NI PXI-6052E is a multifunctional and powerful data acquisition (DAQ) device. As a single slot PXI module, it can be easily integrated into PXI based control platforms, which are widely used in the field of industrial automation due to their modularity and scalability. It serves as a critical interface between on-site sensors and actuators and the central control system.
PXI-6052E
This module has 16 analog inputs and is capable of processing various sensor signals. These inputs can be configured as 8 single ended channels or 8 differential channels, providing flexibility according to application requirements. The module supports 15 different analog input signal ranges, enabling it to interface with sensors that output signals of different voltage levels. For example, it can handle low voltage signals from resistance temperature detectors (RTDs) or high voltage signals from certain industrial sensors.
PXI-6052E
Main features and advantages:
The NI PXI-6052E also has 2 analog outputs that can be used to control actuators or provide reference signals. In addition, it is equipped with 8 digital I/O lines and two 24 bit counters/timers. This device supports both analog and digital triggering, and can achieve precise synchronization with other devices in the automation stack. It can be programmed and configured using NI DAQ driver software, which is compatible with popular software development environments such as LabVIEW, LabWindows/CVI, and Measurement Studio. This enables engineers to easily develop customized applications that meet their specific industrial automation needs.
This device is designed for high performance and reliability, ensuring long-term stable operation even in harsh industrial environments. Its 16 bit resolution provides accurate data acquisition, which is crucial for precision critical applications such as scientific research or high-quality manufacturing processes.
The module’s high sampling rate of 333 kS/s enables it to effectively capture rapidly changing signals. This is particularly useful in applications such as high-speed mechanical monitoring, as accurate detection of rapid changes in vibration or velocity is required. The software configurable feature of this device reduces engineering costs. Engineers can easily adapt the NI PXI-6052E to different applications without the need for complex hardware modifications. This flexibility also extends to its compatibility with various software development environments, enabling seamless integration into existing engineering workflows.
PXI-6052E
Technical specifications:
Model PXI-6052E
Brand NI
Type: Multi functional data collection device
Working temperature range: 0 ° C to+55 ° C
Installation method: PXI single slot module, easy to integrate into PXI chassis
Compact size, suitable for PXI modular systems
Interface/bus PXI bus, used for high-speed data transmission and communication within PXI systems
Compliance meets relevant industry standards and can operate reliably in industrial environments
Support protocol compatibility with protocols used in industrial automation and data acquisition through NI DAQ drivers
contact us
Phone:+86 16626708626
WhatsApp/WeChat:+86 16626708626
Email: 3772179818@qq.com
PXI-6052E
Application areas:
In the automotive manufacturing industry, it is used to monitor and control various production processes. It can be used to measure the torque and speed of motors in robotic arms used for vehicle assembly. The accurate data collection capability of NI PXI-6052E ensures that these robotic arms can operate with high precision, reducing the possibility of assembly errors.
In the field of energy, especially in power plants, this module is used for real-time monitoring of electrical parameters such as voltage, current, and frequency. This helps to maintain grid stability and ensure efficient power generation.
In research laboratories, NI PXI-6052E is a popular choice for data acquisition. It can be used to collect data from various sensors, such as sensors that measure temperature, pressure, and chemical concentration, providing researchers with accurate and reliable data for analysis.
PXI-6052E
Related products:
NI PXI-6071E: Provides 12 bit resolution and a higher maximum sampling rate of 1.25 MS/s, suitable for applications where speed is prioritized over higher resolution.
NI PXI-6070E: With 12 bit resolution and different input/output configurations, it may be more suitable for certain traditional systems or applications with specific I/O requirements.
NI PCI-6052E: Can be used for systems that do not have a PXI chassis but still require high-performance data acquisition capabilities.
NI PXI-6062E: Adopting different form factors (PCMCIA), it may be more suitable for portable or space limited applications, while still providing reliable data acquisition capabilities.
NI PXI-6040E: With different feature sets, sampling rates, and input/output characteristics, it can be used as an application with specific performance requirements.
Installation and maintenance:
Before installing NI PXI-6052E , it is essential to ensure that the PXI chassis has available slots and that the chassis power supply can support additional modules. Check the NI DAQ driver version on the computer and ensure it is up-to-date to ensure compatibility with NI PXI-6052E . At the same time, verify whether the output signals of sensors and other devices connected to the module are within the supported voltage range.
For continuous maintenance, it is necessary to regularly check the connections between modules and other devices to ensure their firmness. Loose connections may cause signal loss or interference. Monitor module performance through diagnostic tests provided by NI-DAQ software. These tests help detect any potential issues, such as abnormal noise or incorrect triggering in the collected signal. If the module is used in dusty or humid environments, appropriate environmental control measures should be considered to prevent damage to internal components.
