MOTOROLA MVME2700-761 high – performance VMEbus processor module
Sale!
MOTOROLA MVME2700-761 high – performance VMEbus processor module
The MOTOROLA MVME2700-761 is a high – performance VMEbus processor module that is part of Motorola’s advanced industrial – grade computing product line. It is designed to meet the stringent requirements of embedded computing applications across a wide range of industries. In a control system’s architecture, the MVME2700 – 761 functions as a central processing unit, acting as the nerve center that coordinates all system operations.
Model MVME2700-761
Brand MOTOROLA
Type VMEbus Processor Module
Processor PowerPC 750, up to 350 MHz (or 400 MHz in some cases)
Memory 32 – 512 MB ECC SDRAM
Flash Memory 2 – 8 MB (for boot code and configuration data)
Cache 32 KB / 32 KB L1 cache, 1 MB backside L2 cache
Interfaces VMEbus, Ethernet, Serial ports (e.g., RS – 232), and potentially parallel ports
Expansion Supports two PCI Mezzanine Cards (PMCs)
Operating Temperature – 40°C to + 85°C
Storage Temperature – 55°C to + 150°C
Dimensions Standard VME module size (compatible with VME enclosures)
Power Supply Check product documentation (usually DC power)
Certifications May include CE, UL, etc.
The MOTOROLA MVME2700-761 is a high – performance VMEbus processor module that is part of Motorola’s advanced industrial – grade computing product line. It is designed to meet the stringent requirements of embedded computing applications across a wide range of industries. In a control system’s architecture, the MVME2700 – 761 functions as a central processing unit, acting as the nerve center that coordinates all system operations.
MVME2700-761
This module is built around the PowerPC 750 processor, which offers remarkable computational power. It can handle complex algorithms and multitasking scenarios with ease, making it an ideal choice for applications that demand high – speed data processing. The MVME2700-761 features a modular design, which is highly beneficial for engineers and integrators. With its support for two PCI Mezzanine Cards (PMCs), it allows for customization according to specific application requirements. Whether it’s adding more communication interfaces to connect with a wider range of devices or enhancing data storage capabilities for large – scale data processing, the flexibility of this module makes it adaptable to a wide array of industrial, medical, and scientific applications. It interfaces seamlessly with other VME – based modules within a system, enabling smooth data flow and efficient operation.
MVME2700-761
Main features and advantages:
Functionally, the MOTOROLA MVME2700-761 is a top – tier performer. The PowerPC 750 processor, which can operate at frequencies up to 350 MHz (or in some configurations, 400 MHz), enables it to execute complex computational tasks at high speed. The module is equipped with a 32 KB / 32 KB L1 cache and a 1 MB backside L2 cache. These caches significantly enhance performance by reducing the time the processor takes to access frequently used data, thus accelerating overall system operation. The on – board ECC SDRAM, available in configurations ranging from 32 MB to 512 MB, ensures data integrity. In environments where electrical interference or other disruptions are common, the error – correcting code feature safeguards the accuracy of data storage and retrieval.
From a hardware design perspective, the MVME2700-761 is rugged and built to endure harsh conditions. It can withstand high temperatures (operating temperature range from – 40°C to + 85°C), vibrations, and electrical noise, which are typical in industrial settings. Its form factor is designed to fit standard VME system enclosures, simplifying installation and integration into existing systems. The support for two PCI Mezzanine Cards (PMCs) provides ample room for expansion. As the requirements of an application evolve, additional functionality can be added without the need to replace the entire module.
Compatibility is one of the MVME2700-761‘s strong suits. It is fully compliant with the VMEbus standard, allowing it to communicate seamlessly with other VME – based modules. This compatibility extends to its rich set of interfaces. It has Ethernet for high – speed network connectivity, which is essential for real – time data transfer in modern industrial and medical applications. It also features serial ports (such as RS – 232) for connecting to legacy devices, ensuring backward compatibility. Additionally, it may have parallel ports in some configurations, providing more options for interfacing with a variety of external devices. The module’s long – term reliability is further enhanced by its thermal design. It dissipates heat efficiently, even during continuous operation, which helps in maintaining stable performance and prolonging its service life.
Technical specifications:
Model MVME2700-761
Brand MOTOROLA
Type VMEbus Processor Module
Processor PowerPC 750, up to 350 MHz (or 400 MHz in some cases)
Memory 32 – 512 MB ECC SDRAM
Flash Memory 2 – 8 MB (for boot code and configuration data)
Cache 32 KB / 32 KB L1 cache, 1 MB backside L2 cache
Interfaces VMEbus, Ethernet, Serial ports (e.g., RS – 232), and potentially parallel ports
Expansion Supports two PCI Mezzanine Cards (PMCs)
Operating Temperature – 40°C to + 85°C
Storage Temperature – 55°C to + 150°C
Dimensions Standard VME module size (compatible with VME enclosures)
Power Supply Check product documentation (usually DC power)
Certifications May include CE, UL, etc.
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
Application areas:
In the dynamic and demanding landscapes of various industries, the MOTOROLA MVME2700-761 emerges as a highly versatile and indispensable component.
In the industrial automation sector, it serves as a linchpin in complex manufacturing processes. For example, in automotive assembly plants, the MVME2700-761 plays a crucial role in coordinating the operations of robotic arms. These arms, guided by the module, perform tasks such as spot – welding car frames with pinpoint accuracy. It processes real – time data from sensors that monitor the position of the arm, the quality of the weld, and the temperature of the welding tip. By analyzing this data, the MVME2700-761 can adjust the movement and parameters of the robotic arm, ensuring high – quality production and minimizing errors. In electronics manufacturing, it controls the precise placement of tiny components on circuit boards. The module’s high – speed data processing capabilities enable it to manage the rapid movement of pick – and – place machines, increasing production efficiency.
The power generation industry also heavily relies on the MOTOROLA MVME2700-761. In power plants, whether they are fossil – fuel – based, nuclear, or renewable energy facilities, this module is used for data acquisition and control. It collects data from a vast array of sensors that monitor variables such as temperature, pressure, and voltage in turbines, generators, and transformers. By processing this data in real – time, the MVME2700-761 helps in optimizing power generation, adjusting equipment settings to maintain grid stability, and ensuring the safe and efficient operation of the power plant. In wind farms, it can control the orientation of wind turbine blades to maximize energy capture based on wind speed and direction data.
In the medical field, theMVME2700-761 is an essential part of medical imaging devices. In CT and MRI scanners, it processes the large amounts of data generated during imaging procedures. This data processing is critical for creating high – resolution images that aid doctors in accurate diagnosis. It can also be found in hospital laboratories, where it automates the operation of testing equipment. It controls the movement of samples, the dispensing of reagents, and the analysis of test results, ensuring rapid and precise medical testing.
Related products:
MVME2700 base model: Serves as a reference point. It shares the overall architecture but may lack some of the specific features of the – 761 variant, such as certain interface configurations or advanced I/O capabilities.
MVME761 Transition Module: This module is closely related as the MVME2700 – 761 is designed to work in harmony with it. The MVME761 provides additional interfaces like an IEEE 1284 parallel port accessible via an RJ – 45 connector, 10BaseT or 100BaseT ports, two DB – 9 connectors for asynchronous serial ports configured as EIA – 574 DTE, and two HD – 26 connectors for synchronous/synchronous serial ports.
RAM200 Memory Expansion Modules: These are compatible with the MVME2700 series, including the – 761 model. They allow for on – site memory capacity upgrades from 16MB to 256MB of ECC DRAM without the need for additional VME slots, enhancing the data – handling capabilities of the MVME2700 – 761.
IPMC761: This is an optional module that can be used in certain configurations related to the MVME2700 – 761. It is designed around the PMC form factor and integrates features like a PCI – to – ISA bridge, an ultra – wide SCSI adapter, and super I/O functions, which can be useful for specific applications where these additional functions are required.
