Name: Motorola MVME187-CP109 Configurable VMEbus Single-Board Computer | Qiming Automation
Brand: MOTOROLA
Price: 49497.00 CNY
Availability: InStock

Description

The Motorola MVME187-CP109 functions as a configurable processing core within VMEbus control architectures, combining the foundational strengths of the MVME187 series with specialized firmware optimized for custom application logic. Like its counterparts, it integrates seamlessly with IEEE 1014-compliant VMEbus backplanes, ensuring compatibility with existing infrastructure while adding a dedicated coprocessor for executing proprietary control routines.

MVME187-CP109

This design allows the Motorola MVME187-CP109 to handle both standard automation tasks and custom logic simultaneously, eliminating the need for external processing modules that introduce latency or integration complexity. It supports all core industrial protocols of the MVME187 family—including RS-232, RS-485, and Ethernet—while adding enhanced memory partitioning to isolate custom code from critical system operations, preventing logic errors from disrupting essential functions. Its diagnostic suite includes advanced error logging specific to custom routines, making it easier for engineers to troubleshoot proprietary code execution alongside hardware performance.

MVME187-CP109

Technical specifications:
Model Number MVME187-CP109
Brand Motorola
Type Configurable VMEbus Single-Board Computer
Input Voltage +5V DC, ±12V DC
Operating Temp Range 0°C to 65°C (32°F to 149°F)
Mounting Style 6U VMEbus backplane mount
Dimensions 233mm x 160mm (9.17in x 6.30in)
Weight 640g (22.6oz)
Interface/Bus VMEbus (IEEE 1014-1987, 32-bit data path)
Compliance CE, UL 508, RoHS, IEC 61010
Supported Protocols RS-232, RS-485, Ethernet, SCSI
Typical Power Draw 28W (max)

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

MVME187-CP109

Main features and advantages:

Choosing the Motorola MVME187-CP109 delivers distinct advantages for engineers working with custom industrial systems. Its dedicated coprocessor offloads proprietary logic execution from the main CPU, ensuring that custom routines—whether for specialized motion control, batch processing algorithms, or legacy equipment interfaces—run without impacting core system performance. This separation enhances reliability, as a fault in custom code won’t compromise essential functions like sensor data acquisition or safety interlocks. The module’s enhanced memory partitioning simplifies code management, allowing engineers to update custom logic without disrupting critical system operations—a key benefit for facilities running 24/7 production cycles. Additionally, its compatibility with MVME187-series peripherals means existing I/O modules, expansion cards, and support infrastructure can be reused, reducing upgrade costs while leveraging familiarity with the platform.

Application areas:

The Motorola MVME187-CP109 is ideally suited for applications requiring custom control logic in demanding environments. In aerospace manufacturing, it manages specialized riveting machinery, executing proprietary force-feedback algorithms to ensure precise joint integrity while processing real-time data from pressure and position sensors. Its programmability allows for quick adjustments to accommodate different aircraft component specifications. In industrial oven systems for ceramics processing, the Motorola MVME187-CP109 runs custom temperature profiling routines, coordinating heating elements, conveyors, and exhaust systems to maintain precise thermal cycles critical for material integrity. Its rugged design withstands the ambient heat and electrical noise of these environments, ensuring consistent performance. Additionally, in custom packaging machinery for pharmaceutical production, it executes proprietary serialization and inspection logic, integrating with vision systems and labeling equipment to meet strict regulatory tracking requirements.

Related products:

MVME187-CP101 – Entry-level configurable variant with basic custom logic support for simple applications.

MVME187-CP209 – High-memory version of the Motorola MVME187-CP109 for data-intensive custom algorithms.

MVME187-001 – Standard MVME187 model, often upgraded to Motorola MVME187-CP109 for added programmability.

MVME177-005 – Specialized analog I/O module optimized for use with Motorola MVME187-CP109 in custom sensing applications.

MVME188-002 – Redundant power module certified for use with Motorola MVME187-CP109 in safety-critical setups.

MVME3100-CP10 – Modern successor with enhanced programmability, compatible with Motorola MVME187-CP109 code bases.

MVME187-CP109-R – Ruggedized version of the Motorola MVME187-CP109 for extreme vibration environments.

Installation and maintenance:

Before installing the Motorola MVME187-CP109 , verify that the target VMEbus backplane has sufficient power overhead to accommodate its 28W max draw—critical for stable operation of the dedicated coprocessor. Confirm firmware compatibility with any custom logic development tools, as older software versions may require updates to support the module’s memory partitioning features. Ensure the enclosure provides at least 35CFM airflow when operating above 50°C, as the coprocessor generates additional heat during intensive logic execution.

For maintenance, schedule quarterly reviews of custom logic error logs, separate from standard system diagnostics, to catch code-related issues early. Annual functional testing should include validating both core system operations and custom routines, as interactions between the two can sometimes introduce unexpected behavior. When updating custom code, use the module’s memory partitioning to load new logic without powering down, then verify execution in a test mode before activating in production.
