PFTL101B 2.0KN 3BSE004185R1 Product Description:
PFTL101B 2.0KN 3BSE004185R1 is a high-performance sensing module that utilizes strain gauge technology at its core. When mechanical force is applied, the strain gauges inside the module will deform, thereby changing their resistance values. This change is then amplified, conditioned, and converted into a high-precision electrical signal corresponding to the magnitude of the applied force. This module supports multiple industry standard communication protocols, including Profibus DP and Modbus RTU, and can seamlessly integrate with various automation systems. It can easily integrate into the sensor layer of automation architecture, transmitting real-time force data to programmable logic controllers (PLCs), monitoring and data acquisition (SCADA) systems, and other control units. The unique feature of PFTL101B 2.0KN 3BSE004185R1 lies in its enhanced environmental protection function. It adopts a sturdy shell with excellent sealing performance, which can prevent the invasion of dust, moisture, and corrosive substances. In addition, it also has built-in temperature compensation and anti-interference mechanisms, which can maintain stable performance even under extreme environmental fluctuations. This module also has comprehensive diagnostic functions, which can continuously monitor its internal status and the quality of measurement signals. Once any abnormalities are detected, an alarm will be immediately issued to the operator.
PFTL101B 2.0KN 3BSE004185R1
Technical specifications:
Model PFTL101B 2.0KN 3BSE004185R1
Brand ABB
Type of force sensing module
Rated load 2.0 kilonewtons (KN)
Input voltage 24V DC (VDC)
Working temperature range -30 ° C to 70 ° C
Installation method: flange installation
Dimensions 90mm x 70mm x 60mm
Weight 0.4 kilograms
Interface/Bus Profibus, Modbus RTU
Certification CE, RoHS
Supports protocols Profibus DP and Modbus RTU
Typical power consumption of 6 watts (W)
Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
PFTL101B 2.0KN 3BSE004185R1
Main features and advantages:
It can operate reliably in harsh environments, eliminating the need for frequent sensor replacement due to environmental damage and significantly reducing maintenance costs. For example, in mining operations, traditional sensors may fail due to dust intrusion or vibration damage, while PFTL101B 2.0KN 3BSE004185R1can continue to operate accurately, ensuring uninterrupted monitoring of forces in mining equipment. The high-precision force measurement capability of this module can achieve precise control of industrial processes, thereby improving product quality and reducing material waste. Its long-term stability and advanced diagnostic capabilities support predictive maintenance strategies, enabling engineers to detect potential problems in a timely manner before they escalate into major failures, thereby minimizing unplanned downtime and improving production efficiency. In addition, its compatibility with common industrial protocols simplifies integration with existing automation systems, making it easy to seamlessly upgrade and expand.
Application areas:
PFTL101B 2.0KN 3BSE004185R1has a wide range of applications in industries that require operation in harsh environments. In the mining industry, it is used to monitor the forces acting on mining trucks, conveyor belts, and heavy machinery. The robust design of this module enables it to withstand the continuous vibrations, dust, and extreme temperatures of mining sites, ensuring accurate force measurement for equipment health monitoring and process optimization. In the marine and offshore industries, it is installed on oil drilling platforms and ships to measure forces during cargo loading and unloading, mooring operations, and mechanical operation on board. Its ability to resist high humidity, saltwater corrosion, and harsh weather conditions makes it a reliable choice for these marine applications. In addition, in industrial foundries, due to the presence of high temperatures and strong electromagnetic fields, PFTL101B 2.0KN 3BSE004185R1 can accurately measure forces during metal casting and forging processes, thereby achieving better control and quality assurance.
Related products:
PFTL102B 3.0KN 3BSE004186R1: Provides higher load-bearing capacity and is suitable for applications that require measuring extremely strong forces, such as heavy construction equipment or large material handling systems.
PFTL11011.0KN 3BSE004166R1: Low capacity, but with standard environmental protection functions, suitable for milder industrial environments with high cost-effectiveness requirements.
PFTL101C 2.0KN 3BSE004187R1: With enhanced electromagnetic interference resistance, it is more suitable for industries with high-intensity electromagnetic fields, such as power plants equipped with large transformers.
PFTL101B-H 2.0KN 3BSE004188R1: With higher accuracy and faster response time, it is suitable for applications that require ultra precise and real-time force measurement under harsh conditions, such as high-speed precision machining in outdoor manufacturing facilities.
PFTL103B 2.5KN 3BSE004189R1: Equipped with additional communication interfaces, it provides greater flexibility for applications that require integration with complex automation systems with diverse communication requirements in harsh environments.
PFTL101B-S 2.0KN 3BSE004190R1: Designed to be more compact, suitable for installation in harsh industrial environments with limited space, such as small mining operations or compact offshore modules.
Installation and maintenance:
Before installing PFTL101B 2.0KN 3BSE004185R1, it is necessary to ensure that the installation surface is flat, clean, and free of any contaminants that may affect module performance. Although the module can operate under extreme conditions, it is still necessary to confirm that the expected environmental conditions at the installation site are within the operating range specified by the module. Carefully check the power supply voltage to ensure it is a stable 24V DC, as any fluctuations may affect the accuracy of the measurement. When integrating with existing control systems, carefully configure communication protocol settings to ensure smooth data transmission. It is strongly recommended to use calibrated force standards for initial calibration in environments similar to actual operating conditions to establish accurate baseline measurements.
For continuous maintenance, although the module is designed to be durable, it is still recommended to conduct regular visual inspections. Check for any physical signs of damage to the casing, such as cracks or wear, which may affect its environmental protection performance. Regularly monitor the diagnostic information provided by the module to detect any early signs of performance degradation. Regular recalibration according to the manufacturer’s recommendations will help maintain the accuracy of the module over its long-term lifespan.
