PROSOFT MVI56-PDPMV1 is an important input/output module that bridges the gap between PROFIBUS networks and ControlLogix processors. It supports complete master station specifications that comply with the IEC 61158 standard, which is a significant advantage in industrial environments.
MVI56-PDPMV1
This module can use Class 1 or Class 2 DPV1 services to handle non cyclic parameter data transmission, making it easy to communicate with slave devices that comply with the PROFIBUS DPV0/V1 standard. The data transmission from the processor to the module is asynchronous with the I/O data transmission on the PROFIBUS network, which helps ensure the integrity of the data stream. The module internally stores a user-defined database for storing the data required by the protocol. Its design is compatible with the 1756 backplane and can perfectly adapt to single slot configurations. The operation of this module is very convenient, using a ladder diagram to achieve data transmission between the module and the processor, and comes with an example ladder diagram file (additional instructions) for easy implementation.
MVI56-PDPMV1
Main features and advantages:
It has stable performance in industrial environments and can ensure long-term operation without frequent maintenance. This module supports a wide range of slave devices that comply with the PROFIBUS standard, providing great flexibility for system design. You can easily integrate new devices into existing infrastructure without the need for large-scale renovations. The module has high-speed data transmission capability and adopts asynchronous data processing method, which reduces data latency and makes the response time of automated processes faster, thereby directly improving production efficiency. The accompanying example ladder diagram file and additional instructions simplify the programming and configuration process, reduce engineering costs, and enable your project to run faster.
MVI56-PDPMV1
Technical specifications:
Model MVI56-PDPMV1
Brand PROSOFT
Type PROFIBUS DP-V1 main station network interface module
Input voltage 10-24 VDC
Working temperature range: 0 ° C to 60 ° C (32 ° F to 140 ° F)
Installation method: Install on the ControlLogix 1756 backplane (single slot)
Interface/Bus PROFIBUS network interface, compatible with 1756 backplane
Certification standards ANSI/ISA, cUL, IEC61010, ATEX, EN60079 (please refer to the product manual for a complete list)
Supports protocols PROFIBUS DP-V0 and DP-V1
Typical power consumption backplane current load: 800 mA @ 5.1 VDC, 3 mA @ 24 VDC
contact information
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
MVI56-PDPMV1
Application areas:
In the manufacturing industry, it is used to connect PLC systems based on ControlLogix with sensors, actuators, and other peripheral devices that support PROFIBUS, ensuring that all components on the production line can communicate effectively and achieve seamless production. For example, it can connect a robotic arm running on PROFIBUS with an overall control system based on ControlLogix. Continuous operation and real-time monitoring are crucial in power generation facilities, and MVI56-PDPMV1 can achieve communication between different control systems and monitoring equipment, thereby better managing power generation, distribution, and grid stability. In the chemical industry, it helps to integrate various chemical processing equipment using PROFIBUS protocol, ensuring appropriate control and monitoring of chemical reactions and material handling processes.
MVI56-PDPMV1
Related products:
MVI56- MBP: Focusing on Modbus Plus communication, it provides another option for applications that require Modbus connectivity.
MVI56E – SIE: It is designed specifically for Ethernet communication with Siemens S7 controllers, providing solutions for different network requirements.
ILX56- PBM: Equipped with enhanced features or more suitable for specific application scenarios.
MVI56- MCM: Provides multi-channel communication support, which is very advantageous for situations with a large number of devices and more complex network settings.
MVI56- MNETCR: Supports communication via Modbus TCP/IP protocol, providing options for applications that rely on Ethernet based Modbus communication.
MVI56-PDPMV1
Installation and maintenance:
Before installing PROSOFT MVI56-PDPMV1, it is essential to ensure that the ControlLogix backplane is compatible with the module. Check the available slots and power capacity of the backplane (MVI56- PDPMV1 requires 800 mA of available power, 5.1 VDC voltage, and 3 mA of 24 VDC power), as well as any specific requirements for module installation. Verify network configuration, including IP address settings (if applicable) and subnet masks, to ensure seamless communication with PROFIBUS devices. In addition, it is necessary to ensure that the firmware of MVI56- PDPMV1 is the latest version, as firmware updates can provide vulnerability fixes, performance improvements, and new features.
For daily maintenance, regularly check the status indicator lights on the module. These indicator lights can provide valuable information about the module’s operational status, such as network connectivity and data transmission activity. Regularly check the connections to ensure they are secure and free from corrosion or damage. Following PROSOFT’s recommendations for annual diagnostic testing can help identify potential issues early and maintain optimal module performance.
