PROSOFT MVI56-MBP Key Network Interface Module

Description

PROSOFT MVI56-MBP is a key network interface module in the industrial automation stack. It serves as a gateway between the Allen Bradley ControlLogix backplane and the Modbus Plus network.

MVI56-MBP

This module supports both master and slave devices, making it easy to connect with Modicon processors and numerous other Modbus compatible devices. It is capable of converting data between the ControlLogix system and Modbus Plus network, achieving seamless data exchange. This module is equipped with two RJ45 communication ports for Modbus, which helps to achieve high-speed data transmission. In addition, it is equipped with an RJ45 serial configuration port (CFG) for easy setup. MVI56-MBP has built-in diagnostic functions that can continuously monitor its own operation and network communication, and issue alerts to operators before any potential issues cause serious interruptions. It also supports asynchronous data exchange, which is crucial for maintaining real-time communication in industrial processes.

MVI56-MBP

Technical specifications:
Model MVI56-MBP
Brand PROSOFT
Type Modbus Plus Dual Port Network Interface Module
The installation method is designed to be installed inside the Allen Bradley ControlLogix backplane
Aspect 163 × 38 × 58 millimeters
Weight 1.35 kilograms
Interface/Bus Modbus Plus Network Interface, RJ45 Port for Communication and Configuration
comply with
Supported protocols Modbus Plus protocol

contact information
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

MVI56-MBP

Main features and advantages:
Its sturdy design ensures long-term operation even in harsh industrial environments, reducing the need for frequent replacement and maintenance. The user-friendly configuration interface significantly reduces engineering costs. Engineers do not need to spend a lot of time on complex programming and setup, but can quickly configure modules to meet their specific application needs. This also means that new projects can be launched and run in a shorter amount of time, thereby accelerating the time to market for products or services. This module supports both master and slave devices, providing flexibility for system design and allowing for more complex and customized automation settings. By achieving seamless communication between different types of industrial equipment, MVI56-MBP helps optimize production processes, thereby increasing productivity and reducing operating costs.

MVI56-MBP

Application areas:
In manufacturing plants, it is used to connect PLC systems based on ControlLogix with sensors, actuators, and other peripheral devices that support Modbus Plus. This ensures effective communication between all components on the production line, thereby achieving smooth and efficient production. For example, it can be used to connect a Modbus Plus based robotic arm to a ControlLogix based overall control system. Continuous operation and real-time monitoring are crucial in power plants, and MVI56-MBP supports communication between different control systems and monitoring equipment. This helps to better manage power generation, distribution, and grid stability. In water treatment plants, it helps to integrate various water treatment equipment using different communication protocols, ensuring proper control and monitoring of the water treatment process.

MVI56-MBP

Related products:
MVI56- MCM – Provides multi-channel communication support, which is very useful for more complex network settings that require connecting a large number of devices.
MVI56- MNETCR – focuses on promoting communication through Modbus TCP/IP protocol, providing an alternative solution for applications that require Ethernet based Modbus communication.
MVI46- MBP – It is designed for different control platforms or with different port configurations, providing options for users with specific system requirements.
MVI56E – MCMXT – This model may have enhanced features and may be more suitable for high-performance or extended range applications. M
VI94- DFM – can be optimized for specific types of data flow management, such as processing large amounts of data in a more efficient way.

Installation and maintenance:
Before installing PROSOFT MVI56-MBP, it is essential to ensure that the Allen Bradley ControlLogix backplane is compatible with the module. Please check the backplane specifications for available slots, power capacity, and any specific requirements for module installation. Please verify that the network configuration (including IP addressing (if applicable) and subnet mask) is set correctly to ensure seamless communication with Modbus Plus devices. In addition, please ensure that the firmware of MVI56-MBP is the latest version, as this can provide error fixes, performance improvements, and additional features.

For continuous maintenance, please regularly check the status LED on the module. These LEDs can provide valuable information about the module’s operational status, such as network connectivity and data transmission activity. Regularly check RJ45 connections to ensure they are secure and free from corrosion or damage. Following PROSOFT’s recommendations for annual diagnostic testing can help identify any potential issues early and maintain optimal module performance.
