Name: PM866 3BSE050200R1 Fault tolerant CPU module | Qiming Automation
Brand: ABB
Price: 5694.00 CNY
Availability: InStock

Description

PM866 3BSE050200R1 Product Description:
ABB PM866 3BSE050200R1 reshapes the performance boundaries of mid-range controllers. As the flagship CPU of ABB Compact 800M series, it achieves deterministic control at the mainframe level in a compact body mounted on DIN rails.

PM866 3BSE050200R1

Unlike standard PLCs that are difficult to handle mixed critical tasks, this model supports real-time Linux and IEC 61131-3 logic parallel operation. This means that you can perform:

Safety interlock (highest SIL2 level)
Predictive maintenance algorithm
OPC UA Data Release
Its Triple Modular Redundancy (TMR) option makes it the first choice for boiler protection systems where 99.9997% availability is not only an advantage, but also a legal requirement.

PM866 3BSE050200R1

Main features and advantages:
Key performance, precise victory
Equipped with a quad core ARM Cortex-A72 processor and 4GB DDR4 ECC memory, the PM866 3BSE050200R1 can easily handle over 10000 labels. The secret lies in a dedicated industrial protocol coprocessor that can offload Modbus TCP and PROFINET IO traffic from the main CPU.

Specially designed for harsh environments
-40 ° C low-temperature start-up capability (essential for Arctic oil fields)
50G impact resistance performance (tested according to MIL-STD-202G standard)
Conformal coated PCB resists H2S corrosion in refineries
Future oriented connectivity
The integrated 2.5GbE port supports time sensitive networks (TSN), while the M12 X encoded connector ensures the vibration resistance of fieldbus connections. Need to integrate old equipment? The optional CI867 module can directly add PROFIBUS DP without the need for an external gateway.

PM866 3BSE050200R1

Technical specifications:
Model ABB PM866 3BSE050200R1
Architecture ARM Cortex-A72 (64 bit)
Main frequency 1.8 GHz (turbo frequency up to 2.4 GHz)
4GB DDR4+32GB eMMC memory
Cycle time standard 1 millisecond, fast mode 100 microseconds
Protocol OPC UA PubSub, MQTT Sparkplug
Environmental Class IEC 60721-3-4 Class 4X
Redundant design with optional TMR configuration
Certified UL Class I Div 2, DNV GL

PM866 3BSE050200R1

Related products:
PM865- I/O Capacity Reduction
SD832- Secure Authentication Digital Input Module
TB811- Terminal Base, Supports Hot Plug Maintenance
AI825-16 channel analog input module with HART transparent transmission function
EXC100- Expansion chassis, supporting additional I/O modules

Installation and maintenance:
Thermal management is crucial – the module consumes 28W at full load. When the ambient temperature exceeds 55 ° C, it is recommended to use ABB’s recommended heat sink (3BSE050200R100). For vibration environments, M4 thread locking adhesive should be applied to the DIN rail buckle.
Configuration tip: ABB PM866 3BSE050200R1 supports parallel task execution. Allocate time sensitive functions (such as PID loops) to the fast task domain (baseline rate of 100 microseconds), while placing non critical tasks (such as data recording) in the standard task domain.
