need for frequent maintenance and replacement. This module supports a wide range of slave devices that comply with the PROFIBUS standard, providing flexibility to easily integrate new devices into existing systems without the need for large-scale modifications. The combination of high-speed data transmission capability and asynchronous data processing reduces data latency, thereby achieving faster response times and improving production efficiency. This module also has user-friendly programming features, such as example ladder diagram files and additional instructions, simplifying the configuration process, reducing engineering costs, and accelerating project implementation. With the help of MVI69-PDPMV1, industrial facilities can optimize their automation processes, improve operational efficiency, and reduce costs in the long run.

MVI69-PDPMV1

Application areas:
In automotive manufacturing factories, it is used to connect CompactLogix based control systems with PROFIBUS enabled robotic arms, sensors, and actuators on production lines. This seamless communication ensures precise control over the manufacturing process, thereby improving product quality and production speed. Continuous operation and real-time monitoring are crucial in the oil and gas industry, and MVI69-PDPMV1 enables communication between different control systems and monitoring equipment in refineries and offshore platforms. This helps to better manage the extraction, processing, and transportation of oil and gas, improving overall operational safety and efficiency. In the food and beverage industry, it helps integrate various processing equipment using PROFIBUS protocol, ensuring appropriate control and monitoring of the food production process from mixing, cooking to packaging, while maintaining strict hygiene and quality standards.

MVI69-PDPMV1

Related products:
MVI69- GSC: Focused on providing serial communication gateway services, suitable for applications that require serial connectivity.
MVI69- AGS: Designed specifically for analog gateway services, suitable for analog data communication between different devices.
MVI69- PBM: Provides communication support for Modbus Plus networks and offers another option for Modbus based applications.
MVI69- FCM: Supports fiber optic network communication, suitable for applications that require long-distance and high-speed data transmission.
MVI69- MCM: Provides multi-channel communication support, suitable for situations with a large number of devices and more complex network settings.

Installation and maintenance:
Before installing PROSOFT MVI69-PDPMV1 , it is essential to verify the compatibility of the CompactLogix or MicroLogix controller with the module. Check the available slots, power capacity (MVI69- PDPMV1 requires 450 mA @ 5 VDC and 20 mA @ 24 VDC power supplies), and any specific requirements for module installation. Ensure that the network configuration is set correctly, including IP address (if applicable) and subnet mask, to achieve seamless communication with PROFIBUS devices. In addition, it is necessary to ensure that the firmware of MVI69-PDPMV1 is the latest version, as firmware updates can provide vulnerability fixes, performance improvements, and new features.

For daily maintenance, regularly check the status indicator lights on the module, which can indicate the operating status of the module, such as network connection and data transmission. Regularly check the connections to ensure they are secure and free from corrosion or damage. Following PROSOFT’s recommendations for annual diagnostic testing can help identify potential issues early and maintain optimal module performance.
