Prosoft 5205- DFNT – PDPS PROFIBUS DP Slave Gateway

Description

Prosoft 5205- DFNT – PDPS is an EtherNet/IP to PROFIBUS DP slave gateway. It serves as a bridge between EtherNet/IP network devices and PROFIBUS master devices. This independent module is designed specifically for DIN rail installation, equipped with an Ethernet port and a configurable PROFIBUS DP slave DB9F port.

5205- DFNT – PDPS

5205- DFNT – PDPS – The EtherNet/IP protocol driver within PDPS supports the explicit message implementation of this protocol. It can be configured by users as both a client and a server, making EtherNet/IP ports a highly flexible data transmission tool. On the other hand, the PROFIBUS DP slave protocol driver supports the implementation of PROFIBUS V0 slave. This enables robust data transmission between the ProLinx module (i.e. 5205 DFNT PDPS) and Siemens PLC or other hosts. The user configurable data mapping and DP port operations make this interface easy to use and powerful.

5205- DFNT – PDPS

Technical specifications:
Model  5205- DFNT – PDPS
Brand Prosoft
Type EtherNet/IP to PROFIBUS DP Slave Gateway
Input voltage 5.1 VDC
Operating temperature range -40 ° F to 185 ° F (-40 ° C to 85 ° C)
Installation method: DIN rail
Size standard: 5.20 inches high x 2.07 inches wide x 4.52 inches deep (13.2 cm x 5.25 cm x 11.48 cm); Expansion: 5.20 inches high x 2.73 inches wide x 4.52 inches deep (13.2 cm x 6.934 cm x 11.48 cm)
Weight 0.19 pounds (0.085 kilograms)
Interface/Bus Ethernet PROFIBUS DP
Compliance [not provided in the given data, please refer to the product manual]
Supports EtherNet/IP and PROFIBUS DP protocols
Typical power consumption backplane current load: 800 mA @ 5.1 VDC

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

5205- DFNT – PDPS

Main features and advantages:
This product is designed for industrial grade reliability, ensuring long-term stable operation even in harsh environments. It can bridge EtherNet/IP and PROFIBUS DP networks, significantly reducing engineering costs. Engineers do not need to design complex customized protocol conversion solutions, they only need to integrate the gateway into existing systems.

The gateway also enhances system flexibility. It allows for easy addition of new devices to the network, whether they are based on EtherNet/IP or PROFIBUS DP. This is particularly useful for industries with constantly evolving technology, where more advanced new equipment needs to be integrated into existing automation infrastructure. 5205- DFNT – PDPS also helps improve productivity. By achieving seamless data transmission between two networks, it ensures that all devices in industrial settings can communicate efficiently, reducing delays and errors in the control process.

5205- DFNT – PDPS

Application areas:
In the manufacturing industry, it plays an important role in integrating different types of production equipment. For example, it can connect EtherNet/IP based robotic arms with conveyor belts controlled by PROFIBUS DP. This integration allows for precise coordination of the manufacturing process, thereby improving productivity and product quality.

In the oil and gas industry, harsh operating conditions are the norm, and 5205- DFNT – PDPSis used to connect sensors and control systems using different network protocols. It can achieve real-time monitoring and control of key processes such as oil extraction and refining, ensuring safe and efficient operation.

The power plant also relies on 5205- DFNT – PDPS. It helps to integrate power generation equipment, such as turbines and generators, which may use different network protocols for control and monitoring. By promoting seamless communication between these devices, it helps maintain grid stability and reduce power outages.

5205- DFNT – PDPS

Related products:
Prosoft 5205- DFNT – PDPMV1: This gateway provides additional features such as support for PROFIBUS DPV1, which may be necessary for more complex industrial applications that require enhanced diagnostic and control capabilities.
Prosoft 5005- DFNT – PDPS: A more compact version suitable for applications with limited space but still requiring EtherNet/IP to PROFIBUS DP slave gateway functionality.
Prosoft 5205- DFNT – MPI: If your system needs to communicate with Siemens S7-300/400 PLC through MPI (Multipoint Interface), this module can serve as a good alternative as it bridges EtherNet/IP and MPI networks.

Installation and maintenance:
Before installing Prosoft 5205- DFNT – PDPS, it is essential to verify its compatibility with existing network infrastructure. Check the network configuration settings, such as IP address, subnet mask, and gateway settings, to ensure they meet the requirements of the module. Meanwhile, confirm that the available power supply is 5.1 VDC and capable of withstanding a backplane current load of 800 mA.

For continuous maintenance, regularly monitor the LED indicator lights on the module. These indicator lights provide visual cues about power status, module status, application status, serial port activity, and serial port error status. Regularly check the Ethernet and PROFIBUS DP connections to ensure they are secure and free from corrosion. It is also recommended to regularly check for available firmware updates. These updates can improve performance, fix vulnerabilities, and add new features.
